HYUNDAI R140LC-9S SWING REDUCTION GEAR (TYPE 2)

HYUNDAI R140LC-9S SWING REDUCTION GEAR (TYPE 2)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING REDUCTION GEAR (TYPE 2):R140LC-9S SWING REDUCTION GEAR (TYPE 2)
Pos. Part No Qty Parts name Comments
*-2. 39Q4-12100 [1]   SWING REDUCTION GEAR      SEE 4105
*-2. 39Q4-12101 [1]   SWING REDUCTION GEAR      SEE 4105
1 39Q4-12110 [1]   GEAR-RING
2 39Q4-12120 [1]   SHAFT-DRIVE
3 39Q6-12140 [1]   BEARING-TAPER
4 39Q4-12130 [1]   BEARING-TAPER
5 39Q4-12140 [1]   RING-NUT
6 39Q4-12150 [1]   PLATE-LOCK
7 S017-080126 [4]   BOLT-HEX
8 39Q4-12160 [1]   CASING
9 S109-141306 [10]   BOLT-SOCKET
K10. 39Q4-12180 [1]   CARRIER 2
K11. 39Q4-12190 [3]   GEAR-PLANETARY 2
K12. 39Q6-42280 [3]   BEARING-NEEDLE 1
K13. 39Q4-12200 [6]   WASHER-THRUST 2
K14. 39Q4-12210 [3]   PIN-CARRIER 2
K15. S472-600364 [6]   PIN-SPRING
K16. 39Q4-12220 [1]   GEAR-SUN 2
K17. 39Q4-12240 [1]   CARRIER 1
K18. 39Q4-12250 [3]   GEAR-PLANETARY 1
K19. 39Q4-12260 [3]   BEARING-NEEDLE 1
K20. 39Q4-12270 [3]   WASHER-THRUST 1
K21. 39Q4-12280 [3]   PIN-CARRIER 1
K22. 39Q4-12290 [1]   GEAR-SUN 1
K23. S751-032004 [3]   RING-SNAP
K24. 39Q4-12300 [2]   PLATE-THRUST
25 39Q4-12310 [1]   SLEEVE
26 S632-095001 [1]   O-RING
27 39Q4-12320 [1]   SEAL-OIL
28 39Q4-12330 [1]   NAME PLATE
28 39Q4-12331 [1]   NAME PLATE
29 39Q6-41800 [2]   RIVET
30 P220-430204 [1]   PLUG-HEX
31 39Q4-12340 [1]   PIN-PARALLEL
K32. 39Q4-12350 [3]   WASHER-THRUST 1
K. 39Q4-12170 [1]   CARRIER ASSY KIT 2      SEE ILLUST
K. 39Q4-12230 [1]   CARRIER ASSY KIT 1      SEE ILLUST
