HYUNDAI R180LC-9 EXCAVATOR SWING REDUCTION GEAR (TYPE 2)

HYUNDAI R180LC-9 EXCAVATOR SWING REDUCTION GEAR (TYPE 2)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING REDUCTION GEAR (TYPE 2):R180LC-9 SWING REDUCTION GEAR (TYPE 2)
Pos. Part No Qty Parts name Comments
N*. 38Q5-10150 [1]   SWING MOTOR ASSY      NOT USED
N*. 38Q5-10151 [1]   SWING MOTOR ASSY      SEE 4105
*-2. 39Q5-12100 [1]   SWING REDUCTION GEAR      NOT USED
*-2. 39Q5-12101 [1]   SWING REDUCTION GEAR
1 39Q5-12110 [1]   GEAR-RING
2 39Q6-12121 [1]   SHAFT-DRIVE
3 39Q6-12130 [1]   BEARING-TAPER.MAIN
4 39Q6-12140 [1]   BEARING-TAPER
5 39Q6-12150 [1]   NUT-RING
6 39Q6-12161 [1]   PLATE-LOCK
7 S017-120166 [4]   BOLT-HEX
8 39Q6-12171 [1]   CASING      NOT USED
8 39Q6-12172 [1]   CASING
9 S109-100306 [10]   BOLT-SOCKET
NK10. 39Q6-12190 [1]   CARRIER 2
NK11. 39Q6-12200 [3]   GEAR-PLANETARY 2
NK12. 39Q6-12210 [6]   BEARING-NEEDLE 2
NK13. 39Q6-12220 [6]   WASHER-THRUST 2
NK14. 39Q6-12230 [3]   PIN-CARRIER 2
NK15. S472-800364 [3]   PIN-SPRING
K16. 39Q6-12240 [1]   GEAR-SUN 2
NK17. 39Q6-12260 [1]   CARRIER 1
NK18. 39Q5-12270 [3]   GEAR-PLANETARY 1
NK19. 39Q5-12280 [3]   BEARING-NEEDLE 1
NK20. 39Q5-12290 [6]   WASHER-THRUST 1,UPP
NK21. 39Q5-12310 [3]   PIN-CARRIER 1
NK22. S472-600284 [3]   PIN-SPRING
K23. 39Q5-12320 [1]   GEAR-SUN 1
NK24. 39Q6-12330 [2]   PLATE-THRUST
25 39Q6-12340 [1]   SLEEVE
26 S632-120001 [1]   O-RING
27 39Q6-12350 [1]   SEAL-OIL
28 39Q6-41450 [2]   PIN-PARALLEL
29 S109-16045D [12]   BOLT-SOCKET
30 39Q5-12360 [1]   NAME PLATE      NOT USED
30 39Q5-12361 [1]   NAME PLATE
31 39Q6-41800 [2]   RIVET
32 P220-430204 [1]   PLUG-HEX
*-1. 38Q5-11100 [1]   SWING MOTOR UNIT      SEE 4115
K1. 39Q6-12180 [1]   CARRIER ASSY KIT 1      SEE ILLUST
K2. 39Q6-12250 [1]   CARRIER ASSY KIT 2      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
