HYUNDAI R110-7 R110-7A R140LC-7 R140LC-7A R180LC-7 R180LC-7A EXCAVATOR 31N5-40060 31N5-40061 31N5-40061BG 31N5-40062BG TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

Name: HYUNDAI R110-7 R110-7A R140LC-7 R140LC-7A R180LC-7 R180LC-7A EXCAVATOR 31N5-40060 31N5-40061 31N5-40061BG 31N5-40062BG TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS
Brand: +8613035309093
Price: 2000.0 USD
Availability: InStock

HYUNDAI R110-7 R110-7A R140LC-7 R140LC-7A R180LC-7 R180LC-7A EXCAVATOR 31N5-40060 31N5-40061 31N5-40061BG 31N5-40062BG TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

31N5-40060 31N5-40061 31N5-40061BG 31N5-40062BG R110-7 R110-7A R140LC-7 R140LC-7A R180LC-7 R180LC-7A

Pos.	Part No	Qty	Parts name	Comments
*.	31N5-40060	[1]	TRAVEL MOTOR ASSY	SEE 4171
*.	31N5-40061	[1]	TRAVEL MOTOR ASSY
*.	31N5-40061BG	[1]	TRAVEL MOTOR ASSY
*.	31N5-40062BG	[1]	TRAVEL MOTOR ASSY
*-2.	XKAH-01067	[1]	REAR FLANGE ASSY
*-21.	XKAH-01075	[1]	REAR FLANGE ASSY
201	XKAH-01069	[1]	FLANGE-REAR
201	XKAH-00873	[1]	FLANGE-REAR
201	XKAH-01682	[1]	FLANGE-REAR
223	XKAH-00633	[1]	SPOOL-MAIN
*-3.	XKAH-00874	[2]	STOPPER ASSY
N294.	XKAH-00875	[1]	STOPPER-A
N298.	XKAH-00876	[1]	STOPPER-B
N295.	XKAH-01052	[1]	SPOOL
N296.	XKAH-01040	[1]	SPRING
224	XKAH-00328	[2]	PLUG
228	XKAH-00045	[2]	SPRING
279	XKAH-00047	[2]	O-RING
226	XKAH-00043	[2]	PLUG
227	XKAH-00879	[2]	VALVE-CHECK
230	XKAH-00046	[2]	SPRING
234	XKAH-00048	[2]	O-RING
221	XKAH-00032	[1]	PLUG-PF
238	XKAH-00035	[1]	O-RING
252	XKAH-00327	[4]	PLUG-PT
244	XKAH-00880	[1]	PLUG
268	XKAH-00056	[2]	BALL-STEEL
242	XKAH-00411	[1]	VALVE
272	XKAH-00462	[1]	SEAT-VALVE
276	XKAH-00382	[1]	RING
275	XKAH-00383	[1]	SPRING
218	XKAH-00881	[1]	SEAT-VALVE
219	XKAH-00392	[1]	VALVE
220	XKAH-00391	[1]	SPRING
222	XKAH-00390	[1]	RING(FOR T-TYPE)
233	XKAH-00389	[1]	O-RING
263	XKAH-00882	[1]	SPOOL-2SPEED
263	XKAH-01683	[1]	SPOOL-2SPEED
264	XKAH-00050	[1]	PLUG-RO
264	XKAH-00050	[5]	PLUG-RO
265	XKAH-00052	[3]	O-RING
266	XKAH-01068	[1]	SPRING-2 SPEED
267	XKAH-00884	[1]	SCREW-SET
241	XKAH-00065	[2]	PIN-PARALLEL
297	XKAH-00885	[1]	ORIFICE
282	XKAH-00066	[9]	BOLT-SOCKET
199	XKAH-01070	[1]	NAME PLATE
199	XKAH-01434	[1]	NAME PLATE
200	XKAH-00116	[2]	SCREW-RIVET
*-4.	XKAH-01065	[2]	RELIEF VALVE ASSY
*-4.	XKAH-01680	[2]	RELIEF VALVE ASSY
N301.	XKAH-00888	[1]	SEAT
N301.	XKAH-01066	[1]	SEAT
N302.	XKAH-00889	[1]	PLUNGER
N302.	XKAH-01064	[1]	PLUNGER
N303.	XKAH-00667	[1]	ROD
N303.	XKAH-01063	[1]	ROD
N304.	XKAH-00668	[1]	PISTON
N305.	XKAH-00670	[1]	BODY
N306.	XKAH-00666	[1]	PLUG
N306.	XKAH-01062	[1]	PLUG
307	XKAH-00890	[1]	SPRING
N307.	XKAH-00671	[1]	SPRING
N308.	XKAH-00669	[1]	SHIM
309	XKAH-00035	[1]	O-RING
310	XKAH-00035	[1]	O-RING
311	XKAH-00665	[1]	RING-BACK UP
K.	XKAH-01074	[1]	SEAL KIT	SEE ILLUST
N.	@	[AR]	NOT SUPPLIED PARTS
Parts on group TRAVEL MOTOR(#3713-, 2/2, TYPE 1, LCM-7):

Pos.	Part No	Qty	Parts name	Comments
*.	@	[1]	TRAVEL MOTOR ASSY	SEE 4171
N*-1.	XKAH-00870	[1]	TRAVEL ROTARY ASSY
*-5.	XKAH-00891	[1]	C/BLOCK & PISTON KIT
104	XKAH-00892	[1]	BLOCK-CYL
110	XKAH-00407	[2]	WASHER
114	XKAH-00406	[1]	SPRING
145	XKAH-00405	[1]	RING-SNAP
*-51.	XKAH-00893	[1]	PISTON ASSY
N105.	XKAH-00894	[9]	PISTON
N106.	XKAH-00419	[9]	SHOE
151	XKAH-00404	[6]	ROLLER
107	XKAH-00403	[1]	PLATE-RETAINER
108	XKAH-00402	[1]	BALL-THRUST
*-52.	XKAH-00895	[1]	PISTON ASSY
N161.	XKAH-00422	[1]	PISTON
N162.	XKAH-00421	[1]	SHOE
163	XKAH-00094	[1]	SPRING
102	XKAH-00410	[1]	SHAFT-MAIN
103	XKAH-00896	[1]	PLATE-SWASH
109	XKAH-00897	[1]	PLATE-TIMING
115	XKAH-00399	[3]	PLATE-FRICTION
116	XKAH-00401	[4]	PLATE-MATING
112	XKAH-00898	[1]	PISTON-PARKING
113	XKAH-00397	[9]	SPRING
132	XKAH-00388	[1]	OIL SEAL
149	XKAH-00899	[1]	SLEEVE ASSY
150	XKAH-00900	[1]	BEARING-BALL
139	XKAH-00396	[1]	O-RING
178	XKAH-00395	[1]	O-RING
181	XKAH-00377	[2]	PIN-PARALLEL
167	XKAH-00095	[2]	PIVOT
168	XKAH-00034	[2]	PIN-PARALLEL
K.	XKAH-01074	[1]	SEAL KIT	SEE ILLUST
N.	@	[AR]	NOT INDIVIDUALLY SUPPLIED
