HYUNDAI R180LC-9 EXCAVATOR SWING REDUCTION GEAR (TYPE 1)

HYUNDAI R180LC-9 EXCAVATOR SWING REDUCTION GEAR (TYPE 1)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING REDUCTION GEAR (TYPE 1):R180LC-9 SWING REDUCTION GEAR (TYPE 1)
Pos. Part No Qty Parts name Comments
N*. @ [1]   SWING MOTOR ASSY      SEE 4100
*-2. 31Q6-10140 [1]   SWING REDUCTION GEAR
*-2. 31Q6-10141 [1]   SWING REDUCTION GEAR
*-2. 31Q6-10141AR [1]   SWING REDUCTION GEAR
1 XKAQ-00771 [1]   CASING
1 XKAQ-00962 [1]   CASING
2 XKAQ-00403 [1]   SHAFT-DRIVE
2 XKAQ-00780 [1]   SHAFT-DRIVE
3 XKAQ-00018 [1]   SPACER
4 XKAQ-00026 [1]   BEARING-ROLLER
5 XKAQ-00032 [1]   SEAL-OIL
6 XKAQ-00029 [1]   BEARING-ROLLER
6 XKAQ-00647 [1]   BEARING-ROLLER
6 XKAQ-00961 [1]   BEARING-ROLLER
7 XKAQ-00404 [1]   PLATE-THRUST
8 XKAQ-00753 [1]   CARRIER ASSY 2      NOT SHOWN
9 XKAQ-00075 [1]   CARRIER 2
10 XKAQ-00023 [3]   GEAR-PLANET 2
11 XKAQ-00643 [3]   PIN ASSY 2      NOT SHOWN
12 XKAQ-00070 [3]   PIN 2      INCL 13
N13. XKAQ-00291 [1]   BUSHING 2
14 XKAQ-00071 [6]   WASHER-THRUST
15 XKAQ-00048 [3]   PIN-SPRING
16 XKAQ-00755 [1]   GEAR-SUN 2
17 XKAQ-00754 [1]   CARRIER ASSY 1      NOT SHOWN
18 XKAQ-00531 [1]   CARRIER 1
19 XKAQ-00025 [3]   GEAR-PLANET 1
20 XKAQ-00532 [3]   PIN 1
21 XKAQ-00030 [3]   CAGE-NEEDLE
22 XKAQ-00057 [3]   PLATE-SIDE 1
23 XKAQ-00040 [3]   PLATE-SIDE 2
24 XKAQ-00041 [3]   RING-STOP
25 XKAQ-00010 [1]   GEAR-SUN 1
26 XKAQ-00534 [1]   PLATE-SIDE 3
27 XKAQ-00529 [1]   GEAR-RING
27 XKAQ-00779 [1]   GEAR-RING
28 XKAQ-00977 [1]   GEAR-PINION
29 XKAQ-00074 [1]   RING-STOP
30 XKAQ-00072 [2]   PIN-KNOCK
31 XKAQ-00065 [12]   BOLT-SOCKET
32 XKAQ-00031 [1]   PLATE-COVER
33 XKAQ-00064 [8]   BOLT-HEX
34 XKAQ-00043 [1]   PLATE-LOCK
35 XKAQ-00042 [2]   BOLT-HEX
36 XKAQ-00292 [1]   WASHER-LOCK
37 XKAQ-00049 [1]   PLUG
38 XKAQ-00066 [2]   PLUG
*-1. @ [1]   SWING MOTOR UNIT      SEE 4100
N. @ [AR]   NOT SUPPLIED PARTS
