HYUNDAI R290LC-9 EXCAVATOR TRAVEL REDUCTION GEAR(TYPE 2, #0318-)

HYUNDAI R290LC-9 EXCAVATOR TRAVEL REDUCTION GEAR(TYPE 2, #0318-)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL REDUCTION GEAR(TYPE 2, #0318-):
Pos. Part No Qty Parts name Comments
*-2. 31Q9-40020 [1]   TRAVEL REDUCTION GEAR
*-2. 31Q9-40021 [1]   TRAVEL REDUCTION GEAR
*-2. 31Q9-40022 [1]   TRAVEL REDUCTION GEAR
*-2. 31Q9-40023 [1]   TRAVEL REDUCTION GEAR
2 XKAQ-00173 [1]   SEAL-FLOATING
2 XKAQ-00803 [1]   SEAL-FLOATING
3 XKAQ-00174 [1]   HOUSING
3 XKAQ-00802 [1]   HOUSING
4 XKAQ-00175 [2]   BEARING-ANGULAR
4 XKAQ-00175-AS [2]   BEARING-ANGULAR      FOR AS ONLY
5 XKAQ-00176 [1]   SHIM
6 XKAQ-00177 [1]   RETAINER
7 XKAQ-00178 [17]   BOLT-WRENCH
8 XKAQ-00398 [1]   CARRIER 3 ASSY
8 XKAQ-00965 [1]   CARRIER 3 ASSY
8-1. XKAQ-00396 [1]   CARRIER 3
8-1. XKAQ-00966 [1]   CARRIER 3
8-2. XKAQ-00389 [4]   GEAR 3-PLANETARY
8-3. XKAQ-00390 [72]   NEEDLE 3
8-4. XKAQ-00391 [8]   WASHER 3-THRUST
8-5. XKAQ-00184 [4]   PIN 3
8-6. XKAQ-00185 [4]   PIN 3-SPRING
8-6. XKAQ-00967 [4]   PIN 3-SPRING
8-7. XKAQ-00186 [1]   GEAR 3-SUN
8-8. XKAQ-00187 [1]   RING 3-SNAP
8-9. XKAQ-00651 [4]   PIN 3-SPRING
8-9. XKAQ-00968 [4]   PIN 3-SPRING
9 XKAQ-00399 [1]   CARRIER ASSY 2
9 XKAQ-00535 [1]   CARRIER ASSY 2
9 XKAQ-00974 [1]   CARRIER ASSY 2
9-1. XKAQ-00397 [1]   CARRIER 2
9-1. XKAQ-00536 [1]   CARRIER 2
9-1. XKAQ-00975 [1]   CARRIER 2
9-2. XKAQ-00392 [3]   GEAR 2-PLANETERY
9-2. XKAQ-00537 [3]   GEAR 2-PLANETARY
9-3. XKAQ-00393 [45]   NEEDLE 2
9-3. XKAQ-00538 [3]   BEARING 2-NEEDLE
9-4. XKAQ-00394 [6]   WASHER 2-THRUST
9-4. XKAQ-00539 [3]   WASHER 2-THRUST
9-5. XKAQ-00193 [3]   PIN 2
9-5. XKAQ-00540 [3]   PIN 2
9-6. XKAQ-00194 [6]   PIN 2-SPRING
9-6. XKAQ-00971 [6]   PIN 2-SPRING
9-7. XKAQ-00195 [1]   GEAR 2-SUN
9-8. XKAQ-00196 [1]   RING 2-SNAP
9-9. XKAQ-00650 [6]   PIN 2-SRPING
9-9. XKAQ-00972 [6]   PIN 2-SRPING
10 XKAQ-00400 [1]   CARRIER 1 ASSY
10-1. XKAQ-00198 [1]   CARRIER 1
10-2. XKAQ-00199 [3]   GEAR 1-PLANETARY
10-3. XKAQ-00200 [3]   BEARING-NEEDLE
10-4. XKAQ-00395 [6]   WASHER 1-THRUST
10-5. XKAQ-00202 [3]   PIN 1
11 XKAQ-00203 [1]   GEAR 1-SUN
12 XKAQ-00204 [3]   PLUG
13 XKAQ-00205 [4]   PIN-LOCK
14 XKAQ-00206 [1]   GEAR-RING
14 XKAQ-00762 [1]   GEAR-RING
15 XKAQ-00207 [24]   BOLT-WRENCH
16 XKAQ-00208 [1]   RING-THRUST
17 XKAQ-00209 [1]   COVER
17 XKAQ-00973 [1]   COVER
18 XKAQ-00210 [AR]   RING 2-THRUST
19 XKAQ-00211 [16]   BOLT-WRENCH
20 XKAQ-00212 [1]   MOTOR-RING
21 XKAQ-00213 [1]   RING 3-THRUST
22 XKAQ-00214 [1]   PAD
23 XKAQ-00215 [1]   COUPLING
24 [1]   CLAMP-HOSE
N. @ [1]   NOT SUPPLIED PARTS
