HYUNDAI R140LC-9S TRAVEL REDUCTION GEAR (TYPE 2)

HYUNDAI R140LC-9S TRAVEL REDUCTION GEAR (TYPE 2)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL REDUCTION GEAR (TYPE 2):R140LC-9S TRAVEL REDUCTION GEAR (TYPE 2)
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR ASSY      SEE 4170
N*-2. XKAY-01869 [1]   TRAVEL REDUCTION GEAR
2 XKAY-01781 [2]   SEAL-FLOATING
3 XKAY-01780 [2]   BEARING-BALL
4 XKAY-01779 [1]   HOUSING
5 XKAY-01778 [1]   SHIM(1.4T)
5 XKAY-01777 [1]   SHIM(1.5T)
5 XKAY-01776 [1]   SHIM(1.6T)
6 XKAY-01775 [3]   SHIM(6.0T)
7 XKAY-01774 [1]   CARRIER 2 ASSY
7-1. XKAY-01773 [1]   CARRIER 2
7-2. XKAY-01772 [3]   PIN 2-SPRING
7-3. XKAY-01771 [3]   GEAR 2-PLANETARY
7-4. XKAY-01770 [6]   WASHER 2
7-5. XKAY-01769 [3]   BEARING 2
7-6. XKAY-01768 [3]   PIN 2
8 XKAY-01767 [1]   COUPLING
9 XKAY-01766 [1]   GEAR 2-SUN
10 XKAY-01765 [1]   CARRIER 1 ASSY
10-1. XKAY-01764 [1]   CARRIER 1
10-2. XKAY-01763 [3]   PIN 1-SPRING
10-3. XKAY-01762 [3]   GEAR 1-PLANETARY
10-4. XKAY-01761 [6]   WASHER 1
10-5. XKAY-01760 [3]   BEARING 1
10-6. XKAY-01759 [3]   PIN 1
11 XKAY-01758 [1]   GEAR 1-SUN
12 XKAY-01757 [1]   PLATE 1
13 XKAY-01756 [1]   COVER-END
14 XKAY-01755 [12]   BOLT
15 XKAY-01754 [1]   RING-SNAP
16 XKAY-01753 [3]   PLUG-PF
N. @ [AR]   NOT SUPPLIED PARTS
