HYUNDAI 38Q4-10150 38Q4-10151 38Q4-11100 38Q4-11101 39Q4-10150 39Q4-10151 39Q4-11100 39Q4-11101 SWING MOTOR PARTS

HYUNDAI 38Q4-10150 38Q4-10151 38Q4-11100 38Q4-11101 39Q4-10150 39Q4-10151 39Q4-11100 39Q4-11101 SWING MOTOR PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
38Q4-10150 38Q4-10151
38Q4-11100 38Q4-11101
39Q4-10150 39Q4-10151
39Q4-11100 39Q4-11101
R125LCR-9A R140LC-9 R140LC-9(INDIA) R140LC-9A R140LC-9S R140LC-9S(BRAZIL) R140W-9 R140W-9A R140W-9S R145CR-9 R145CR-9A
Pos. Part No Qty Parts name Comments
*. 39Q4-10150 [1]   SWING MOTOR ASSY      *-1,*-2, TYPE 2
*. 39Q4-10151 [1]   SWING MOTOR ASSY      *-1,*-2, TYPE 2
*. 38Q4-10150 [1]   SWING MOTOR ASSY      *-1,*-2
*. 38Q4-10151 [1]   SWING MOTOR ASSY      *-1,*-2
*-1. 39Q4-11100 [1]   SWING MOTOR      TYPE 2
*-1. 39Q4-11101 [1]   SWING MOTOR      TYPE 2
*-1. 38Q4-11100 [1]   SWING MOTOR
*-1. 38Q4-11101 [1]   SWING MOTOR
1 39Q4-11110 [1]   CASING
2 39Q4-11120 [1]   SEAL-OIL
3 39Q4-11130 [1]   SHAFT
4 39Q4-11140 [1]   RING-SNAP
5 39Q4-11150 [1]   BEARING-ROLLER
6 39Q4-11160 [1]   BEARING-ROLLER
7 39Q4-11170 [1]   PLATE-SWASH
N8. 39Q4-11200 [1]   BLOCK-CYLINDER
N9. 39Q4-41230 [9]   SPRING-CYLINDER
N10. 39Q4-11220 [1]   GUIDE-BALL
N11. 39Q4-11230 [1]   PLATE-RETAINER
N12. 39Q4-11240 [9]   PISTON ASSY
13 39Q4-11270 [3]   PLATE-FRICTION
14 39Q4-11280 [3]   PLATE-SEPARATE
15 39Q4-11290 [1]   PISTON-PARKING
16 39Q4-11300 [24]   SPRING
17 S471-600364 [1]   PIN-SPRING
18 Y172-036004 [2]   O-RING
19 Y172-034004 [1]   O-RING
20 39Q4-11310 [1]   PLATE-VALVE
21 S471-600164 [2]   PIN-SPRING
22 39Q4-11320 [1]   VALVE CASING
23 39Q4-11330 [2]   VALVE-CHECK
24 39Q4-11340 [2]   SPRING
25 39Q4-11350 [2]   PLUG
26 31N8-19650 [2]   O-RING
27 39Q6-41750 [2]   PLUG
28 S631-011004 [2]   O-RING
29 39Q6-41780 [1]   PLUG
30 S631-008004 [1]   O-RING
31 39Q4-11360 [2]   RELIEF VALVE ASSY
32 39Q6-11420 [2]   REACTIONLESS VLV ASSY
33 39Q4-11520 [2]   PLUG
34 S631-012004 [2]   O-RING
35 S631-018004 [2]   O-RING
36 39Q4-11380 [1]   SPOOL
37 39Q4-11390 [1]   SEAT-SPRING
38 39Q4-11400 [1]   SPRING
39 39Q4-11410 [1]   RESTRICTOR
40 S631-020004 [1]   O-RING
41 39Q4-11421 [1]   LEVEL GAUGE ASSY
42 S109-140456 [4]   BOLT-SOCKET
43 P220-430202 [1]   PLUG-HEX
44 39Q4-11470 [2]   EXPANDER
45 39Q4-11480 [1]   EXPANDER
46 39Q4-11490 [1]   NAME PLATE      TYPE 2
46 39Q4-11491 [1]   NAME PLATE      TYPE 2
46 38Q4-11491 [1]   NAME PLATE
47 39Q6-41800 [2]   RIVET
*-2. @ [1]   SWING REDUCTION GEAR      SEE 4115
K. 39Q4-11600 [1]   ROTARY KIT      SEE ILLUST
K. 39Q4-11700 [1]   CYLINDER BLOCK KIT      SEE ILLUST
K. 39Q4-11800 [1]   RETAINER KIT      SEE ILLUST
K. 39Q4-11900 [1]   SEAL KIT      SEE ILLUST
K. 38Q4-11710 [1]   VALVE CASING KIT      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
