HYUNDAI R170W-3 R180LC-3 R200NLC-3 R200W-3 R210LC-3 R210LC-3H R210LC-3_LL excavator 31EM-10030 MFB160-046 MFC160-010A swing motor rotary group and spare parts

HYUNDAI R170W-3 R180LC-3 R200NLC-3 R200W-3 R210LC-3 R210LC-3H R210LC-3_LL excavator 31EM-10030 MFB160-046 MFC160-010A swing motor rotary group and spare parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
31EM-10030 MFB160-046 MFC160-010A R170W-3 R180LC-3 R200NLC-3 R200W-3 R210LC-3 R210LC-3H R210LC-3_LL
Pos. Part No Qty Parts name Comments
*. 31EM-10030 [1]   SWING MOTOR
N*-1. MFB160-046 [1]   SWING MOTOR UNIT
*-1. MFC160-010A [1]   SWING MOTOR UNIT
1 1399-206 [1]   RACE-INNER
2 0722-142 [1]   SEAL-OIL
3 0671-133 [1]   BEARING-ROLLER
4 8320-003 [2]   PLUG
5 1390-164 [1]   SPRING-BACKING
6 1398-149 [1]   PLATE-CAM
7 1398-150 [1]   PLATE-RETURN
8 1321-122 [9]   PISTON ASSY
8 1321-222 [9]   PISTON ASSY
9 7598-032 [2]   PLATE-LINING
10 7598-031 [2]   PLATE
11 0200-152 [1]   O-RING
12 1320-130 [1]   PISTON
13 0200-153 [2]   O-RING
14 1390-166 [10]   SPRING
15 0522-143 [2]   PIN-PARALLEL
16 1320-153 [2]   PISTON
17 0824-051 [3]   CAP
18 8202-009 [3]   O-RING
19 1390-192 [4]   DISC-SPRING
20 0719-084 [4]   RING-TEFLON
21 1391-136 [4]   BUSHING
22 1313-185 [1]   PLATE-BALANCE
23 0682-135 [1]   BEARING-NEEDLE
24 0809-194 [1]   RING-SNAP
25 1318-168 [1]   CYLINDER ASSY
N26. 1311-185 [1]   HOUSING
N26. 1311-285 [1]   HOUSING
27 1399-205 [1]   COLLAR
27 1399-234 [1]   COLLAR
28 7589-012 [1]   GAUGE ASSY-LEVEL
28-1. 7589-008 [1]   GAUGE-LEVEL
28-2. 0201-011 [1]   O-RING
28-3. 7595-010 [1]   PIPE
29 0809-193 [1]   RING-SNAP
30 3537-252 [2]   BYPASS VALVE ASSY
31 8202-014 [2]   O-RING
32 0859-174 [2]   RING-BACK UP
33 8202-010 [2]   O-RING
34 1303-289 [1]   COVER
35 3537-194 [2]   RELIEF VALVE ASSY
36 8202-021 [4]   O-RING
37 8072-144 [4]   BOLT-SOCKET
38 3513-154 [2]   VALVE-CHECK
39 3590-288 [2]   SPRING
40 3526-327 [2]   CAP
40 3526-229 [2]   CAP
41 0859-229 [2]   RING-BACK UP
42 1329-111 [1]   VALVE-TIME DELAY
43 0576-054 [3]   BOLT-SOCKET
N*-2. RG08S-172-01 [1]   REDUCTION GEAR      SEE 2111
N. @ [AR]
