HYUNDAI 31Q8-10131 31Q8-10131AR 31Q8-10152 31Q8-10152SG8 SWING MOTOR PARTS

HYUNDAI 31Q8-10131 31Q8-10131AR 31Q8-10152 31Q8-10152SG8 SWING MOTOR PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
31Q8-10131 31Q8-10131AR
31Q8-10152 31Q8-10152SG8
R290LC-9 R290LC-9MH R300LC-9A R300LC-9S R300LC-9SH
Pos. Part No Qty Parts name Comments
*. 31Q8-10152 [1]   SWING MOTOR ASSY
*. 31Q8-10152SG8 [1]   SWING UNIT
*-1. 31Q8-10131 [1]   SWING MOTOR UNIT
*-1. 31Q8-10131AR [1]   SWING MOTOR
101 XKAH-01660 [1]   CASING-V/V
102 XKAH-01659 [2]   PLUG
103 XKAH-01158 [2]   SPRING
104 XKAH-01159 [2]   PLUNGER S
105 XKAH-01658 [2]   O-RING
106 XKAH-01657 [1]   S/REACTIONLESS VALVE
107 XKAH-01656 [2]   RELIEF V/V
108 XKAH-01655 [1]   ROLLER BEARING
109 XKAH-01654 [4]   BOLT-SOCKET
110 XKAH-00136 [3]   PLUG-VP
111 XKAH-01653 [3]   O-RING
112 XKAH-01652 [1]   O-RING
113 XKAH-00137 [2]   PIN-SPRING
201 XKAH-01651 [1]   SHAFT-DRIVE
202 XKAH-01650 [1]   PLATE-SHOE
204 XKAH-01649 [9]   PISTON ASSY
205 XKAH-01648 [1]   BLOCK-CYLINDER
206 XKAH-01647 [1]   BUSHING-SPHERICAL
207 XKAH-01646 [1]   RETAINER PLATE
208 XKAH-01645 [1]   SPACER F
209 XKAH-01644 [12]   ROD-PUSH
210 XKAH-01643 [1]   SPACER R
211 XKAH-01642 [1]   SPRING
212 XKAH-00315 [1]   RING-SNAP
213 XKAH-01641 [1]   PLATE-VALVE
214 XKAH-01640 [1]   SPACER R
301 XKAH-01639 [1]   CASING
302 XKAH-01638 [1]   OIL SEAL
303 XKAH-01637 [1]   ROLLER BEARING
304 XKAH-00983 [3]   PLATE-SEPARATION
305 XKAH-00984 [2]   PLATE-FRICTION
306 XKAH-00133 [1]   O-RING
307 XKAH-00967 [1]   O-RING
308 XKAH-01636 [1]   PISTON-BRAKE
309 XKAH-00127 [20]   SPRING-BRAKE
310 XKAH-00503 [2]   PLUG
400 XKAH-01635 [1]   BRAKE V/V
401 XKAH-01634 [3]   BOLT-SOCKET
402 XKAH-01633 [1]   PLATE-NAME
403 XKAH-00116 [2]   SCREW-RIVET
404 XKAH-00120 [2]   PLUG
405 XKAH-00119 [1]   PLUG
406 XKAH-00118 [1]   PLUG
*-2. @ [1]   SWING REDUCTION GEAR      SEE 4115
N. @ [AR]   NOT SUPPLIED PARTS
