HYUNDAI R140LC-7 EXCAVATOR TRAVEL REDUCTION GEAR(TYPE 1)

HYUNDAI R140LC-7 EXCAVATOR TRAVEL REDUCTION GEAR(TYPE 1)

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL REDUCTION GEAR(TYPE 1):
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR      *-1,*-2
*-1. XKAH-00367 [1]   REDUCTION GEAR ASSY
*-11. XKAH-00368 [1]   HUB ASSY
1 XKAH-00364 [1]   HUB
4 XKAH-00363 [1]   GEAR-RING(A)
*-12. XKAH-00369 [1]   SPINDLE KIT
*-12A. XKAH-00362 [1]   SPINDLE ASSY
N2. XKAH-00361 [1]   SPINDLE
N8. XKAH-00360 [1]   GEAR-COUPLING
17 XKAH-00334 [10]   PIN-PARALLEL
35 XKAH-00359 [10]   BOLT-SOCKET
*-13. XKAH-00358 [1]   CARRIER KIT
*-13A. XKAH-00357 [1]   CARRIER ASSY
3 XKAH-00356 [1]   CARRIER
6 XKAH-00355 [3]   GEAR-CLUSTER
9 XKAH-00354 [3]   SHAFT-CLUSTER
14 XKAH-00353 [6]   COLLAR-THRUST
25 XKAH-00352 [6]   BEARING-NEEDLE
34 XKAH-00351 [3]   PIN-PARALLEL
5 XKAH-00350 [1]   GEAR-RING(B)
7 XKAH-00349 [1]   GEAR-SUN
12 XKAH-00348 [1]   PIECE-DISTANCE
13 XKAH-00347 [1]   COVER
15 XKAH-00346 [1]   RING
19 XKAH-00345 [1]   COUPLING
20 XKAH-00344 [2]   PLATE-THRUST
23 XKAH-00343 [1]   RING-SEAL
*-14. XKAH-00342 [1]   FLOATING SEAL KIT
N31. XKAH-00341 [2]   SEAL-FLOATING
24 XKAH-00340 [2]   BEARING-A/BALL
27 XKAH-00339 [10]   PIN-PARALLEL
28 XKAH-00194 [2]   O-RING
29 XKAH-00028 [1]   O-RING
30 XKAH-00338 [3]   PLUG-PT
32 XKAH-00337 [20]   BOLT
33 XKAH-00336 [20]   WASHER-SPRING
36 XKAH-00033 [1]   BALL-STEEL
40 XKAH-00335 [1]   O-RING
42 XKAH-00034 [2]   PIN-PARALLEL
N*-2. XKAH-00333 [1]   CONTROL UNIT
N*-3. XKAH-00322 [1]   TRAVEL MOTOR UNIT
*-4. XKAH-00097 [1]   RELIEF VALVE KIT
K. XKAH-00366 [1]   SEAL KIT      SEE ILLUST
N. @ [1]   NOT SUPPLIED PARTS
