Hyundai R290LC-7 R290LC-7A R290LC7H R300LC-7 R305LC-7 R320LC-7 R320LC-7A excavator 31N9-10131 31N9-10132 31N9-10133 31N8-12010 swing motor rotary group and spare parts

Hyundai R290LC-7 R290LC-7A R290LC7H R300LC-7 R305LC-7 R320LC-7 R320LC-7A excavator 31N9-10131 31N9-10132 31N9-10133 31N8-12010 swing motor rotary group and spare parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
31N9-10131 31N9-10132 31N9-10133 31N8-12010 R290LC-7 R290LC-7A R290LC7H R300LC-7 R305LC-7 R320LC-7 R320LC-7A
Pos. Part No Qty Parts name Comments
N*. 31N9-10131 [1]   SWING MOTOR ASSY
N*. 31N9-10132 [1]   SWING MOTOR ASSY
N*. 31N9-10133 [1]   SWING MOTOR ASSY
*-1. 31N8-12010 [1]   SWING MOTOR UNIT
31 XKAH-00121 [1]   VALVE-BRAKE
51 XKAH-00122 [2]   VALVE-RELIEF
52 XKAH-00115 [1]   BLOCK
101 XKAH-00162 [1]   SHAFT-DRIVE
106 XKAH-00161 [3]   SPACER
111 XKAH-00160 [1]   BLOCK-CYLINDER
113 XKAH-00159 [1]   BUSHING-SPHERICAL
114 XKAH-00158 [1]   SPRING
116 XKAH-00157 [12]   ROD-PUSH
117 XKAH-00156 [1]   SPACER F
118 XKAH-00155 [1]   SPACER R
NS121. XKAH-00154 [9]   PISTON
NS122. XKAH-00153 [9]   SHOE
123 XKAH-00152 [1]   RETAINER
124 XKAH-00151 [1]   PLATE-SHOE
131 XKAH-00150 [1]   PLATE-VALVE
301 XKAH-00149 [1]   CASING
303 XKAH-00546 [1]   CASING-VALVE
304 XKAH-00147 [1]   COVER-FRONT
304 XKAH-00930 [1]   COVER-FRONT
351 XKAH-00146 [2]   PLUNGER
355 XKAH-00145 [2]   SPRING
401 XKAH-00144 [4]   BOLT-SOCKET
432 XKAH-00143 [2]   RING-SNAP
433 XKAH-00142 [1]   RING-SNAP
437 XKAH-00141 [1]   RING-SNAP
438 XKAH-00140 [1]   RING-SNAP
443 XKAH-00139 [1]   BEARING-ROLLER
444 XKAH-00138 [1]   BEARING-ROLLER
451 XKAH-00137 [2]   PIN-SPRING
464 XKAH-00136 [1]   PLUG-VP
468 XKAH-00136 [2]   PLUG-VP
469 XKAH-00135 [2]   PLUG
K471. XKAH-00134 [1]   O-RING
K472. XKAH-00133 [1]   O-RING
K485. XKAH-00052 [1]   O-RING
K487. XKAH-00052 [2]   O-RING
K488. XKAH-00132 [2]   O-RING
K491. XKAH-00131 [1]   SEAL-OIL
K491. XKAH-00929 [1]   SEAL-OIL
702 XKAH-00130 [1]   PISTON-BRAKE
K706. XKAH-00129 [1]   O-RING
K707. XKAH-00128 [1]   O-RING
712 XKAH-00127 [20]   SPRING-BRAKE
742 XKAH-00126 [2]   PLATE-FRICTION
743 XKAH-00125 [3]   PLATE-SEPERATION
744 XKAH-00120 [2]   PLUG
745 XKAH-00119 [1]   PLUG
746 XKAH-00118 [1]   PLUG
841 XKAH-00114 [2]   BOLT-SOCKET
993 XKAH-00124 [1]   PLUG
994 XKAH-00123 [1]   PLUG
N*-2. 31N9-10150 [1]   SWING REDUCTION GEAR
K. XKAH-00465 [1]   SEAL KIT      SEE ILLUST
S. XKAH-00615KT [1]   PISTON ASSY      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
