Hyundai R320LC-7 R320LC-7A R340LC-7 excavator 31N9-40020BG 31N9-40021BG 31N9-40022 31N9-40023 31N9-40024 31N9-40025 31N9-40030BG 31N9-40031BG 31N9-40032 31N9-40033 travel motor parts

Name: Hyundai R320LC-7 R320LC-7A R340LC-7 excavator 31N9-40020BG 31N9-40021BG 31N9-40022 31N9-40023 31N9-40024 31N9-40025 31N9-40030BG 31N9-40031BG 31N9-40032 31N9-40033 travel motor parts
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

Hyundai R320LC-7 R320LC-7A R340LC-7 excavator 31N9-40020BG 31N9-40021BG 31N9-40022 31N9-40023 31N9-40024 31N9-40025 31N9-40030BG 31N9-40031BG 31N9-40032 31N9-40033 travel motor parts

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

31N9-40020BG 31N9-40021BG 31N9-40022 31N9-40023 31N9-40024 31N9-40025 31N9-40030BG 31N9-40031BG 31N9-40032 31N9-40033 R320LC-7 R320LC-7A R340LC-7(INDIA)

Pos.	Part No	Qty	Parts name	Comments
*.	31N9-40020BG	[1]	TRACK MOTOR ASSY
*.	31N9-40021BG	[1]	TRACK MOTOR ASSY
*.	31N9-40022	[1]	TRACK MOTOR ASSY
*.	31N9-40023	[1]	TRACK MOTOR ASSY
*.	31N9-40024	[1]	TRAVEL UNIT
*.	31N9-40025	[1]	TRAVEL UNIT
*-1.	31N9-40030BG	[1]	TRAVEL MOTOR
*-1.	31N9-40031BG	[1]	TRAVEL MOTOR
*-1.	31N9-40032	[1]	TRAVEL MOTOR
*-1.	31N9-40033	[1]	TRAVEL MOTOR
1	XKAY-00197	[1]	CASING-SHAFT
1	XKAY-00962	[1]	CASING-SHAFT
1	XKAY-02052	[1]	CASING-SHAFT
3	XKAY-00199	[1]	SCREW-ORIFICE
4	XKAY-00200	[1]	SCREW-ORIFICE
5	XKAY-00201	[2]	PIN-SUPPORT
6	XKAY-00202	[4]	PIN-BRAKE
7	XKAY-00203	[1]	STOPPER(S)
8	XKAY-00204	[4]	O-RING
9	XKAY-00205	[3]	RING-BACK UP
10	XKAY-00206	[1]	PISTON-SWASH
11	XKAY-00207	[1]	SHAFT
12	XKAY-00208	[1]	SPACER-BEARING
13	XKAY-00209	[1]	BEARING-ROLLER
14	XKAY-00210	[1]	RING-STOP
*.	XKAY-00211	[1]	SUPPORT KIT
N15.	XKAY-00212	[1]	SUPPORT
N16.	XKAY-00213	[1]	PLATE-SWASH
17	XKAY-00214	[1]	PISTON-SWASH
18	XKAY-00215	[1]	STOPPER(L)
19	XKAY-00216	[1]	O-RING
20	XKAY-00217	[2]	RING-BACK UP
*.	XKAY-00218	[1]	ROTARY KIT
*.	XKAY-01510	[1]	ROTARY KIT
*.	XKAY-00218	[1]	ROTARY KIT
*-1.	XKAY-00219	[1]	CYLINDER BLOCK KIT
*-1.	XKAY-01509	[1]	CYLINDER BLOCK KIT
*-1.	XKAY-00219	[1]	CYLINDER BLOCK KIT
N21.	XKAY-00220	[1]	BLOCK-CYLINDER
N21.	XKAY-01504	[1]	BLOCK-CYLINDER
N21.	XKAY-00220	[1]	BLOCK-CYLINDER
22	XKAY-00221	[9]	SPRING-CYLINDER
23	XKAY-00222	[1]	SPACER
67	XKAY-00268	[1]	PLATE-VALVE
67	XKAY-01505	[1]	PLATE-VALVE
67	XKAY-00268	[1]	PLATE-VALVE
*-2.	XKAY-00223	[1]	RETAINER KIT
24	XKAY-00224	[1]	GUIDE-BALL
25	XKAY-00225	[1]	SET-PLATE
*-3.	XKAY-00226	[1]	PISTON KIT
N26.	XKAY-00227	[9]	PISTON & SHOE ASSY
27	XKAY-00228	[2]	PLATE-FRICTION
28	XKAY-00229	[1]	PLATE-SEPARATOR
29	XKAY-00230	[1]	RING-PISTON
30	XKAY-00231	[1]	RING-PISTON 252
31	XKAY-00232	[1]	RING-PISTON 278
32	XKAY-00233	[10]	SPRING-BRAKE
33	XKAY-01416	[1]	CASING-VALVE
33	XKAY-01506	[1]	CASING-VALVE
34	XKAY-00235	[1]	BEARING-NEEDLE
35	XKAY-00236	[1]	O-RING
36	XKAY-00237	[2]	PIN-VALVE PLATE
*.	XKAY-00238	[1]	SPOOL KIT-C/BLC VALVE
37	XKAY-00239	[1]	SPOOL-C/BLC VALVE
38	XKAY-00240	[2]	SCREW-ORIFICE
39	XKAY-00241	[2]	DAMPING CHECK ASSY
40	XKAY-00242	[2]	SPRING-C/BLC VALVE
41	XKAY-00247	[2]	O-RING
42	XKAY-00244	[2]	PLUNGER-C/BLC VALVE
43	XKAY-00245	[2]	SPRING-CHECK
44	XKAY-00246	[2]	STOPPER-CHECK
45	XKAY-00247	[4]	O-RING
46	XKAY-00248	[4]	RING-BACK UP
47	XKAY-00249	[1]	CAP-C/BLC VALVE(R)
48	XKAY-00250	[1]	CAP-C/BLC VALVE(L)
49	XKAY-00136	[8]	BOLT-SOCKET
50	XKAY-00251	[4]	BOLT-SOCKET
51	XKAY-00252	[2]	SEAT
52	XKAY-00253	[2]	BALL-STEEL
53	XKAY-00254	[2]	STOPPER
54	XKAY-00255	[7]	PLUG-HP
55	XKAY-00256	[7]	O-RING
56	XKAY-00257	[2]	PLUG-HP
57	XKAY-00672	[2]	RELIEF VALVE ASSY
58	XKAY-00259	[2]	O-RING
59	XKAY-00260	[2]	RING-BACK UP
60	XKAY-00261	[1]	ROD-SWASH
61	XKAY-00262	[1]	O-RING
62	XKAY-00263	[1]	SCREW-LOCK
63	XKAY-00279	[2]	NUT-HEX
64	XKAY-00265	[1]	SPOOL-SWASH
65	XKAY-00266	[1]	PLUG
66	XKAY-00267	[1]	O-RING
68	XKAY-00269	[1]	SPRING-SWASH
69	XKAY-00270	[3]	O-RING
70	XKAY-00271	[8]	BOLT-WRENCH
71	XKAY-00272	[4]	BOLT-SOCKET
72	XKAY-00273	[1]	SCREW-LOCK
73	XKAY-00274	[1]	SEAL-OIL
74	XKAY-00275	[1]	RING-LOCK
75	XKAY-02056	[1]	NAME PLATE
76	XKAY-00277	[2]	RIVET
K.	XKAY-00278	[1]	SEAL KIT	SEE ILLUST
*-2.	@	[1]	T/REDUCTION GEAR
N.	@	[1]	NOT SUPPLIED PARTS
