HYUNDAI HX140L R140LC-9 R140LC-9A R140LC-9S R140LC-9S(BRAZIL) EXCAVATOR 31Q4-10010 HYDRAULIC MAIN PUMP ROTARY GROUP AND SPARE PARTS

HYUNDAI HX140L R140LC-9 R140LC-9A R140LC-9S R140LC-9S(BRAZIL) EXCAVATOR 31Q4-10010 HYDRAULIC MAIN PUMP ROTARY GROUP AND SPARE PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
31Q4-10010
HX140L R140LC-9 R140LC-9A R140LC-9S R140LC-9S(BRAZIL)
Pos. Part No Qty Parts name Comments
*. 31Q4-10010 [1]   MAIN PUMP      *-1, *-2, *-3
*-1. @ [1]   MAIN PUMP UNIT
111 XJBN-00802 [1]   SHAFT(F)-DRIVE
113 XJBN-00803 [1]   SHAFT(R)-DRIVE
116 XJBN-00804 [1]   GEAR-1ST
123 XJBN-00429 [2]   BEARING-ROLLER
124 XJBN-00805 [2]   BEARING-NEEDLE
127 XJBN-00806 [4]   SPACER-BEARING
NS141. XJBN-00807 [2]   BLOCK-CYLINDER
NS151. XJBN-00425 [18]   PISTON
NS152. XJBN-01278 [18]   SHOE
153 XJBN-00808 [2]   PLATE-SET
156 XJBN-00422 [2]   BUSHING-SPHERICAL
157 XJBN-00421 [18]   SPRING-CYLINDER
211 XJBN-00420 [2]   PLATE-SHOE
S212. XJBN-00419 [2]   PLATE-SWASH
S214. XJBN-00418 [2]   BUSHING-TILTING
251 XJBN-00417 [2]   SUPPORT
261 XJBN-00809 [1]   COVER-FR
271 XJBN-01046 [2]   CASING-PUMP
312 XJBN-00812 [1]   BLOCK-VALVE
NS313. XJBN-01045 [1]   PLATE(R)-VALVE
NS314. XJBN-01044 [1]   PLATE(L)-VALVE
326 XJBN-00937 [1]   COVER
401 XJBN-00411 [8]   SCREW
406 XJBN-00410 [8]   SCREW
414 XJBN-01371 [4]   SCREW
466 XJBN-00356 [2]   PLUG-VP
467 XJBN-00409 [4]   PLUG
468 XJBN-00237 [2]   PLUG
490 XJBN-00032 [15]   PLUG
S531. XJBN-00815 [2]   PIN-TILTING
532 XJBN-00407 [2]   PISTON-SERVO
534 XJBN-00816 [2]   STOPPER(L)
535 XJBN-00405 [2]   STOPPER(S)
NS548. XJBN-00360 [2]   PIN-FEED BACK
K702. XJBN-00888 [2]   O-RING
K710. XJBN-00387 [1]   O-RING
K711. XJBN-00878 [1]   O-RING
K717. XJBN-00401 [2]   O-RING
K719. XJBN-00400 [2]   O-RING
K724. XJBN-00044 [18]   O-RING
K725. XJBN-00045 [2]   O-RING
K727. XJBN-01357 [2]   O-RING
K728. XJBN-00097 [4]   O-RING
K732. XJBN-00820 [2]   O-RING
K774. XJBN-01029 [1]   SEAL-OIL
K789. XJBN-00398 [2]   RING-BACK UP
K792. XJBN-00397 [2]   RING-BACK UP
808 XJBN-00396 [4]   NUT-HEX
824 XJBN-00395 [2]   STOP RING
885 XJBN-00394 [2]   PIN-VALVE PLATE
886 XJBN-00365 [4]   PIN-SPRING
901 XJBN-00393 [2]   BOL-EYE
953 XJBN-00105 [2]   SCREW-SET
954 XJBN-00392 [2]   SCREW-SET
981 XJBN-00156 [1]   NAME PLATE
983 XJBN-00341 [2]   PIN
79 @ [2]   EPPR VALVE      SEE 4020
*-2. @ [2]   REGULATOR      SEE 4020
*-3. @ [1]   PUMP-GEAR      SEE 4030
11 XJBN-01572 [2]   PISTON SUB ASSY      SEE ILLUST
13 XJBN-01048 [1]   CYLINDER SUB ASSY-RH      SEE ILLUST
14 XJBN-01047 [1]   CYLINDER SUB ASSY-LH      SEE ILLUST
30 XJBN-00800 [2]   SWASH PLATE SUB ASSY      SEE ILLUST
