HYUNDAI R290LC-9 EXCAVATOR SWING REDUCTION GEAR (TYPE 3, 4)

HYUNDAI R290LC-9 EXCAVATOR SWING REDUCTION GEAR (TYPE 3, 4)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING REDUCTION GEAR (TYPE 3, 4):
Pos. Part No Qty Parts name Comments
*-2. 39Q8-12100 [1]   SWING REDUCTION GEAR      SEE 4107
*-2. 39Q8-12101 [1]   SWING REDUCTION GEAR      SEE 4107
1 39Q8-12110 [1]   GEAR RING
2 39Q8-12120 [1]   SHAFT-DRIVE
3 39Q8-12130 [1]   BEARING-SPH.ROLLER
4 39Q8-12140 [1]   BEARING-SPH.ROLLER
5 39Q8-12150 [1]   PLATE-THRUST
6 39Q8-12160 [1]   RING-SNAP
7 39Q8-12170 [1]   COVER
8 S017-120306 [12]   BOLT-HEX
9 39Q8-12180 [1]   CASING
10 S632-290001 [1]   O-RING
11 S109-100306 [12]   BOLT-SOCKET
K12. 39Q8-12201 [1]   CARRIER NO.2
K13. 39Q8-12211 [4]   GEAR-PLANETARY NO.2
K14. 39Q8-12220 [4]   BEARING-NEEDLE NO.2
K15. 39Q8-12231 [8]   WASHER-THRUST NO.2
K16. 39Q8-12240 [4]   PIN-CARRIER NO.2
K17. S472-910404 [4]   PIN-SPRING
K18. 39Q8-12251 [1]   GEAR-SUN NO.2
K19. 39Q8-12261 [1]   PLATE-THRUST NO.2
K20. 39Q8-12281 [1]   CARRIER NO.1
K21. 39Q8-12291 [3]   GEAR-PLANETARY NO.1
K22. 39Q8-12300 [3]   BEARING-NEEDLE NO.1
K23. 39Q8-12311 [6]   WASHER-THRUST NO.1
K24. 39Q8-12320 [3]   PIN-CARRIER NO.1
K25. S472-800404 [3]   PIN-SPRING NO.1
K26. 39Q8-12331 [1]   GEAR-SUN NO.1
K27. 39Q8-12341 [1]   PLATE-THRUST NO.1
28 39Q8-12350 [1]   SLEEVE
29 S632-140001 [1]   O-RING
30 39Q6-12350 [1]   SEAL-OIL
31 39Q6-41450 [2]   PIN-PARALLEL
32 S109-18050D [14]   BOLT-SOCKET
33 39Q8-12360 [1]   NAME PLATE
34 39Q6-41800 [2]   RIVET
35 P220-430204 [1]   PLUG-HEX
K. 39Q8-12190 [1]   CARRIER ASSY NO.2      SEE ILLUST
K. 39Q8-12270 [1]   CARRIER ASSY NO.1      SEE ILLUST
