HYUNDAI R35Z-7 R35Z-7A R35Z-9 R35Z-9A EXCAVATOR 31MH-11130 SWING MOTOR PARTS

HYUNDAI R35Z-7 R35Z-7A R35Z-9 R35Z-9A EXCAVATOR 31MH-11130 SWING MOTOR PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
31MH-11130
R35Z-7 R35Z-7A R35Z-9 R35Z-9A
Pos. Part No Qty Parts name Comments
*. 31MH-11130 [1]   SWING MOTOR      SEE 4210
*-1. @ [1]   MOTOR-SWING      AXIAL PISTON
1 XJBV-00006 [1]   CASE
2 XJBV-00007 [1]   BEARING-BALL
3 XJBV-00008 [1]   SHAFT
4 XJBV-00009 [1]   PLATE-THRUST
5 @ [1]   BLOCK-CYLINDER
6 XJBV-00010 [1]   COLLAR
7 XJBV-00011 [1]   SPRING
8 XJBV-00012 [1]   WASHER
9 XJBV-00013 [1]   RING-SNAP
10 XJBV-00014 [3]   PIN
11 XJBV-00015 [1]   HOLDER-RETAINER
12 XJBV-00016 [1]   PLATE-RETAINER
13 @ [9]   PISTON ASSY
14 XJBV-00017 [1]   DISK
15 XJBV-00018 [1]   PISTON-BRAKE
K16. XJBV-00019 [1]   O-RING
NK17. XJBV-00020 [1]   O-RING
18 XJBV-00021 [2]   SEAT-SPRING
19 XJBV-00022 [1]   SPRING ASSY-DISK
K20. XJBV-00023 [1]   O-RING
21 XJBV-00024 [1]   COVER
22 XJBV-00025 [1]   BEARING-BALL
23 XJBV-00026 [1]   PIN
24 XJBV-00027 [1]   PLATE-VALVE
25 XJBV-00028 [2]   PIN
K26. XJBV-00029 [2]   O-RING
27 XJBV-00001 [5]   BOLT-SOCKET
28 XJBV-00030 [1]   ORIFICE
38 XJBV-00031 [2]   VALVE ASSY-RELIEF
38-1. @ [1]   HOUSING-RELIEF
38-2. @ [1]   POPPET
38-3. @ [1]   SEAT-POPPET
38-4. @ [1]   SEAT-SPRING
38-5. @ [1]   SPRING
38-6. @ [1]   PLUG
38-7. @ [1]   GUIDE-SPRING
K38-8. XJBV-00032 [1]   O-RING
38-9. @ [1]   O-RING
38-10. @ [1]   O-RING
K38-11. XJBV-00033 [1]   O-RING
38-12. @ [2]   RING-BACK UP
K38-13. XJBV-00034 [2]   RING-BACK UP
38-14. @ [1]   PISTON
38-15. @ [1]   SCREW-SET
38-16. @ [1]   NUT
39 XJBV-00035 [2]   VALVE-CHECK
40 XJBV-00036 [2]   SPRING
41 XJBV-00037 [2]   PLUG
K42. XJAA-00040 [2]   O-RING
43 XJBV-00039 [2]   PLUG
K44. XJBV-00058 [2]   O-RING
45 XJBV-00041 [1]   PLUG
K46. XJBV-00042 [1]   O-RING
51 @ [1]   NAME PLATE
52 @ [2]   SCREW-DRIVE
A. XJBV-00002 [1]   SEAL KIT      SEE ILLUST
B1. XJBV-00003 [1]   CYLILNDER BLOCK KIT      SEE ILLUST
B5. XJBV-00004 [1]   THRUST PLATE KIT      SEE ILLUST
B6. XJBV-00123 [1]   HOUSING ASSY      SEE ILLUST
