HYUNDAI R140LC-9S SWING REDUCTION GEAR(TYPE 1)

HYUNDAI R140LC-9S SWING REDUCTION GEAR(TYPE 1)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group SWING REDUCTION GEAR(TYPE 1):R140LC-9S SWING REDUCTION GEAR(TYPE 1)
Pos. Part No Qty Parts name Comments
N*. @ [1]   SWING MOTOR ASSY      *-1,*-2
*-2. 31Q4-11141 [1]   SWING REDUCTION GEAR
*-2. 31Q4-11142 [1]   SWING REDUCTION GEAR
*-2. 31Q4-11142AR [1]   SWING REDUCTION GEAR
1 XKAQ-00511 [1]   CASING
2 XKAQ-00512 [1]   SHAFT-DRIVE
3 XKAQ-00513 [1]   PLATE-COVER
4 XKAQ-00514 [1]   SPACER
5 XKAQ-00515 [1]   BEARING-SPH ROLLER
6 XKAQ-00089 [1]   BEARING-CYL ROLLER
7 XKAQ-00087 [1]   SEAL-OIL
8 XKAQ-00809 [1]   CARRIER ASSY 2
9 XKAQ-00516 [1]   CARRIER 2
10 XKAQ-00810 [4]   GEAR-PLANET 2
11 XKAQ-00811 [4]   PIN ASSY 2
N12. XKAQ-00812 [1]   PIN 2
N13. XKAQ-00813 [1]   BUSHING 2
21 XKAQ-00093 [4]   WASHER-THRUST(B)
22 XKAQ-00086 [4]   PIN-SPRING
14 XKAQ-00519 [1]   GEAR-SUN 2
15 XKAQ-00814 [1]   CARRIER ASSY 1
16 XKAQ-00520 [1]   CARRIER 1
17 XKAQ-00815 [3]   GEAR-PLANET 1
18 XKAQ-00816 [3]   PIN ASSY 1
N19. XKAQ-00817 [1]   PIN 1
N20. XKAQ-00818 [1]   BUSHING 1
21 XKAQ-00093 [3]   WASHER-THRUST(B)
22 XKAQ-00086 [3]   PIN-SPRING
23 XKAQ-00085 [3]   RING-STOP
24 XKAQ-00523 [1]   GEAR-SUN 1
25 XKAQ-00084 [1]   RING-STOP
26 XKAQ-00524 [1]   PLATE-SIDE 1
27 XKAQ-00782 [1]   GEAR-RING
28 XKAQ-00091 [4]   PIN-KNOCK
29 XKAQ-00526 [9]   BOLT-HEX
30 XKAQ-00527 [10]   BOLT-SOCKET
31 XKAQ-00049 [1]   PLUG
32 XKAQ-00066 [2]   PLUG
*-1. @ [1]   SWING MOTOR UNIT      SEE 4100
N. @ [AR]   NOT SUPPLIED PARTS
