HYUNDAI R290LC-9 EXCAVATOR TRAVEL REDUCTION GEAR(TYPE 1, -#0317)

HYUNDAI R290LC-9 EXCAVATOR TRAVEL REDUCTION GEAR(TYPE 1, -#0317)

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL REDUCTION GEAR(TYPE 1, -#0317):
Pos. Part No Qty Parts name Comments
N*-2. XJCK-00379 [1]   REDUCTION GEAR ASSY      SEE 4120
1 XJCK-00124 [1]   HOUSING
2 XJCK-00053 [2]   BEARING
3 XJCK-00078 [1]   GEAR-RING
4 XJCK-00047 [25]   SCREW-CAP
5 XJCK-00049 [1]   SEAL-FLOATING
K6. XJCK-00052 [1]   SHIM
7 XJCK-00051 [2]   WASHER-LOCK
8 XJCK-00050 [1]   SUPPORT-RING
9 XJCK-00128 [1]   CARRIER 2
10 XJCK-00380 [1]   PLANETARY GEAR 2
11 XJCK-00126 [6]   WASHER-THRUST
12 XJCK-00381 [3]   NEEDLE BEARING
13 XJCK-00127 [3]   PIN-CARRIER
14 XJCK-00057 [3]   PIN-SPRING
15 XJCK-00382 [1]   SUN GEAR 2
16 XJCK-00146 [1]   CARRIER 1
17 XJCK-00383 [3]   PLANETARY GEAR 1
18 XJCK-00132 [6]   WASHER-THRUST
19 XJCK-00384 [3]   NEEDLE BEARING
20 XJCK-00142 [3]   PIN-CARRIER
21 XJCK-00145 [3]   PIN-SPRING
22 XJCK-00385 [1]   SUN GEAR
23 XJCK-00064 [1]   PLATE-THRUST
24 XJCK-00386 [1]   COVER
25 XJCK-00048 [18]   SCREW-CAP
26 XJCK-00205 [2]   PLUG
27 XJCK-00206 [2]   O-RING
K. XJCK-00416 [1]   SHIM KIT      SEE ILLUST
N. @ [AR]   NOT INDIVIDUALLY SUPPLIED
