HYUNDAI R140LC-9S TRAVEL REDUCTION GEAR (TYPE 3 & 4)

HYUNDAI R140LC-9S TRAVEL REDUCTION GEAR (TYPE 3 & 4)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL REDUCTION GEAR (TYPE 3 & 4):R140LC-9S TRAVEL REDUCTION GEAR (TYPE 3 & 4)
Pos. Part No Qty Parts name Comments
*. 39Q4-40100 [1]   TRAVEL MOTOR ASSY      SEE 4174A
N*-2. 39Q4-42100 [1]   T/REDUCTION GEAR
N*-2. 39Q4-42101 [1]   T/REDUCTION GEAR
N*-2. 39Q4-42102 [1]   T/REDUCTION GEAR
59 39Q4-42110 [1]   GEAR-RING
60 39Q4-42120 [2]   BEARING-ANG.BALL
61 39Q4-42130 [2]   SEAL ASSY-FLOATING
62 39Q4-42140 [1]   RING-NUT
63 39Q4-42151 [1]   PLATE-LOCK
64 S017-100166 [9]   BOLT-HEX
65 39Q4-42170 [4]   PLATE-THRUST 2
66 39Q4-42180 [4]   GEAR-PLANETARY 2
67 39Q4-42190 [4]   BEARING-NEELDLE 2
68 39Q4-42200 [4]   RACE-INNER 2
69 39Q4-42210 [4]   WASHER-THRUST 2
70 39Q4-42220 [1]   GEAR-SUN 2
K71. 39Q4-42240 [1]   CARRIER 1
K72. 39Q4-42250 [3]   GEAR-PLANETARY 1
K73. 39Q4-42260 [3]   BEARING-NEEDLE 1
K74. 39Q4-42270 [3]   RACE-INNER 1
K75. 39Q4-42280 [1]   PLATE-THRUST 1
K76. S017-080166 [3]   BOLT-HEX
77 39Q4-42330 [1]   SCREW
78 39Q4-42290 [1]   GEAR-SUN 1
79 39Q4-42300 [1]   BALL-STEEL
80 39Q4-42310 [1]   COVER
81 S109-100256 [12]   BOLT-SOCKET
82 P220-110203 [3]   PLUG-HEX
K83. S631-014001 [3]   O-RING
N84. 39Q4-42320 [1]   NAME PLATE
85 39Q6-41800 [2]   RIVET
86 39Q4-42340 [3]   CAP-RUBBER
87 39Q4-42350 [12]   CAP-RUBBER
K. 39Q4-42230 [1]   CARRIER ASSY KIT 1      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
