HYUNDAI R290LC-3 EXCAVATOR travel reduction gear Parts on group TRAVEL REDUCTION GEAR(-#0888)

HYUNDAI R290LC-3 EXCAVATOR travel reduction gear Parts on group TRAVEL REDUCTION GEAR(-#0888)

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL REDUCTION GEAR(-#0888):
Pos. Part No Qty Parts name Comments
*-2. 3550BX067 [1]   T/REDUCTION GEAR
1 35050BAA-001 [1]   RING GEAR
2 35050BAA-002 [1]   HOUSING(16 HOLE)
2 3530800138 [1]   HOUSING(24 HOLE)
4 35050BAA-004 [1]   COVER-SIDE
5 35050BAA-005 [1]   CARRIER NO1
6 35050BAA-006 [1]   CARRIER NO2
7 35050BAA-007A [1]   CARRIER NO3
8 35050BAA-008 [1]   RETAINER-BEARING
9 35050BAA-009 [1]   GEAR-SUN NO1
10 35050BAA-010 [1]   GEAR-SUN NO2
11 35050BAA-011 [1]   GEAR-SUN NO3
12 35050BAA-012 [3]   GEAR-PLANETARY NO1
13 35050BAA-013 [3]   GEAR-PLANETARY NO2
14 35050-00-014 [4]   GEAR-PLANETARY NO3
15 35050BAA-015 [3]   PIN NO1
16 35050BAA-016 [3]   PIN NO2
17 35050-00-017 [4]   PIN NO3
18 35050BAA-018 [3]   PLATE-SIDE
19 35050BAA-019 [3]   PLATE-SIDE
20 35050BAA-020 [14]   PLATE-SIDE
21 PKT505825E4 [3]   GAUGE-NEEDLE
22 PKT597132 [3]   GAUGE-NEEDLE
23 PBN506006 [4]   GAUGE-NEEDLE
24 35050BAA-024 [2]   RING-THRUST
25 63050-AA-285 [1]   RING-THRUST
26 63050-AA-289 [1]   RING-THRUST
27 3550800193 [1]   SHIM
29 OSBM20100 [20]   SCREW-HEX
30 OSBM1035 [20]   SCREW-HEX
31 PWBM1230M [12]   SCREW-HEX
32 OBP12 [3]   PLUG
33 35050BAA-033 [2]   BEARING-ANGULAR
34 P297 [1]   SEAL-FLOATING
35 35050-00-035 [1]   SHIM
36 OSPV625 [6]   PIN-SPRING
37 OSPV832 [4]   PIN-SPRING
41 OSSM1030 [2]   SCREW-SET
42 35050BAA-042 [1]   SHIM
44 OSR50 [3]   RING-SNAP
45 PWR110 [1]   CLIP
46 PWR130 [1]   CLIP
51 PNPA-2550A [1]   PLATE-NAME
52 OSK2548 [2]   PIN
S. 3550BX067-05 [1]   CARRIER 1 SUB ASSY(5,12,
S. 3550BX000-06 [1]   CARRIER 2 SUB ASSY(6,13,
S. 3550BX000-07A [1]   CARRIER 3 SUB ASSY(7,14,
N. @ [1]   NOT INDIVIDUALLY SUPPLIED
