Hyundai R320LC-7 excavator final drive travel reduction gearbox parts

Hyundai R320LC-7 excavator final drive travel reduction gearbox parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING REDUCTION GEAR(TYPE 1, #1275-):
Pos. Part No Qty Parts name Comments
*-2. 31N9-10180 [1]   SWING REDUCTION  GEAR
*-2. 31N9-10181 [1]   SWING REDUCTION GEAR
1 XKAQ-00427 [1]   CASING
2 XKAQ-00428 [1]   SHAFT-DRIVE
2 XKAQ-00759 [1]   SHAFT-DRIVE
3 XKAQ-00117 [1]   BEARING-ROLLER
4 XKAQ-00119 [1]   SEAL-OIL
5 XKAQ-00120 [1]   BEARING-ROLLER
6 XKAQ-00429 [1]   CARRIER ASSY-2
7 XKAQ-00430 [1]   CARRIER-2
8 XKAQ-00431 [4]   GEAR-PLANET-2
9 XKAQ-00432 [4]   PIN ASSY-2
N10. XKAQ-00433 [1]   PIN-2
N11. XKAQ-00434 [1]   BUSHING-2
12 XKAQ-00435 [8]   WASHER-THRUST
13 XKAQ-00050 [4]   PIN-SPRING
14 XKAQ-00436 [1]   GEAR-SUN-2
15 XKAQ-00437 [1]   CARRIER ASSY-1
16 XKAQ-00438 [1]   CARRIER-1
17 XKAQ-00439 [4]   GEAR-PLANET-1
18 XKAQ-00440 [4]   PIN ASSY 1
N19. XKAQ-00441 [1]   PIN 1
N20. XKAQ-00079 [1]   BUSHING 1
21 XKAQ-00417 [4]   PLATE 1-SIDE
22 XKAQ-00416 [4]   PLATE 2-SIDE
23 XKAQ-00041 [4]   RING-STOP
24 XKAQ-00048 [4]   PIN-SPRING
25 XKAQ-00442 [1]   GEAR-SUN-1
26 XKAQ-00444 [1]   GEAR-RING
27 XKAQ-00443 [1]   PLATE-COVER
28 XKAQ-00445 [1]   SPACER
28 XKAQ-00758 [1]   SPACER
29 XKAQ-00446 [1]   RING-SPACER
30 XKAQ-00072 [2]   PIN-KNOCK
31 XKAQ-00447 [1]   PLATE 3-THRUST
32 XKAQ-00105 [1]   GEAR-PINION
33 XKAQ-00043 [1]   PLATE-LOCK
33 XKAQ-00757 [1]   PLATE-LOCK
34 XKAQ-00064 [8]   BOLT-HEX
35 XKAQ-00042 [2]   BOLT-HEX
35 XKAQ-00756 [4]   BOLT-HEX
36 XKAQ-00292 [1]   WASHER-LOCK
37 XKAQ-00448 [12]   BOLT-SOCKET
38 XKAQ-00049 [1]   PLUG
39 XKAQ-00066 [2]   PLUG
40 XKAQ-00167 [1]   PIPE-GAUGE
41 XKAQ-00450 [1]   BAR-GAGE
42 XKAQ-00143 [1]   POST-AIR BREATHER
