HYUNDAI R140LC-7 EXCAVATOR TRAVEL REDUCTION GEAR(#0239-#2712,LCM-7)

HYUNDAI R140LC-7 EXCAVATOR TRAVEL REDUCTION GEAR(#0239-#2712,LCM-7)

$50,000.00 USD
$50,000.00 USD
特價 售罄
結帳時計算運費。
Parts on group TRAVEL REDUCTION GEAR(#0239-#2712,LCM-7):
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR ASSY      *-1,*-2
*-2. XKAH-00474 [1]   T/REDUCTION GEAR
1 XKAH-00001 [1]   HUB
*-9. XKAH-00002 [1]   SPINDLE KIT
*-91. XKAH-00003 [1]   SPINDLE ASSY
N2. XKAH-00004 [1]   SPINDLE
N3. XKAH-00005 [1]   HOLDER-FLANGE
19 XKAH-00006 [3]   BOLT-SOCKET
34 XKAH-00007 [6]   PIN-PARALLEL
37 XKAH-00008 [3]   WASHER-PLAIN
*-10. XKAH-00371 [1]   RV GEAR ASSY
*-101. XKAH-00010 [1]   RV GEAR KIT
N4. XKAH-00475 [1]   RV GEAR(A)
N5. XKAH-00476 [1]   RV GEAR(B)
N9. XKAH-00477 [3]   SHAFT-CRANK
12 XKAH-00014 [6]   SPACER
22 XKAH-00015 [6]   BEARING-T/ROLLER
23 XKAH-00016 [6]   BEARING-NEEDLE
6 XKAH-00017 [1]   GEAR-INPUT
*-11. XKAH-00018 [1]   GEAR-SPUR KIT
7 XKAH-00019 [3]   GEAR-SPUR
8 XKAH-00480 [1]   COVER
13 XKAH-00021 [3]   PIECE-DISTANCE
15 XKAH-00022 [1]   COUPLING
17 XKAH-00023 [24]   PIN
20 XKAH-00024 [3]   RING-SNAP
21 XKAH-00025 [2]   BEARING-BALL
25 XKAH-00026 [3]   RING-SNAP
K27. XKAH-00027 [2]   O-RING
K29. XKAH-00028 [1]   O-RING
K30. XKAH-00029 [1]   O-RING
*-12. XKAH-00372 [1]   FLOATING SEAL KIT
KN31. XKAH-00031 [2]   SEAL-FLOATING
33 XKAH-00032 [3]   PLUG-RO
35 XKAH-00110 [12]   BOLT-SOCKET
36 XKAH-00033 [1]   BALL-STEEL
42 XKAH-00034 [2]   PIN-PARALLEL
K43. XKAH-00035 [3]   O-RING
*-1. @ [1]   TRAVEL MOTOR UNIT      SEE 4171-73
K. XKAH-00111 [1]   SEAL KIT      SEE ILLUST
