Hyundai R55-7 R55-7A R55-9 R55-9A R60-9S R60CR-9 R60CR-9A excavator travel motor rotary group

Hyundai R55-7 R55-7A R55-9 R55-9A R60-9S R60CR-9 R60CR-9A excavator travel motor rotary group

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
31M8-40020 31M8-40021 31M8-40022 XKAY-01861 XKAY-02242 R55-7 R55-7A R55-9 R55-9A R60-9S R60CR-9 R60CR-9A
Pos. Part No Qty Parts name Comments
*. 31M8-40020 [1]   TRAVLE MOTOR
*. 31M8-40021 [1]   TRAVEL MOTOR
*. 31M8-40022 [1]   TRAVEL UNIT ASSY
*-1. XKAY-01861 [1]   TRAVEL MOTOR ASSY
*-1. XKAY-02242 [1]   TRAVEL MOTOR_9SERIES
*. @ [1]   TRAVEL  MOTOR      SEE 4270
*-1. @ [1]   TRAVEL MOTOR ASSY      SEE 4270
1 XKAY-00331 [1]   CASING-SHAFT
2 XKAY-00332 [1]   EXPAND
K3. XKAY-00333 [1]   SEAL-OIL
4 XKAY-00334 [1]   SHAFT
4 XKAY-01950 [1]   SHAFT
5 XKAY-00335 [1]   BEARING
5 XKAY-01949 [1]   BEARING-ROLLER
6 XKAY-00336 [1]   PISTON KIT-SWASH
7 XKAY-00338 [1]   SPRING
8 XKAY-00339 [1]   BALL-SWASH STILL
9 XKAY-00340 [1]   PLATE-SWASH
10 XKAY-00341 [1]   PLATE-SHOE
*-1. XKAY-00342 [1]   ROTARY KIT
*-1. XKAY-01945 [1]   ROTARY KIT
*-11. XKAY-00343 [1]   CYLINDER BLOCK KIT
*-11. XKAY-01946 [1]   CYLINDER BLOCK KIT
11 XKAY-00344 [1]   BLOCK-CYLINDER
11 XKAY-01947 [1]   CYLINDER BLOCK
N12. XKAY-00345 [2]   SEAT-SPRING
13 XKAY-00346 [1]   SPRING
N14. XKAY-00347 [1]   RING-SNAP
N15. XKAY-00348 [3]   PIN
N56. XKAY-00383 [1]   PLATE-VALVE
56 XKAY-01948 [1]   PLATE-VALVE
*-12. XKAY-00349 [1]   RETAINER KIT
16 XKAY-00350 [1]   GUIDE-BALL
N17. XKAY-00351 [1]   PLATE-SET
18 XKAY-00352 [1]   PISTON KIT
19 XKAY-00354 [3]   PLATE-FRICTION
20 XKAY-00355 [3]   PLATE-PARKING
21 XKAY-00356 [1]   PISTON-PARKING
K22. XKAY-00357 [1]   O-RING
K23. XKAY-00358 [1]   O-RING
K24. XKAY-00359 [3]   O-RING
K25. XKAY-00360 [1]   O-RING
54 @ [1]   BEARING
57 XKAY-00384 [1]   PLATE-SPRING
K85. XKAY-00410 [1]   RING-BACK UP
K86. XKAY-00411 [1]   RING-BACK UP
K. XKAY-00413 [1]   SEAL KIT
N. @ [AR]   NOT SUPPLIED PARTS
46 XKAY-00378 [2]   RELIEF VALVE ASSY
46 XKAY-02220 [2]   RELIEF VALVE ASSY
