HYUNDAI R35Z-7 TRAVEL GEARBOX

HYUNDAI R35Z-7 TRAVEL GEARBOX

$5,600.00 USD
$5,600.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL MOTOR(3/3, MAG-26VP:
Pos. Part No Qty Parts name Comments
*-1. XJBV-00079 [1]   GEAR BOX      INCL 1-28
1 @ [1]   HOLDER-FLANGE
K2. XJBV-00060 [2]   SEAL-FLOATING
3 XJBV-00080 [1]   BEARING-ANGULAR
4 XJBV-00081 [1]   NUT-RING
5 XJBV-00082 [2]   PLUG
6 @ [1]   HOUSING
7 XJBV-00083 [132]   BALL-STEEL
8 XJBV-00084 [3]   PLUG
9 XJBV-00085 [4]   GEAR-PLANETARY B
10 XJBV-00086 [4]   BEARING-NEEDLE
11 XJBV-00087 [4]   COLLAR
12 XJBV-00088 [4]   WASHER-THRUST
13 XJBV-00089 [1]   PLATE-THRUST
14 XJBV-00090 [4]   SCREW
15 XJBV-00091 [1]   GEAR-SUN
16 XJBV-00092 [1]   RING-SNAP
17 XJBV-00093 [1]   HOLDER
18 XJBV-00094 [3]   GEAR-PLANETARY(A)
19 XJBV-00095 [3]   BEARING-NEEDLE
20 XJBV-00096 [3]   RACE-INNER
21 XJBV-00097 [3]   PIN-SPRING
22 XJBV-00098 [1]   GEAR-DRIVE
23 @ [1]   PLATE-THRUST      1.8T
23 @ [1]   PLATE-THRUST      2.3T
23 @ [1]   PLATE-THRUST      2.8T
24 XJBV-00099 [1]   COVER
K25. XJBV-00061 [1]   O-RING
26 XJBV-00100 [1]   WIRE
27 XJBV-00101 [3]   PLUG
28 XJBV-00102 [2]   PLUG
K. XJBV-00117 [1]   SEAL KIT      SEE ILLUST
