Hyundai R320LC-7 excavator final drive travel reduction gearbox parts

Hyundai R320LC-7 excavator final drive travel reduction gearbox parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING REDUCTION GEAR(TYPE 1, -#1274):
Pos. Part No Qty Parts name Comments
N*-2. 31N9-10151 [1]   SWING REDUCTION GEAR
N*-2. 31N9-10152 [1]   SWING REDUCTION GEAR
1 XKAQ-00106 [1]   CASING-FRONT
1 XKAQ-00141 [1]   CASING-FRONT
1 XKAQ-00279 [1]   CASING-FRONT
1 XKAQ-00329 [1]   CASING-FRONT
2 XKAQ-00003 [1]   CASING-MIDDLE
3 XKAQ-00328 [1]   SHAFT-DRIVE
4 XKAQ-00006 [1]   GEAR-RING 2
4 XKAQ-00172 [1]   GEAR-RING
5 XKAQ-00022 [3]   GEAR-PLANET 2
6 XKAQ-00012 [1]   GEAR-2 SUN
7 XKAQ-00008 [1]   GEAR-RING 1
8 XKAQ-00024 [3]   GEAR-PLANET 1
8 XKAQ-00137 [3]   GEAR-PLANET 1
9 XKAQ-00009 [1]   GEAR-1 SUN
10 XKAQ-00016 [1]   CARRIER
*. XKAQ-00021 [3]   PIN ASSY NO.2
N11. XKAQ-00060 [3]   PIN ASSY-2
N32. XKAQ-00046 [3]   BUSHING 2
12 XKAQ-00059 [6]   WASHER-THRUST
13 XKAQ-00058 [1]   BUTTON-THRUST
14 XKAQ-00019 [3]   PIN 1
14 XKAQ-00136 [3]   PIN ASSY 1
15 XKAQ-00057 [3]   PLATE-SIDE 1
16 XKAQ-00056 [6]   MAGNET
17 XKAQ-00055 [1]   PLATE-SIDE 3
18 XKAQ-00034 [1]   BAR-GAUGE
19 XKAQ-00035 [1]   PIPE-GAUGE
20 XKAQ-00108 [1]   RING-SPACER
20 XKAQ-00111 [1]   RING-SPACER
21 XKAQ-00053 [4]   PIN-KNOCK
21 XKAQ-00053 [2]   PIN-KNOCK
22 XKAQ-00028 [1]   BEARING-ROLLER
23 XKAQ-00027 [1]   BEARING-ROLLER
24 XKAQ-00030 [3]   CAGE-NEEDLE
25 XKAQ-00052 [16]   BOLT-SOCKET
26 XKAQ-00051 [12]   BOLT-SOCKET
27 XKAQ-00033 [1]   SEAL-OIL
27 XKAQ-00138 [1]   SEAL-OIL
27 XKAQ-00280 [1]   SEAL-OIL
27 XKAQ-00330 [1]   SEAL-OIL
28 XKAQ-00050 [3]   PIN-SPRING
29 XKAQ-00049 [1]   PLUG
30 XKAQ-00048 [3]   PIN-SPRING
31 XKAQ-00047 [1]   RING-STOP
33 XKAQ-00045 [1]   RING-STOP
34 XKAQ-00044 [2]   WASHER-LOCK
34 XKAQ-00292 [1]   WASHER-LOCK
35 XKAQ-00105 [1]   GEAR-PINION
36 XKAQ-00043 [1]   PLATE-LOCK
36 XKAQ-00296 [1]   PLATE-LOCK
37 XKAQ-00042 [4]   BOLT-HEX
37 XKAQ-00042 [2]   BOLT-HEX
38 XKAQ-00041 [3]   RING-STOP
39 XKAQ-00040 [3]   PLATE-SIDE 2
40 XKAQ-00109 [1]   CIRCLIP
41 XKAQ-00110 [1]   V-SEAL
42 XKAQ-00143 [1]   AIR BREATHER ASSY
N. @ [1]   NOT SUPPLIED PARTS
