HYUNDAI R140LC-9S TRAVEL REDUCTION GEAR (TYPE 1)

HYUNDAI R140LC-9S TRAVEL REDUCTION GEAR (TYPE 1)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL REDUCTION GEAR (TYPE 1):R140LC-9S TRAVEL REDUCTION GEAR (TYPE 1)
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR ASSY      SEE 4140
*-4. XKAH-01458 [1]   TRAVEL REDUCTION GEAR
*-4. XKAH-01667 [1]   TRAVEL REDUCTION GEAR
101 XKAH-01203 [1]   SPINDLE
101 XKAH-01668 [1]   SPINDLE
K102. XKAH-01205 [2]   SEAL-FLOATING
103 XKAH-01210 [1]   RING-NUT
103 XKAH-01664 [1]   RING-NUT
104 XKAH-00818 [3]   PLUG-PT
105 XKAH-01204 [1]   HUB
105 XKAH-01669 [1]   HUB
106 XKAH-01209 [1]   RING-SNAP
108 XKAH-01212 [4]   GEAR(F)-PLANETARY
109 XKAH-01211 [8]   WASHER-THRUST
110 XKAH-01216 [4]   SCREW
111 XKAH-01213 [4]   BEARING-NEEDLE
112 XKAH-01214 [4]   COLLAR
113 XKAH-01215 [1]   PLATE(F)-THRUST
114 XKAH-01217 [1]   GEAR-SUN
115 XKAH-01218 [1]   RING-SNAP
116 XKAH-01219 [1]   HOLDER
116 XKAH-01665 [1]   HOLDER
117 XKAH-01220 [3]   GEAR(R)-PLANETARY
118 XKAH-01221 [3]   BEARING-NEEDLE
119 XKAH-01222 [3]   RACE-INNER
120 XKAH-00137 [3]   PIN-SPRING
120 XKAH-01666 [3]   BOLT-HEX
121 XKAH-01224 [1]   GEAR-DRIVE
122 XKAH-01223 [1]   PLATE(R)-THRUST
123 XKAH-01225 [1]   COVER
124 XKAH-01227 [12]   BOLT-SOCKET
125 XKAH-01208 [2]   BEARING-ANGULAR
K126. XKAH-01226 [1]   O-RING
K127. XKAH-01115 [1]   WASHER(M)-THRUST
128 XKAH-00058 [3]   PLUG
129 XKAH-01206 [1]   RING-SEAL
K130. XKAH-01207 [1]   O-RING
K131. XKAH-00326 [3]   O-RING
150 XKAH-00344 [1]   PLATE-THRUST
K. XKAH-01457 [1]   SEAT KIT      SEE ILLUST
