HYUNDAI 38Q6-10150 38Q6-10151 38Q6-10152 38Q6-11100 38Q6-11101 39Q6-10150 39Q6-10151 39Q6-10152 39Q6-11100 39Q6-11101  swing motor rotary group and spare parts

HYUNDAI 38Q6-10150 38Q6-10151 38Q6-10152 38Q6-11100 38Q6-11101 39Q6-10150 39Q6-10151 39Q6-10152 39Q6-11100 39Q6-11101  swing motor rotary group and spare parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
38Q6-10150 38Q6-10151 38Q6-10152 38Q6-11100 38Q6-11101 39Q6-10150 39Q6-10151 39Q6-10152 39Q6-11100 39Q6-11101  ROTARY KIT 39Q6-11160   CYLINDER BLOCK KIT 39Q6-11170 RETAINER KIT 39Q6-11190 R210LC-9 R210NLC-9 R210W-9 R210W9-MH R210W-9S R220LC-9S R220LC-9SH R235LCR-9 R235LCR-9A R220LC-9S(BRAZIL)
Pos. Part No Qty Parts name Comments
*. 39Q6-10150 [1]   SWING MOTOR ASSY
*. 39Q6-10151 [1]   SWING MOTOR ASSY
*. 39Q6-10152 [1]   SWING MOTOR ASSY
*. 38Q6-10150 [1]   SWING MOTOR ASSY
*. 38Q6-10151 [1]   SWING MOTOR ASSY
*. 38Q6-10152 [1]   SWING MOTOR ASSY
*-1. 39Q6-11100 [1]   SWING MOTOR UNIT
N*-1. 39Q6-11101 [1]   SWING MOTOR UNIT
*-1. 38Q6-11100 [1]   SWING MOTOR UNIT
*-1. 38Q6-11101 [1]   SWING MOTOR UNIT
1 39Q6-11110 [1]   CASING
*-A. 39Q6-11160 [1]   ROTARY KIT
*-B. 39Q6-11170 [1]   CYLINDER BLOCK KIT      INCL 8, 9
N8. 39Q6-11180 [1]   BLOCK-CYLINDER
N9. 39Q6-41290 [9]   SPRING
*-C. 39Q6-11190 [1]   RETAINER KIT   INCL 10, 11
N10. 39Q6-11200 [1]   GUIDE-BALL
N11. 39Q6-11210 [1]   PLATE-RETAINER
N12. 39Q6-11220 [9]   PISTON ASSY
K2. 39Q6-11660 [1]   SEAL-OIL
3 39Q6-11120 [1]   SHAFT
4 S601-040004 [1]   RING-SNAP
5 39Q6-11130 [1]   BEARING-ROLLER
6 39Q6-11140 [1]   BEARING-NEEDLE
7 39Q6-11150 [1]   PLATE-SWASH
13 39Q6-41360 [4]   PLATE-FRICTION
13 39Q6-41361 [4]   PLATE-FRICTION
14 39Q6-41370 [4]   PLATE-SEPARATED
15 39Q6-11250 [1]   PISTON-PARKING
16 39Q6-11260 [26]   SPRING-BRAKE
17 S471-800454 [1]   PIN-SPRING
 K18. Y172-043004 [1]   O-RING
K19. Y172-041004 [1]   O-RING
20 39Q6-11270 [1]   PLATE-VALVE
21 S471-800254 [2]   PIN-SPRING
K22. Y172-042004 [1]   O-RING
23 39Q6-11280 [1]   CASING A-VALVE
23 39Q6-11281 [1]   CASING A-VALVE
24 39Q6-11290 [2]   VALVE-CHECK
25 39Q6-11300 [2]   SPRING-CHECK VALVE
26 39Q6-11670 [2]   PLUG
26 39Q6-11671 [2]   PLUG
K27. S631-038004 [2]   O-RING
28 39Q6-41750 [3]   PLUG
K29. S631-011004 [3]   O-RING
30 39Q6-11310 [2]   VALVE ASSY-RELIFE
30 39Q6-11311 [2]   VALVE ASSY-RELIFE
31 39Q6-11420 [2]   REACTIONLESS VLV ASSY
32 39Q6-11500 [2]   PLUG
K33. S631-012004 [2]   O-RING
K34. S631-018004 [2]   O-RING
35 39Q6-11510 [1]   VALVE ASSY-TIME DELAY
36 39Q6-11600 [1]   GAUGE-LEVEL
36 39Q6-11601 [1]   GAUGE-LEVEL
37 S109-180456 [2]   BOLT-SOCKET
38 S109-180556 [4]   BOLT-SOCKET
39 P220-430202 [1]   PLUG-HEX
40 39Q6-11650 [1]   NAME PLATE      TYPE 2
40 39Q6-11652 [1]   NAME PLATE      TYPE 2
40 39Q6-11653 [1]   NAME PLATE      TYPE 2
40 38Q6-11650 [1]   NAME PLATE      TYPE 3
40 38Q6-11652 [1]   NAME PLATE      TYPE 3
40 38Q6-11653 [1]   NAME PLATE      TYPE 3
41 39Q6-41800 [2]   RIVET
*-2. @ [1]   SWING REDUCTION GEAR      SEE 4116
K. 39Q6-11700 [1]   SEAL KIT
N. @ [AR]   NOT SUPPLIED PARTS