530 XJBN-00801 [2]   TILTING PIN SUB ASSY      SEE ILLUST
K. XJBN-01780 [1]   SEAL KIT      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
Parts on group REGULATOR(TYPE 1, W/PTO):
Pos. Part No Qty Parts name Comments
*. @ [1]   MAIN PUMP      SEE 4010
*-2. XJBN-01586 [1]   REGULATOR ASSY      REAR
*-2. XJBN-01587 [1]   REGULATOR ASSY      FRONT
405 XJBN-00449 [4]   SCREW      REAR
412 XJBN-00448 [2]   SCREW
413 XJBN-00447 [2]   SCREW
436 XJBN-00446 [2]   SCREW
438 XJBN-00445 [6]   SCREW      REAR
438 XJBN-00445 [10]   SCREW      FRONT
466 XJBN-00356 [1]   PLUG      REAR
496 XJBN-00032 [6]   PLUG      REAR
496 XJBN-00032 [5]   PLUG      FRONT
601 XJBN-00317 [1]   CASING
611 XJBN-00824 [1]   LEVER
612 XJBN-00315 [1]   LEVER-1
613 XJBN-00314 [1]   LEVER-2
614 XJBN-00313 [1]   PLUG-CENTER
615 XJBN-00312 [1]   PLUG-ADJUST
621 XJBN-00580 [1]   PISTON
622 XJBN-00581 [1]   CASE-PISTON
N623. XJBN-01202 [1]   ROD-COMPENSATOR
N624. XJBN-01203 [1]   SEAT(C)-SPRING
625 XJBN-00307 [1]   SPRING-OUTER
N626. XJBN-00960 [1]   SPRING-INNER
627 XJBN-01024 [1]   STEM(C)-ADJUST
628 XJBN-01025 [1]   SCREW(C)-ADJUST
629 XJBN-00303 [1]   COVER(C)
630 XJBN-00302 [1]   LOCK NUT
631 XJBN-00301 [1]   SLEEVE
641 XJBN-00871 [1]   COVER-PILOT
N643. XJBN-01205 [1]   PISTON-PILOT
N644. XJBN-01206 [1]   SEAT(Q)-SPRING
N645. XJBN-00584 [1]   STEM(Q)-ADJUST
646 XJBN-00585 [1]   SPRING-PILOT
651 XJBN-00443 [1]   SLEEVE
652 XJBN-00291 [1]   SPOOL
653 XJBN-00290 [1]   SEAT-SPRING
654 XJBN-00289 [1]   SPRING-RETURN
655 XJBN-00288 [1]   SPRING-SET
656 XJBN-00287 [1]   COVER-BLOCK      FRONT
699 XJBN-00442 [1]   CASING      REAR
708 XJBN-00286 [1]   O-RING
722 XJBN-00285 [1]   O-RING      REAR
722 XJBN-00285 [3]   O-RING      FRONT
724 XJBN-00044 [9]   O-RING
725 XJBN-00231 [1]   O-RING
728 XJBN-00097 [1]   O-RING
730 XJBN-00230 [1]   O-RING
732 XJBN-00820 [1]   O-RING
733 XJBN-00282 [1]   O-RING
734 XJBN-00281 [1]   O-RING
735 XJBN-00280 [1]   O-RING
753 XJBN-01026 [1]   O-RING      FRONT
753 XJBN-01369 [1]   O-RING      REAR
754 XJBN-00441 [2]   O-RING      REAR
755 XJBN-00362 [3]   O-RING      REAR
755 XJBN-00362 [2]   O-RING      FRONT
756 XJBN-00279 [1]   O-RING
763 XJBN-00094 [1]   O-RING
801 XJBN-00440 [1]   NUT
802 XJBN-01027 [1]   NUT
814 XJBN-00439 [1]   RING-SNAP
836 XJBN-00276 [1]   RING-SNAP
858 XJBN-00438 [2]   RING-SNAP
874 XJBN-00344 [1]   PIN
875 XJBN-00273 [2]   PIN
876 XJBN-00794 [2]   PIN
887 XJBN-00272 [1]   PIN
897 XJBN-00795 [1]   PIN
898 XJBN-00270 [1]   PIN
924 XJBN-00269 [1]   SCREW-SET
79 XJBN-00382 [1]   EPPR VALVE
N. @ [AR]   NOT SUPPLIED PARTS
