HYUNDAI R35Z-7 SWING REDUCTION GEAR

HYUNDAI R35Z-7 SWING REDUCTION GEAR

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING REDUCTION GEAR: R35Z-7 SWING REDUCTION GEAR EPC Hyundai
Pos. Part No Qty Parts name Comments
*-2. @ [1]   REDUCTION GEAR      SEE 4200
1 @ [1]   HOUSING
2 @ [1]   SHAFT-PINION
3 @ [1]   PLATE-THRUST
4 @ [1]   COLLAR
5 @ [1]   BEARING-TAPER ROLLER
6 XJBV-00126 [1]   SEAL-OIL
7 @ [1]   BEARING-TAPER ROLLER
8 @ [2]   PLATE
9 @ [1]   COLLAR
10 XJBV-00044 [1]   HOLDER
11 XJBV-00045 [4]   WASHER-THRUST
12 XJBV-00046 [4]   RACE-INNER
13 XJBV-00047 [4]   BEARING-NEEDLE
14 XJBV-00048 [4]   GEAR-PLANETARY B
15 XJBV-00049 [1]   PLATE-THRUST
16 XJBV-00050 [4]   SCREW
17 XJBV-00051 [1]   GEAR-SUN B
18 XJBV-00052 [1]   HOLDER
19 XJBV-00053 [4]   WASHER-THRUST
20 XJBV-00054 [4]   RACE-INNER
21 XJBV-00055 [4]   BEARING-NEEDLE
22 XJBV-00056 [4]   GEAR-PLANETARY
23 @ [1]   PLATE-THRUST
24 XJBV-00057 [1]   GEAR-DRIVE
35 @ [1]   PLUG
K36. XJBV-00058 [1]   O-RING
K37. XJBV-00059 [1]   O-RING
55 XJBV-00001 [2]   BOLT-SOCKET
