HYUNDAI R290LC-9 EXCAVATOR 31Q8-40030 XJCK-00387 TRAVEL MOTOR ROTARY GROUP

HYUNDAI R290LC-9 EXCAVATOR 31Q8-40030 XJCK-00387 TRAVEL MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
31Q8-40030 XJCK-00387 R290LC-9
Pos. Part No Qty Parts name Comments
N*. 31Q8-40030 [1]   TRAVEL UNIT
*-1. XJCK-00387 [1]   MOTOR ASSY
28 XJCK-00388 [1]   CASING
29 XJCK-00389 [1]   PLUG
30 XJCK-00019 [1]   SEAL-OIL
31 XJCK-00027 [1]   RING-RETAINER
32 XJCK-00076 [1]   PLUG-EXPANDER
K33. XJCK-00390 [1]   PISTON-SHIFTER
K34. XJCK-00391 [1]   SEAL-PISTON
35 XJCK-00393 [1]   STEEL BALL
36 XJCK-00037 [1]   SHAFT
37 XJCK-00015 [1]   BEARING
NK38. XJCK-00034 [2]   PIVOT
K39. XJCK-00394 [1]   PLATE SWASH
40 XJCK-00395 [1]   CYLINDER BLOCK
41 XJCK-00017 [9]   SPRING-CYLINDER
42 XJCK-00396 [1]   SPRING HOLDER
43 XJCK-00023 [1]   JOINT-BALL
44 XJCK-00042 [1]   RETAINER-SHOE
45 XJCK-00119 [9]   PISTON ASSY
46 XJCK-00049 [5]   SEAL-FLOATING
47 XJCK-00041 [4]   PLATE-FRICTION
48 XJCK-00040 [1]   PISTON-BRAKE
49 XJCK-00397 [1]   D-RING
50 XJCK-00398 [1]   D-RING
78 XJCK-00014 [1]   BEARING
NK79. XJCK-00026 [2]   SHIM
81 XJCK-00120 [1]   PLATE-VALVE
85 XJCK-00036 [1]   COUPLING
86 XJCK-00028 [1]   RING-RETAINER
K. XJCK-00415 [1]   SHIM KIT      SEE ILLUST
NK. XJCK-00417 [1]   SHIFTER PISTON SET      SEE ILLUST
K. XJCK-00418 [1]   SWASH PLATE SET      SEE ILLUST
*-2. @ [1]   TRAVEL REDUCTION GEAR
Parts on group TRAVEL MOTOR(TYPE 1, 2/2, -#0317):
Pos. Part No Qty Parts name Comments
*-1. @ [1]   TRAVEL MOTOR      SEE 4120
51 XJCK-00399 [1]   REAR COVER
52 XJCK-00075 [14]   PLUG
53 XJCK-00400 [1]   SPOOL ASSY
54 XJCK-00401 [2]   SPRING HOLDER
55 XJCK-00402 [2]   SPRING
56 XJCK-00403 [2]   COVER
57 XJCK-00104 [2]   O-RING
58 XJCK-00404 [1]   SPOOL
59 XJCK-00112 [1]   PIN
60 XJCK-00113 [1]   SPRING-HOLDER
61 XJCK-00111 [1]   SPRING
62 XJCK-00405 [1]   PLUG
63 XJCK-00293 [2]   O-RING
64 XJCK-00115 [1]   CONNECTOR
65 XJCK-00003 [2]   PLUG
66 XJCK-00001 [2]   O-RING
67 XJCK-00406 [2]   RESTRICTOR
68 XJCK-00407 [2]   SPRING
69 XJCK-00408 [5]   PLUG
70 XJCK-00320 [5]   O-RING
71 XJCK-00409 [3]   CHECK VALVE
72 XJCK-00410 [3]   SPRING-CHECK VALVE
73 XJCK-00411 [2]   RESTRICTOR
74 XJCK-00412 [1]   O-RING
75 XJCK-00413 [1]   RESTRICTOR
76 XJCK-00200 [1]   O-RING
77 XJCK-00007 [1]   O-RING
80 XJCK-00012 [1]   PIN-PARALLEL
82 XJCK-00016 [14]   SPRING-BRAKE
83 XJCK-00013 [10]   SCREW-CAP
84 XJCK-00414 [2]   OVERLOAD RELIEF VALVE
87 XJCK-00204 [2]   PLUG
88 XJCK-00190 [2]   O-RING
89 S632-025004 [1]   O-RING
*-2. @ [1]   TRAVEL REDUCTION GEAR
