HYUNDAI R290LC R290LC-3 R290LC-3LL R290LC-3RB EXCAVATOR 11E9-1501 31E9-03010 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

Name: HYUNDAI R290LC R290LC-3 R290LC-3LL R290LC-3RB EXCAVATOR 11E9-1501 31E9-03010 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS
Brand: 13035309093
Price: 2000.0 USD
Availability: InStock

HYUNDAI R290LC R290LC-3 R290LC-3LL R290LC-3RB EXCAVATOR 11E9-1501 31E9-03010 HYDRAULIC PUMP ROTARY GROUP AND SPARE PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

11E9-1501 31E9-03010 R290LC R290LC-3 R290LC-3LL R290LC-3RB

Pos.	Part No	Qty	Parts name	Comments
*.	11E9-1501	[1]	MAIN PUMP
*.	31E9-03010	[1]	MAIN PUMP
*-1.	K3V140DT-112R	[1]	MAIN PUMP UNIT
*-1.	K3V140DT-1R2R	[1]	MAIN PUMP UNIT
111	2933800890	[1]	SHAFT-DRIVE(FR)
113	2933800903	[1]	SHAFT-DRIVE(RR)
114	2953801867	[1]	COUPLING-SPLINE
123	PNUP309E	[2]	BEARING-ROLLER
124	PRNA6932	[2]	BEARING-NEEDLE
127	2953802066	[3]	SPACER-BEARING
141	2933800878	[2]	BLOCK-CYLINDER
151	@	[18]	PISTON
152	@	[18]	SHOE
153	2943800488	[2]	PLATE-SET
156	2953801840	[2]	BUSHING-SPHERICAL
157	2953801842	[18]	SPRING-CYLINDER
158	2953801841	[2]	SPACER
211	871A00AA-124	[2]	PLATE-SHOE
212	2933800908	[2]	PLATE-SWASH
212	2923800908	[2]	PLATE-SWASH
214	P1R222616	[2]	BUSHING
251	2923800936	[2]	SUPPORT-SP
261	2943800518	[1]	COVER(FR)-SEAL
263	2933800906	[1]	COVER-REAR
271	2923800904	[2]	CASING-PUMP
312	2923801022	[1]	VALVE-BLOCK
313	38A0R-313N	[1]	PLATE VALVE(RH)
314	38A0R-314N	[1]	PLATE(LH)-VALVE
314	38A0L-314N	[1]	PLATE(LH)-VALVE
401	2953801868	[8]	SCREW
406	OSBM820	[4]	SCREW-HEX SOC HD
413	OSBM1070	[2]	SCREW
466	OVP14	[2]	PLUG
468	OVP34	[3]	PLUG
490	PBP116-2403	[32]	PLUG
N531.	2943800502	[2]	PIN-TILTING
532	2943800503	[2]	PISTION-SERVO
534	2953801865	[2]	STOPPER(L)
535	2953801864	[2]	STOPPER(S)
N541.	2953802029	[4]	SEAT
542	2953802044	[2]	SPACER
N543.	2953802030	[2]	STOPPER 1
N544.	2953802043	[2]	STOPPER 2
545	ODW732	[4]	BALL-STEEL
N548.	2953802202	[2]	PIN-FEED BACK
702	OORBG40	[2]	O-RING
710	OORBG105	[2]	O-RING
710	OORBG105	[1]	O-RING
717	PCPP170	[2]	O-RING
719	PCPP165	[2]	O-RING
724	OORBP8	[16]	O-RING
725	OORBP11	[7]	O-RING
728	OORBP24	[3]	O-RING
732	OORBP21	[2]	O-RING
774	PSPD55788F	[1]	SEAL-OIL
789	OT2BP21	[2]	RING-BACK UP
792	OT2BG40	[2]	RING-BACK UP
808	ORNM20	[4]	NUT
824	OSR45	[2]	RING-SNAP
885	PJR1014	[2]	PIN-2
886	OSPV614	[4]	PIN-SPRING
901	OEBM12	[2]	BOLT-EYE
953	PSSSM2035	[2]	SCREW-SET
954	2953801866	[2]	SCREW-SET
981	PNPA-2550A	[1]	PLATE-NAME
983	OSK2548	[2]	PIN
*-2.	293H-9N29	[1]	REGULATOR
*-3.	3803830583-2	[1]	GEAR PUMP
*-3.	2902440-0397A	[1]	GEAR PUMP
*-4.	V8701302622	[1]	PROPORTIONAL VALVE
*-4.	V9511138109	[1]	EPPR VALVE
S .	38B00-11	[18]	PISTON ASSY
S.	3853802468	[2]	PISTON ASSY
S.	2953802068	[1]	CYLINDER ASSY
S.	2953801992	[1]	CYLINDER ASSY
S.	2953802069	[1]	CYLINDER ASSY-LH
S.	2953801993	[1]	CYLINDER ASSY
S.	2953801991	[2]	SWASH PLATE SUB ASSY
S.	2953802048	[2]	CHECK 1 ASSY
S.	2953802049	[2]	CHECK 2 ASSY
S.	2953801988	[2]	TILTING PIN SUB ASSY
Parts on group PUMP MOUNTING:

Pos.	Part No	Qty	Parts name	Comments
2	11E9-1602	[1]	HOUSING
3	11E9-1601	[1]	COUPLING ASSY
3	11E8-16010	[1]	COUPLING ASSY
3-1.	11E9-1503	[1]	ELEMENT	1SET=4PIECE
N3-1.	11E9-15090	[1]	ELEMENT	1SET=4PIECE
3-2.	11E9-1504	[1]	HUB
3-2.	11E9-15080	[1]	HUB
3-3.	11E9-1505	[4]	BUSHING
N3-3.	11E9-15100	[4]	INSERT-A
3-4.	11E9-1506	[4]	INSERT
N3-4.	11E9-15110	[4]	INSERT-R
3-5.	S107-200502	[8]	BOLT-SOCKET
3-5.	S107-200502	[4]	BOLT-SOCKET
3-6.	11E9-1507	[2]	BOLT-CLAMPING
3-7.	S472-800162	[8]	PIN-SPRING
3-7.	S472-800162	[12]	PIN-SPRING
3-8.	E211-1602	[1]	PLATE
4	S107-200552	[4]	BOLT-SOCKET
5	S017-100652	[12]	BOLT-HEX
6	S411-100002	[24]	WASHER-SPRING
7	S207-101002	[12]	NUT-HEXAGON HEAD
8	S017-100602	[12]	BOLT-HEXAGON HEAD
