HYUNDAI 38Q5-10150 38Q5-10151 38Q5-11100 31Q5-21130 SWING MOTOR ROTARY GROUP

HYUNDAI 38Q5-10150 38Q5-10151 38Q5-11100 31Q5-21130 SWING MOTOR ROTARY GROUP

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
38Q5-10150 38Q5-10151 38Q5-11100 31Q5-21130
R160LC-9 R160LC-9A R160LC-9S R160W-9A R170W-9 R180LC-9 R180LC-9A R180LC-9S R180W-9A R180W-9S
Pos. Part No Qty Parts name Comments
N*. 38Q5-10150 [1]   SWING MOTOR ASSY      *-1, *-2, TYPE 2
N*. 38Q5-10151 [1]   SWING MOTOR ASSY      *-1, *-2, TYPE 2
*-1. 38Q5-11100 [1]   SWING MOTOR UNIT      TYPE 2
1 39Q6-11110 [1]   CASING
*-A. 39Q6-11160 [1]   ROTARY KIT      INCL *-B, *-C, 12
*-B. 39Q6-11170 [1]   CYLINDER BLOCK KIT      INCL 8, 9
N8. 39Q6-11180 [1]   BLOCK-CYLINDER
N9. 39Q6-41290 [9]   SPRING
*-C. 39Q6-11190 [1]   RETAINER KIT      INCL 10, 11
N10. 39Q6-11200 [1]   GUIDE-BALL
N11. 39Q6-11210 [1]   PLATE-RETAINER
N12. 39Q6-11220 [9]   PISTON ASSY
NK2. 39Q6-11660 [1]   SEAL-OIL
3 39Q6-11120 [1]   SHAFT
4 S601-040004 [1]   RING-SNAP
5 39Q6-11130 [1]   BEARING-ROLLER
6 39Q6-11140 [1]   BEARING-NEEDLE
7 39Q6-11150 [1]   PLATE-SWASH
13 39Q6-41361 [4]   PLATE-FRICTION
14 39Q6-41370 [4]   PLATE-SEPARATED
15 39Q6-11250 [1]   PISTON-PARKING
16 39Q8-11180 [26]   SPRING
17 S471-800454 [1]   PIN-SPRING
NK18. Y172-043004 [1]   O-RING
NK19. Y172-041004 [1]   O-RING
20 39Q6-11270 [1]   PLATE-VALVE
21 S471-800254 [2]   PIN-SPRING
NK22. Y172-042004 [1]   O-RING
23 39Q6-11281 [1]   CASING A-VALVE
24 39Q6-11290 [2]   VALVE-CHECK
25 39Q6-11300 [2]   SPRING-CHECK VALVE
26 39Q6-11671 [2]   PLUG
NK27. S631-040004 [2]   O-RING
28 39Q6-41750 [3]   PLUG
NK29. S631-011004 [3]   O-RING
30 39Q5-11310 [2]   VALVE ASSY-RELIFE
31 39Q6-11420 [2]   REACTIONLESS VLV ASSY
32 39Q6-11500 [2]   PLUG
NK33. S631-012004 [2]   O-RING
NK34. S631-018004 [2]   O-RING
35 39Q6-11510 [1]   VALVE ASSY-TIME DELAY
36 39Q6-11601 [1]   GAUGE-LEVEL
37 S109-180456 [2]   BOLT-SOCKET
38 S109-180556 [4]   BOLT-SOCKET
39 P220-430202 [1]   PLUG-HEX
40 38Q6-11650 [1]   NAME PLATE
40 38Q6-11651 [1]   NAME PLATE
41 39Q6-41800 [2]   RIVET
*-2. 39Q5-12100 [1]   SWING REDUCTION GEAR      SEE 4115
*-2. 39Q5-12101 [1]   SWING REDUCTION GEAR      SEE 4115
K. 39Q6-11700 [1]   SEAL KIT      SEE ILLUST
K. 38Q5-11710 [1]   VALVE CASING KIT      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
