HYUNDAI R140LC-9S TRAVEL REDUCTION GEAR (HIGH WALKER)

HYUNDAI R140LC-9S TRAVEL REDUCTION GEAR (HIGH WALKER)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL REDUCTION GEAR (HIGH WALKER):R140LC-9S TRAVEL REDUCTION GEAR (HIGH WALKER)
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR ASSY      SEE 4175
*-2. 31Q6-40020 [1]   TRAVEL REDUCTION GEAR
*-2. 31Q6-40121 [1]   T/REDUCTION GEAR
1 XKAQ-00217 [1]   HOUSING
2 XKAQ-00218 [2]   BEARING-MAIN
2 XKAQ-00986 [2]   BEARING-MAIN
3 XKAQ-00219 [1]   SEAL-FLOATING
4 XKAQ-00220 [1]   SHIM
5 XKAQ-00221 [1]   RETAINER
6 XKAQ-00222 [12]   BOLT-HEX
7 XKAQ-00223 [2]   PIN-PARALLEL
8 XKAQ-00224 [1]   GEAR-RING
9 XKAQ-00225 [1]   COUPLING
10 XKAQ-00226 [1]   CARRIER 2 ASSY
10-1. XKAQ-00227 [1]   CARRIER 2
10-2. XKAQ-00228 [4]   GEAR-PLANET 2
10-3. XKAQ-00229 [8]   BEARING-NEEDLE 2
10-4. XKAQ-00230 [8]   WASHER-THRUST
10-5. XKAQ-00231 [4]   PIN 2
10-6. XKAQ-00232 [4]   PIN-SPRING
10-7. XKAQ-00208 [2]   RING-THRUST
11 XKAQ-00233 [1]   CARRIER ASSY 1
11-1. XKAQ-00234 [1]   CARRIER 1
11-2. XKAQ-00235 [1]   GEAR-SUN 2
11-3. XKAQ-00236 [1]   RING-RETAINING
11-4. XKAQ-00237 [3]   GEAR-PLANET 1
11-5. XKAQ-00238 [3]   BEARNG-NEEDLE 1
11-6. XKAQ-00239 [6]   WASHER-THRUST
11-7. XKAQ-00240 [3]   PIN 1
11-8. XKAQ-00241 [3]   PIN-SPRING
11-9. XKAQ-00655 [3]   PIN-SPRING
12 XKAQ-00242 [1]   GEAR-SUN 1
13 XKAQ-00243 [1]   COVER
14 XKAQ-00214 [1]   PAD
15 XKAQ-00244 [20]   BOLT-SOCKET
16 XKAQ-00245 [2]   SCREW-HEX SOCKET
17 XKAQ-00246 [3]   PLUG-HYDRAULIC
18 XKAQ-00247 [3]   O-RING
19 XKAQ-00248 [1]   NAME PLATE
19 XKAQ-00989 [1]   NAME PLATE
N. @ [AR]   NOT SUPPLIED PARTS
