HYUNDAI R320LC-7 R320LC-7A excavator 31N9-10010 hydraulic pump parts

HYUNDAI R320LC-7 R320LC-7A excavator 31N9-10010 hydraulic pump parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
31N9-10010 R320LC-7 R320LC-7A
Pos. Part No Qty Parts name Comments
*. 31N9-10010 [1]   MAIN  PUMP
*-1. @ [1]   MAIN PUMP UNIT
NS012. XJBN-00567 [2]   BLOCK-CYLINDER
111 XJBN-00015 [1]   SHAFT-DRIVE(F)
113 XJBN-00153 [1]   SHAFT-DRIVE(R)
114 XJBN-00367 [1]   COUPLING-SPLINE
123 XJBN-00017 [2]   BEARING-ROLLER
124 XJBN-00018 [2]   BEARING-NEEDLE
127 XJBN-00019 [3]   SPACER-BEARING
NS151. XJBN-00566 [1]   PISTON
NS152. XJBN-00565 [1]   SHOE
153 XJBN-00020 [2]   PLATE-SET
156 XJBN-00564 [2]   BUSHING-SPHERICAL
157 XJBN-00541 [18]   SPRING-CYLINDER
211 XJBN-00023 [2]   PLATE-SHOE
S212. XJBN-00012 [1]   PLATE-SWASH
S214. XJBN-00013 [1]   BUSHING-TILTING
251 XJBN-00560 [2]   SUPPORT-S.P.
261 XJBN-00025 [1]   COVER(FR)-SEAL
271 XJBN-00026 [2]   CASING-PUMP
312 XJBN-00027 [1]   BLOCK-VALVE
S313. XJBN-00557 [1]   PLATE-VALVE(R)
S314. XJBN-00556 [1]   PLATE-VALVE(L)
325 XJBN-00380 [1]   CASING-VALVE
401 XJBN-00028 [8]    SCREW
406 XJBN-00355 [4]   SCREW
466 XJBN-00356 [2]   PLUG
468 XJBN-00357 [3]   PLUG
490 XJBN-00032 [30]   PLUG
NS531. XJBN-00369 [1]   PIN-TILTING
532 XJBN-00033 [2]   PISTON-SERVO
534 XJBN-00034 [2]   STOPPER(L)
535 XJBN-00035 [2]   STOPPER(S)
N541. XJBN-00036 [4]   SEAT
N543. XJBN-00037 [2]   STOPPER 1
N544. XJBN-00039 [2]   STOPPER 2
545 XJBN-00359 [4]   BALL-STEEL
NS548. XJBN-00360 [1]   PIN-FEED BACK
K702. XJBN-00040 [2]   O-RING
K710. XJBN-00041 [1]   O-RING
K717. XJBN-00042 [2]   O-RING
K719. XJBN-00043 [2]   O-RING
K724. XJBN-00044 [16]   O-RING
K725. XJBN-00362 [4]   O-RING
K727. XJBN-00283 [1]   O-RING
K728. XJBN-00363 [3]   O-RING
K732. XJBN-00047 [2]   O-RING
K774. XJBN-00906 [1]   SEAL-OIL
K789. XJBN-00049 [2]   RING-BACK UP
K792. XJBN-00050 [2]   RING-BACK UP
808 XJBN-00364 [4]   NUT
824 XJBN-00052 [2]   RING-SNAP
885 XJBN-00053 [2]   PIN-2
886 XJBN-00365 [4]   PIN-SPRING
901 XJBN-00055 [2]   BOLT-EYE
953 XJBN-00654 [2]   SCREW-SET
954 XJBN-00057 [2]   SCREW-SET
981 XJBN-00391 [1]   NAME PLATE
983 XJBN-00341 [2]   PIN
*-2. XJBN-00656 [1]   REGULATOR
*-3. XJBN-00655 [1]   GEAR PUMP
11 XJBN-00563 [18]   PISTON ASSY      SEE ILLUST
13 XJBN-00562 [1]   CYLINDER ASSY-RH      SEE ILLUST
14 XJBN-00561 [1]   CYLINDER ASSY-LH      SEE ILLUST
30 XJBN-00011 [2]   SWASH PLATE ASSY      SEE ILLUST
530 XJBN-00371 [2]   TILTING PIN SUB ASSY      SEE ILLUST
K. XJBN-01108 [1]   SEAL KIT-PUMP UNIT      SEE ILLUST
