HYUNDAI R170W-7 R170W-7A R170W-9S R180W-9S WHEEL EXCAVATOR 31N5-43002 TRAVEL MOTOR PARTS

Name: HYUNDAI R170W-7 R170W-7A R170W-9S R180W-9S WHEEL EXCAVATOR 31N5-43002 TRAVEL MOTOR PARTS
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

HYUNDAI R170W-7 R170W-7A R170W-9S R180W-9S WHEEL EXCAVATOR 31N5-43002 TRAVEL MOTOR PARTS

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

31N5-43002 R170W-7 R170W-7A R170W-9S R180W-9S

Pos.	Part No	Qty	Parts name	Comments
*.	31N5-43002	[1]	TRAVEL MOTOR
1	XJDD-00889	[1]	ROTARY GROUP
1-1.	XJDD-00899	[1]	ROTARY-HYD SECTION
1-1-1.	XJDD-00914	[1]	CYLINDER
1-1-2.	XJDD-00915	[1]	CONTROL LENS
1-1-3.	XJDD-00916	[1]	PIN-CENTER
1-1-4.	XJDD-00917	[7]	PISTON ASSY
1-1-6.	XJDD-00920	[1]	SHIM(3.5T)-ADJUST
1-1-6.	XJDD-00921	[1]	SHIM(3.6T)-ADJUST
1-1-6.	XJDD-00922	[1]	SHIM(3.7T)-ADJUST
1-1-6.	XJDD-00923	[1]	SHIM(3.8T)-ADJUST
1-1-6.	XJDD-00924	[1]	SHIM(3.9T)-ADJUST
1-1-6.	XJDD-00925	[1]	SHIM(4.0T)-ADJUST
1-1-7.	XJDD-00926	[1]	SPRING-PRESSURE
1-1-11.	XJDD-00927	[1]	PLATE-RETAINING
1-1-12.	XJDD-00928	[14]	SCREW-PAN HEAD
1-2.	XJDD-00900	[1]	SHAFT-DRIVE
1-3.	XJDD-00901	[1]	SHIM
1-6.	XJDD-00902	[1]	PLATE(3.1T)-BACK UP
1-6.	XJDD-00903	[1]	PLATE(3.5T)-BACK UP
1-6.	XJDD-00904	[1]	PLATE(3.45T)-BACK UP
1-6.	XJDD-00905	[1]	PLATE(3.4T)-BACK UP
1-6.	XJDD-00906	[1]	PLATE(3.35T)-BACK UP
1-6.	XJDD-00907	[1]	PLATE(3.3T)-BACK UP
1-6.	XJDD-00908	[1]	PLATE(3.25T)-BACK UP
1-6.	XJDD-00909	[1]	PLATE(3.2T)-BACK UP
1-6.	XJDD-00910	[1]	PLATE(3.15T)-BACK UP
1-7.	XJDD-00911	[1]	RING-RETAINING
1-10.	XJDD-00912	[1]	BEARING-ROLLER
1-11.	XJDD-00913	[1]	BEARING-ROLLER
5	XJDD-00891	[1]	HOUSING
8	XJDD-00892	[1]	SCREW-LOCKING
9	XJDD-00893	[1]	RING-RETAINING
K10.	XJDD-00894	[1]	SEAL RING-SHAFT
11	XJDD-00895	[1]	PLATE-BACK UP
K12.	XJDD-00896	[1]	O-RING
13	XJDD-00892	[1]	SCREW-LOCKING
17	XJDD-00897	[2]	PIN-THREADED
K18.	XJDD-00898	[2]	NUT-SEAL LOCK
*-1.	@	[1]	CONTROL PART	SEE 4150
*-2.	@	[1]	COUNTER BALANCE VALVE	SEE 4160
K.	XJDD-00683	[1]	SEAL KIT	SEE ILLUST
Parts on group TRAVEL MOTOR(2/2):

Pos.	Part No	Qty	Parts name	Comments
*-1.	XJDD-01227	[1]	CONTROL
1	XJDD-01231	[1]	CONTROL PART
1-1.	XJDD-01236	[1]	HOUSING-CONTROL
1-2.	XJDD-01237	[1]	BUSHING-CONTROL
1-3.	XJDD-01238	[1]	PISTON-CONTROL
1-4.	XJDD-00947	[1]	BUSHING-ADJUSTING
1-5.	XJDD-00948	[1]	COLLAR-SPRING
1-7.	XJDD-00949	[1]	SPRING-PRESSURE
1-9.	XJDD-00950	[1]	SPRING-PRESSURE
K1-14.	XJDD-00951	[1]	O-RING
1-15.	XJDD-00864	[4]	SCREW-SOCKET HEAD
1-16.	XJDD-00952	[2]	SCREW-LOCKING
1-17.	XJDD-00953	[1]	RING-RETAINING
1-19.	XJDD-00954	[1]	PIN-THREADED
1-20.	XJDD-00955	[1]	PIN-CYLINDER
K1-21.	XJDD-00956	[1]	NUT-SEAL LOCK
1-22.	XJDD-00036	[2]	PIN-D/BREAK OFF
1-23.	XJDD-00054	[1]	PIN-D/BREAK OFF
1-29.	XJDD-00957	[1]	DISC-RETAINING
2	XJDD-01232	[1]	COVER
2-1.	XJDD-01239	[1]	COVER
2-2.	XJDD-01240	[1]	SCREW-THROTTLE
2-10.	XJDD-01241	[4]	SOCKET-HEAD SCREW
K2-11.	XJDD-00965	[1]	O-RING
2-12.	XJDD-00952	[1]	SCREW-LOCKING
3	XJDD-01233	[1]	PORT PLATE
4	XJDD-00932	[1]	PISTON-POSITIONING
5	XJDD-00933	[1]	TRUNNION
7	XJDD-00934	[1]	PISTON WITH PISTON RINGS
8	XJDD-00935	[1]	PIN-THREADED
15	XJDD-00938	[4]	SCREW-SOCKET HEAD
16	XJDD-00939	[4]	SCREW-SOCKET HEAD
K20.	XJDD-00875	[3]	O-RING
23	XJDD-00940	[1]	SCREW-SOCKET HEAD
26	XJDD-00941	[2]	PIN-CYLINDER
28	XJDD-00017	[2]	PLUG
29	XJDD-01234	[2]	PLUG
32	XJDD-00054	[1]	PIN-D/BREAK OFF
33	XJDD-00967	[1]	SCREW-LOCKING
34	XJDD-00942	[2]	SCREW-LOCKING
50	XJDD-00943	[2]	RELIEF VALVE
K.	XJDD-00683	[1]	SEAL KIT	SEE ILLUST
