HYUNDAI R140LC-7 EXCAVATOR TRAVEL REDUCTION GEAR(TYPE 1, LCM-7)

HYUNDAI R140LC-7 EXCAVATOR TRAVEL REDUCTION GEAR(TYPE 1, LCM-7)

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL REDUCTION GEAR(TYPE 1, LCM-7):
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR ASSY      SEE 4175
*-7. XKAH-00901 [1]   REDUCTION GEAR ASSY      SEE 4174
*-7. XKAH-01627 [1]   REDUCTION GEAR ASSY      SEE 4174
*-71. XKAH-00902 [1]   HUB ASSY
*-71. XKAH-01670 [1]   HUB ASSY
N1. XKAH-00903 [1]   HUB
N1. XKAH-01671 [1]   HUB
4 XKAH-00904 [1]   RING GEAR(A)
4 XKAH-01672 [1]   RING GEAR(A)
27 XKAH-00431 [10]   PIN-PARALLEL
*-72. XKAH-00905 [1]   SPINDLE ASSY
N2. XKAH-00906 [1]   SPINDLE
8 XKAH-00907 [1]   COUPLING GEAR
35 XKAH-00428 [10]   BOLT-SOCKET
17 XKAH-00437 [10]   PIN
*-73. XKAH-00908 [1]   CARRIER ASSY
3 XKAH-00909 [1]   CARRIER
6 XKAH-00910 [3]   CLUSTER GEAR
6 XKAH-01673 [3]   CLUSTER GEAR
9 XKAH-00911 [3]   SHAFT
14 XKAH-00912 [6]   COLLAR-THRUST
25 XKAH-00913 [6]   BEARING-NEEDLE
5 XKAH-00914 [1]   RING GEAR(B)
7 XKAH-00445 [1]   GEAR-SUN
12 XKAH-00442 [1]   PIECE-DISTENCE
13 XKAH-00915 [1]   COVER
13 XKAH-01674 [1]   COVER
15 XKAH-00439 [1]   RING
19 XKAH-00022 [1]   COUPLING
20 XKAH-00436 [2]   PLATE-THRUST
23 XKAH-00435 [1]   SEAL-RING
24 XKAH-00434 [2]   BEARING-BALL
26 XKAH-00916 [2]   SEAL-FLOATING
26 XKAH-01675 [2]   SEAL-FLOATING
29 XKAH-00028 [1]   O-RING
30 XKAH-00338 [3]   PLUG-PT
30 XKAH-00032 [3]   PLUG-PF
32 XKAH-00430 [20]   BOLT-HEX
32 XKAH-01676 [20]   SOKET BOLT
33 XKAH-00336 [20]   WASHER-SPRING
34 XKAH-00429 [3]   PIN-PARALLEL
36 XKAH-00033 [1]   BALL-STEEL
38 XKAH-00035 [3]   O-RING
39 XKAH-00194 [2]   O-RING
40 XKAH-00427 [1]   O-RING
K. XKAH-01074 [1]   SEAL KIT      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
