HYUNDAI R55-7 R55-7A R55-9 R55-9A R60-7 R60-9S R60CR-9 R60CR-9A excavator travel motor parts

Name: HYUNDAI R55-7 R55-7A R55-9 R55-9A R60-7 R60-9S R60CR-9 R60CR-9A excavator travel motor parts
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

HYUNDAI R55-7 R55-7A R55-9 R55-9A R60-7 R60-9S R60CR-9 R60CR-9A excavator travel motor parts

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

31M8-40020GG 31M8-40021GG 31M8-40022GG XKAY-01861 XKAY-02242 R55-7 R55-7A R55-9 R55-9A R60-7 R60-9S R60CR-9 R60CR-9A

Pos.	Part No	Qty	Parts name	Comments
*.	@	[1]	TRAVEL MOTOR	SEE 4230
*-1.	@	[1]	TRAVEL MOTOR ASSY	SEE 4230
1	XKAY-00331	[1]	CASING-SHAFT
2	XKAY-00332	[1]	EXPAND
K3.	XKAY-00333	[1]	SEAL-OIL
4	XKAY-00334	[1]	SHAFT
4	XKAY-01950	[1]	SHAFT
4	XKAY-02206	[1]	SHAFT
4	XKAY-01950	[1]	SHAFT
5	XKAY-00335	[1]	BEARING
5	XKAY-01949	[1]	BEARING-ROLLER
6	XKAY-00336	[1]	PISTON KIT-SWASH
7	XKAY-00338	[1]	SPRING
8	XKAY-00339	[1]	BALL-SWASH STILL
9	XKAY-00340	[1]	PLATE-SWASH
10	XKAY-00341	[1]	PLATE-SHOE
*-1.	XKAY-00342	[1]	ROTARY KIT
*-1.	XKAY-01945	[1]	ROTARY KIT
*-1.	XKAY-02207	[1]	ROTARY KIT
*-1.	XKAY-01945	[1]	ROTARY KIT
*-11.	XKAY-00343	[1]	CYLINDER BLOCK KIT
*-11.	XKAY-01946	[1]	CYLINDER BLOCK KIT
*-11.	XKAY-02208	[1]	CYLINDER BLOCK KIT
*-11.	XKAY-01946	[1]	CYLINDER BLOCK KIT
11	XKAY-00344	[1]	CYLINDER BLOCK
11	XKAY-01947	[1]	CYLINDER BLOCK
11	XKAY-02209	[1]	CYLINDER BLOCK
11	XKAY-01947	[1]	CYLINDER BLOCK
N12.	XKAY-00345	[2]	SEAT-SPRING
13	XKAY-00346	[1]	SPRING
N14.	XKAY-00347	[1]	RING-SNAP
N15.	XKAY-00348	[3]	PIN
N56.	XKAY-00383	[1]	PLATE-VALVE
56	XKAY-01948	[1]	PLATE-VALVE
*-12.	XKAY-00349	[1]	RETAINER KIT
16	XKAY-00350	[1]	GUIDE-BALL
N17.	XKAY-00351	[1]	PLATE-SET
18	XKAY-00352	[9]	PISTON KIT
18	XKAY-02210	[9]	PISTON KIT
19	XKAY-00354	[3]	PLATE-FRICTION
20	XKAY-00355	[3]	PLATE-PARKING
21	XKAY-00356	[1]	PISTON-PARKING
K22.	XKAY-00357	[1]	O-RING
K22.	XKAY-02212	[1]	O-RING
K23.	XKAY-00358	[1]	O-RING
K23.	XKAY-02213	[1]	O-RING
K24.	XKAY-00359	[3]	O-RING
K24.	XKAY-02214	[3]	O-RING
K25.	XKAY-00360	[1]	O-RING
K25.	XKAY-02215	[1]	O-RING
54	@	[1]	BEARING
57	XKAY-00384	[1]	PLATE-SPRING
K85.	XKAY-00410	[1]	RING-BACK UP
K85.	XKAY-02228	[1]	RING-BACK UP
K86.	XKAY-00411	[1]	RING-BACK UP
K86.	XKAY-02229	[1]	RING-BACK UP
K.	XKAY-00413	[1]	SEAL KIT
N.	@	[AR]	NOT SUPPLIED PARTS
Pos.	Part No	Qty	Parts name	Comments
*.	31M8-40020GG	[1]	TRAVEL MOTOR
*.	31M8-40021GG	[1]	TRAVEL UNIT ASSY
*.	31M8-40021GG	[1]	TRAVEL MOTOR
*.	31M8-40022GG	[1]	TRAVEL UNIT ASSY
*-1.	XKAY-01861	[1]	TRAVEL MOTOR ASSY
*-1.	XKAY-02242	[1]	TRAVEL MOTOR_9SERIES
*-11.	XKAY-01991	[1]	REAR COVER ASSY
K24.	XKAY-00359	[1]	O-RING
26	XKAY-00361	[1]	COVER-REAR
27	XKAY-00198	[9]	PLUG
28	XKAY-00362	[1]	SPOOL
29	XKAY-00363	[1]	SPRING
30	XKAY-00364	[1]	STOPPER
31	XKAY-00365	[1]	RING-SNAP
32	XKAY-00366	[1]	CHECK
33	XKAY-00367	[1]	SPRING
34	XKAY-00368	[1]	SEAT
35	XKAY-00415	[1]	RING-SNAP
36	XKAY-00369	[2]	CHECK
37	XKAY-00370	[2]	SPRING
38	XKAY-00371	[2]	PLUG
K39.	XKAY-00204	[2]	O-RING
K39.	XKAY-02216	[2]	O-RING
40	XKAY-00205	[2]	RING-BACK UP
40	XKAY-02219	[2]	RING-BACK UP
41	XKAY-00372	[1]	MAIN SPOOL KIT
84	XKAY-00409	[2]	ORIFICE
42	XKAY-00374	[2]	SEAT-SPRING
43	XKAY-00375	[2]	SPRING
44	XKAY-00376	[2]	PLUG
N45.	XKAY-00377	[2]	O-RING
N45.	XKAY-02218	[2]	O-RING
46	XKAY-00378	[2]	RELIEF VALVE ASSY
46	XKAY-02220	[2]	RELIEF VALVE ASSY
47	XKAY-00253	[1]	BALL-STEEL
48	XKAY-00379	[1]	SEAT-CHECK
49	XKAY-00140	[1]	PLUG
50	XKAY-00150	[2]	PLUG
N51.	XKAY-00256	[2]	O-RING
N51.	XKAY-02221	[2]	O-RING
52	XKAY-00380	[1]	PLUG
52	XKAY-00138	[1]	PLUG
K53.	XKAY-00267	[1]	O-RING
K53.	XKAY-02222	[1]	O-RING
54	XKAY-00381	[1]	BEARING-BALL
55	XKAY-00382	[1]	PIN
57	XKAY-00620	[8]	SPRING
58	XKAY-00385	[8]	BOLT-WRENCH
58	XKAY-00385	[8]	BOLT-WRENCH
58	XKAY-00136	[8]	BOLT-SOCKET
87	XKAY-00412	[1]	PLATE-NAME
87	XKAY-02243	[1]	PLATE-NAME
88	XKAY-00277	[2]	RIVET
K.	XKAY-00413	[1]	SEAL KIT
N.	@	[AR]	NOT SUPPLIED PARTS
