HYUNDAI R200W R200W-2R210LC-3 R210LC-3H R210LC-3_LL excavator 31EM-10010 31EM-10100 hydraulic pump rotary group

HYUNDAI R200W R200W-2R210LC-3 R210LC-3H R210LC-3_LL excavator 31EM-10010 31EM-10100 hydraulic pump rotary group

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
31EM-10010 31EM-10100 R200W R200W-2R210LC-3 R210LC-3H R210LC-3_LL
Pos. Part No Qty Parts name Comments
1 31EM-10010 [1]   MAIN PUMP
2 11EM-12010 [1]   HOUSING
3 11EM-12020 [1]   COUPLING ASSY
3-1. 11E1-1507 [1]   ELEMENT
3-2. 11E1-1508 [1]   HUB
3-3. 11E1-1509 [4]   INSERT-A
3-4. 11E1-1510 [4]   INSERT-R
3-5. S107-160602 [8]   BOLT-SOCKET
3-6. 11E1-1511 [2]   BOLT-CLAMP
3-7. S472-500102 [12]   PIN-SPRING
4 S107-200504 [4]   BOLT-SOCKET
5 S017-100352 [8]   BOLT-HEX
6 S411-100002 [12]   WASHER-SPRING
9 S017-100402 [4]   BOLT-HEX
10 31EM-10100 [1]   MAIN PUMP      OPT
*. 31EM-10010 [1]   MAIN  PUMP      *-1∼*-4
*. 31EM-10100 [1]   MAIN PUMP-LOW EMISSION      *-1∼*-4
N*-1. K3V112DT-1RER [1]   MAIN  PUMP UNIT
111 2933800774 [1]   SHAFT-DRIVE(F)
113 2933800883 [1]   SHAFT-DRIVE(R)
114 2953801763 [1]   COUPLING-SPLINE
123 PNUP308K [2]   BEARING-ROLLER
124 PRNA6906 [2]   BEARING-NEEDLE
127 38800-127 [4]   SPACER-BEARING
N141. 2933800787 [2]   BLOCK-CYLINDER
151 @ [18]   PISTON
152 @ [18]   SHOE
153 2943800463 [2]   PLATE-SET
156 2953801765 [2]   BUSHING
157 2953801769 [18]   SPRING-CYLINDER
158 2953801764 [2]   SPACER
211 68710-00-211 [2]   PLATE-SHOE
N212. 2933800813 [2]   PLATE-SWASH
214 P1R2025125 [2]   BUSHING
251 2923800809 [2]   SUPPORT-SP
261 2943800464 [1]   COVER-FRONT
271 2923800807 [2]   CASING-PUMP
312 2923801021 [1]   BLOCK-VALVE
313 3890R-313N [1]   PLATE-VALVE-RH
314 3890L-314N [1]   PLATE-VALVE-LH
401 2953801767 [8]   SCREW
406 OSBM820 [4]   SCREW-HEX SOC HD
466 OVP14 [4]   PLUG
468 OVP34 [4]   PLUG
490 PBP116-2403 [18]   PLUG
N531. 2943800517 [2]   PIN-TILTING
532 2943800462 [2]   PISTON-SERVO
534 2953801761 [2]   STOPPER(L)
535 2953801762 [2]   STOPPER(S)
N541. 2953802029 [4]   SEAT
N543. 2953802030 [2]   STOPPER(1)
N544. 2953802043 [2]   STOPPER(2)
545 ODW732 [4]   BALL-STEEL
N548. 2953802202 [2]   PIN-FEED BACK
702 OORBG35 [2]    O-RING
710 OORBG95 [1]    O-RING
717 OORBG145 [4]   O-RING
724 OORBP8 [16]   O-RING
725 OORBP11 [4]   O-RING
728 OORBP24 [4]   O-RING
732 OORBP18 [2]   O-RING
774 PTCV40V [1]   SEAL-OIL
789 OT2BP18 [2]   RING-BACK UP
792 OT2BG35 [2]   RING-BACK UP
806 ORNM16 [2]   NUT
808 ORNM20 [2]   NUT
824 OSR40 [2]   RING-SNAP
885 PJR812 [2]   PIN-VALVE PLATE
886 OSPV614 [4]   PIN-SPRING
901 OEBM10 [2]   BOLT-EYE
953 PSSSM1630 [2]   SCREW-SET
954 2953801768 [2]   SCREW-SET
981 PNPA-2550A [1]   PLATE-NAME
983 OSK2548 [2]   PIN
*-2. 293G-9C39 [2]   REGULATOR ASSY
*-3. 2902440-0396A [1]   GEAR  PUMP ASSY
*-4. 2931100-0056 [1]   EPPR VLV CASING ASSY
11 3853802464 [2]   PISTON ASSY
13 2953801893 [1]   CYLINDER ASSY-RH
14 2953801894 [1]   CYLINDER ASSY-LH
30 2953801990 [2]   SWASH PLATE ASSY
41 2953802048 [2]   CHECK ASSY 1
42 2953802049 [2]   CHECK ASSY 2
530 2953801989 [2]   TILTING PIN ASSY
