HYUNDAI R35Z-7 R35Z-7A R35Z-9 EXCAVATOR 31MH-10010 HYDRAULIC MAIN PUMP ROTARY GROUP

Name: HYUNDAI R35Z-7 R35Z-7A R35Z-9 EXCAVATOR 31MH-10010 HYDRAULIC MAIN PUMP ROTARY GROUP
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

HYUNDAI R35Z-7 R35Z-7A R35Z-9 EXCAVATOR 31MH-10010 HYDRAULIC MAIN PUMP ROTARY GROUP

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

31MH-10010 R35Z-7 R35Z-7A R35Z-9

Pos.	Part No	Qty	Parts name	Comments
*.	31MH-10010	[1]	MAIN PUMP
1	XJDD-00686	[1]	SHAFT ASSY
1-1.	XJDD-00701	[1]	SHAFT
1-4.	XJDD-00702	[1]	RING
1-5.	XJDD-00703	[1]	RING-RETAINING
1-6.	XJDD-00704	[1]	KEY
1-7.	XJDD-00705	[1]	SHIM
1-8.	XJDD-00706	[1]	SHIM
2	XJDD-00687	[1]	SWASH PLATE ASSY
2-1.	XJDD-00707	[1]	SWASH PLATE
2-2.	XJDD-00708	[1]	GUIDE-SUCTION SIDE
2-3.	XJDD-00709	[1]	BUSHING-SUCTION SIDE
2-4.	XJDD-00710	[1]	GUIDE-DELIVERY SIDE
2-5.	XJDD-00711	[1]	BUSHING-DELIVERY SIDE
3	XJDD-00688	[1]	ROTARY GROUP
3-1.	XJDD-00712	[10]	PISTON ASSY
3-2.	XJDD-00713	[1]	CYLINDER BLOCK
3-3.	XJDD-00714	[1]	RETAINER
3-4.	XJDD-00715	[1]	GUIDE
3-5.	XJDD-00716	[1]	SPRING
3-6.	XJDD-00717	[3]	PRESSURE PIN
3-7.	XJDD-00718	[1]	SPRING SEAT
3-8.	XJDD-00719	[1]	RING-RETAINING
5	XJDD-00690	[1]	SPRING SEAT ASSY
5-1.	XJDD-00728	[1]	SPRING SEAT
5-2.	XJDD-00729	[1]	SPRING SEAT
5-3.	XJDD-00730	[1]	COVER
5-4.	XJDD-00731	[1]	SCREW-ADJUSTING
5-7.	XJDD-00732	[1]	O-RING
5-8.	XJDD-00733	[2]	SCREW-HEX S/HD CAP
5-9.	XJDD-00734	[1]	NUT-HEX
5-10.	XJDD-00735	[1]	GUIDE
5-34.	XJDD-00736	[1]	SHIM
5-44.	XJDD-00737	[1]	SHIM
5-54.	XJDD-00738	[1]	SHIM
6	XJDD-00691	[1]	CONTROL PISTION ASSY
6-1.	XJDD-00739	[1]	SLEEVE
6-2.	XJDD-00740	[1]	PIN-PARALLEL
6-3.	XJDD-00741	[1]	PIECE-DISTANCE
6-4.	XJDD-00742	[1]	PISTON
6-7.	XJDD-00743	[1]	O-RING
6-8.	XJDD-00744	[1]	O-RING
6-9.	XJDD-00745	[3]	SPRING-CONED DISC
6-20.	XJDD-00746	[1]	SHIM
6-21.	XJDD-00747	[1]	SHIM
6-22.	XJDD-00748	[1]	SHIM
8	XJDD-00693	[1]	HOUSING ASSY
11	XJDD-00695	[1]	SEAL-OIL
12	XJDD-00696	[1]	BEARING
14	XJDD-00697	[1]	STOPPER ASSY
14-1.	XJDD-00773	[1]	GUIDE
14-2.	XJDD-00774	[1]	PIECE-DISTANCE
14-3.	XJDD-00745	[2]	SPRING-CONED DISC
14-4.	XJDD-00775	[1]	RING-RETAINING
14-5.	XJDD-00776	[1]	SHIM
14-6.	XJDD-00777	[1]	SHIM
14-7.	XJDD-00778	[1]	SHIM
18	XJDD-00699	[1]	SPRING
19	XJDD-00700	[1]	SPRING
21	XJDD-00010	[1]	VALVE-AIR VENT
Parts on group MAIN PUMP(2/3):

Pos.	Part No	Qty	Parts name	Comments
4	XJDD-00689	[1]	PORT PLATE ASSY
4-1.	XJDD-00720	[1]	PLATE-PORT
4-2.	XJDD-00721	[1]	PLATE-CONTROL
4-3.	XJDD-00722	[1]	PIN-PARALLEL
4-4.	XJDD-00723	[3]	SCREW-HEX S/HD CAP
4-5.	XJDD-00724	[1]	PACKING
4-6.	XJDD-00017	[2]	PLUG
4-7.	XJDD-00725	[1]	BEARING
4-9.	XJDD-00726	[1]	SCREW-HEX S/HD CAP
4-10.	XJDD-00054	[3]	PLUG
4-12.	XJDD-00727	[1]	ORIFICE
9	XJDD-00694	[1]	TROCHOID PUMP ASSY
9-1.	XJDD-00764	[1]	GEAR
9-2.	XJDD-00765	[1]	CASE
9-3.	XJDD-00766	[1]	PLATE-THRUST
9-4.	XJDD-00767	[1]	O-RING
9-5.	XJDD-00768	[1]	PIN-SPRING
9-6.	XJDD-00769	[3]	SCREW-HEX S/HD CAP
9-7.	XJDD-00770	[1]	PLATE-THRUST
9-8.	XJDD-00771	[1]	PIN-SPRING
9-9.	XJDD-00772	[1]	PLATE
16	XJDD-00698	[1]	RELIEF VALVE ASSY
16-1.	XJDD-00101	[1]	SPOOL
16-2.	XJDD-00102	[1]	SCREW-ADJUST
16-3.	XJDD-00103	[1]	O-RING
16-4.	XJDD-00779	[1]	SPRING
16-5.	XJDD-00105	[1]	NUT
16-6.	XJDD-00780	[1]	SEAT-SPRING
Parts on group MAIN PUMP(3/3):

Pos.	Part No	Qty	Parts name	Comments
7	XJDD-00692	[1]	GEAR PUMP
7-3.	XJDD-00749	[1]	HOUSING
7-4.	XJDD-00750	[1]	COVER
7-5.	XJDD-00751	[1]	GEAR
7-6.	XJDD-00752	[1]	GEAR
7-7.	XJDD-00753	[2]	THRUST PLATE ASSY
7-10.	XJDD-00754	[1]	PLATE
7-11.	XJDD-00755	[2]	GUIDE
7-12.	XJDD-00756	[1]	COUPLING
7-14.	XJDD-00781	[2]	O-RING
7-15.	XJDD-00758	[1]	O-RING
7-16.	XJDD-00759	[1]	RING-SQUARE
7-17.	XJDD-00760	[2]	RING-SQUARE
7-18.	XJDD-00761	[1]	O-RING
7-19.	XJDD-00098	[2]	BOLT
7-21.	XJDD-00762	[4]	SCREW-HEX S/HD CAP
N7-30.	XJDD-00763	[1]	NAME PLATE
22	XJDD-00020	[1]	PLUG
