HYUNDAI R170W-9 R170W-9S R180W-9A R180W-9S EXCAVATOR 31Q5-12160 31Q5-12160AR 31Q5-21120 SWING MOTOR ROTARY GROUP

HYUNDAI R170W-9 R170W-9S R180W-9A R180W-9S EXCAVATOR 31Q5-12160 31Q5-12160AR 31Q5-21120 SWING MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
31Q5-12160 31Q5-12160AR 31Q5-21120
R170W-9 R170W-9S R180W-9A R180W-9S
Pos. Part No Qty Parts name Comments
N*. @ [1]   SWING MOTOR ASSY      *-1, *-2
*-1. 31Q5-12160 [1]   SWING MOTOR UNIT
*-1. 31Q5-12160AR [1]   SWING MOTOR UNIT
1 XKAY-01394 [1]   BODY
1 XKAY-02153 [1]   BODY
K2. XKAY-00521 [1]   SEAL-OIL
3 XKAY-00522 [1]   BEARING-ROLLER
4 XKAY-00523 [1]   RING-SNAP
5 XKAY-00524 [1]   SHAFT
6 XKAY-00525 [1]   BUSHING
7 XKAY-00526 [1]   RING-STOP
8 XKAY-00625 [1]   PIN
9 XKAY-00527 [1]   PLATE-SHOE
A. XKAY-00528 [1]   ROTARY KIT
A-A. XKAY-00529 [1]   CYLINDER BLOCK KIT
N10. XKAY-01511 [1]   BLOCK-CYLINDER
11 XKAY-00531 [9]   SPRING
24 XKAY-01512 [1]   PLATE-VALVE
A-B. XKAY-00532 [1]   RETAINER KIT
12 XKAY-00533 [1]   GUIDE-BALL
13 XKAY-00534 [1]   PLATE-SET
A-C. XKAY-00535 [1]   PISTON KIT
N14. XKAY-01513 [9]   PISTON ASSY
15 XKAY-00537 [3]   PLATE-FRICTION
16 XKAY-00538 [3]   PLATE
17 XKAY-00632 [1]   PISTON-BRAKE
K18. XKAY-00468 [1]   O-RING
K19. XKAY-00540 [2]   O-RING
20 XKAY-00541 [20]   SPRING
21 XKAY-01514 [1]   COVER-REAR
22 XKAY-00543 [1]   BEARING-NEEDLE
23 XKAY-00382 [2]   PIN
25 XKAY-00546 [4]   BOLT-WRENCH
26 XKAY-00309 [2]   PLUG
K27. XKAY-00141 [2]   RING-BACK UP
K28. XKAY-00310 [2]   O-RING
29 XKAY-00311 [2]   SPRING
30 XKAY-00312 [2]   CHECK
31 XKAY-01751 [2]   RELIEF VALVE ASSY
32 XKAY-00314 [2]   VLV ASSY-REACTIONLESS
33 XKAY-01470 [1]   VALVE ASSY-TIME DELAY
34 XKAY-00149 [3]   BOLT-WRENCH
35 XKAY-00150 [1]   PLUG
K36. XKAY-00151 [3]   O-RING
37 XKAY-00140 [1]   PLUG
38 XKAY-00975 [1]   PLUG
39 XKAY-00548 [1]   PLUG
40 XKAY-01515 [1]   NAME PLATE
41 XKAY-00277 [2]   RIVET
42 XKAY-01986 [1]   GAUGE-LEVEL
42-1. XKAY-01988 [1]   PLUG
43 XKAY-00322 [2]   PLUG
K44. XKAY-00324 [2]   O-RING
K45. XKAY-00247 [2]   O-RING
K46. XKAY-00605 [2]   RING-BACK UP
*-2. @ [1]   SWING REDUCTION GEAR      SEE 4110
K. XKAY-01401 [1]   SEAL KIT      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
