HYUNDAI 33HDLL R250LC-3 R290LC-3 R290LC-3H R290LC-3_LL/RB R290LC-7 EXCAVATOR 31E9-00030 33822J-02A 33822J-02B 33822J-02C 33822J-02D TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

HYUNDAI 33HDLL R250LC-3 R290LC-3 R290LC-3H R290LC-3_LL/RB R290LC-7 EXCAVATOR 31E9-00030 33822J-02A 33822J-02B 33822J-02C 33822J-02D TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
31E9-00030 33822J-02A 33822J-02B 33822J-02C 33822J-02D 33HDLL R250LC-3 R290LC-3 R290LC-3H R290LC-3_LL/RB R290LC-7
Pos. Part No Qty Parts name Comments
*. 31E9-00030 [1]   TRAVEL MOTOR
*-1. 33822J-02A [1]   TRAVEL MOTOR UNIT
*-1. 33822J-02B [1]   TRAVEL MOTOR UNIT
*-1. 33822J-02C [1]   TRAVEL MOTOR UNIT
*-1. 33822J-02D [1]   TRAVEL MOTOR UNIT
22 VZ03320-1494 [1]   SPOOL-COUNT,B
22 VZ03320-0258 [1]   SPOOL-COUNT,B
101 3324250-0299 [1]   SHAFT-DRIVE
102 PNUP2210 [1]   BEARING-ROLLER
103 PNK365528 [1]   BEARING-NEEDLE
107 OSR50 [1]   RING-SNAP
N111. 3324370-0204 [1]   CYLINDER
113 3724610-0025 [1]   BUSHING-SPHERICAL
114 2953802061 [9]   SPRING-CYLINDER
N121. 371A00AA-121 [9]   PISTON
N122. 3743700378 [9]   SHOE
123 3724110-0005 [1]   PLATE-SET
131 3724710-0021 [1]   PLATE-VALVE
161 OORBG30 [2]   O-RING
162 OT2BG30 [2]   RING-BACK UP
201 3324150-0075 [1]   PLATE-SWASH
272 3323190-0033 [1]   CASING-F
272 3323190-0047 [1]   CASING-K
N303. 3323230-0110 [1]   CASING-VALVE,B
350 V8911248179 [2]   VALVE-RELIEF
351 V9511178128 [1]   VALVE-REDUCING
352 VZ991-004 [1]   COVER
361 5A250010-3310 [2]   WASHER
362 3303340-1028 [2]   SPRING-COUNT,B
364 3350800150 [2]   COVER-C/BALANCE
K365. OORBG45 [2]   O-RING
366 OSBM1245 [8]   SCREW-HEX
401 OSBM20100 [2]   SCREW-HEX
402 OSBM2050 [4]   SCREW-HEX
435 ORR90 [1]   RING-SNAP
451 PJR1014 [2]   PIN-2
461 PBP116-2403 [13]   PLUG
464 OVP12 [2]   PLUG
K472. OORWG47 [1]   O-RING
K485. OORBP18 [2]   O-RING
K491. PTCV48V [1]   SEAL-OIL
N502. 3324530-0098 [1]   PISTON-TILTING
N503. 3324350-0011 [1]   SHOE-TILTING
504 3324760-0008 [2]   BALL
K509. OORBP16 [1]   O-RING
531 3303320-1257 [1]   SPOOL-TILTING
531 3303320-1552 [1]   SPOOL-TILTING
532 3303270-0212 [1]   SEAT-SPRING
533 3303340-1029 [1]   SPRING-TILTING,B
534 3303380-0127 [1]   SLEEVE
534 3303380-0178 [1]   SLEEVE
535 3324550-0036 [1]   PISTON
536 OSSSM45 [1]   SCREW-HEX
537 2953801710 [1]   WASHER
541 2933180-0007 [1]   SEAT-2
541 3333180-0125 [1]   SEAT-2
542 2933260-0018 [1]   STOPPER
543 ODW732 [1]   BALL-STEEL
545 OTRS116A15 [1]   ORIFICE
546 OTRS116A10 [1]   ORIFICE
K547. OORBP10 [2]   O-RING
564 OBP14 [2]   PLUG
567 OVP14 [4]   PLUG
K568. OORBP11 [4]   O-RING
569 OROH14 [2]   PLUG
K570. OORBP11 [2]   O-RING
571 OROMH22 [1]   PLUG
K572. OORBP20 [1]   O-RING
702 3324510-0016 [1]   PISTON-BRAKE
703 OTRM4406 [1]   ORIFICE
704 OTRM5510 [1]   ORIFICE
705 3753700453 [14]   SPRING-BRAKE
K707. OORWG44 [1]   O-RING
K708. OORWG49 [1]   O-RING
741 3743700413 [3]   PLATE
742 3743700449 [2]   PLATE
801 PNPA-2550A [1]   PLATE-NAME
802 OSK2548 [2]   PIN
N*-2 . 3550D-01A [1]   T/REDUCTION GEAR
K. 3302255-0135 [1]   SEAL KIT(365-708)
K. @ [1]   2
S. 3321210-0003 [1]   TILTING SPOOL SUB
S. 3321210-0006 [1]   TILTING SPOOL SUB
S. 3324530-0099 [1]   TILTING PISTON SUB
S. 3321130-0033 [1]   VALVE CASING SUB
S. 3321190-0072 [1]   CYLINDER SUB
S. 3324530-0121 [1]   PISTON SUB
N. @ [1]   NOT INDIVIDUALLY SUPPLIED
