HYUNDAI 31Q5-42030 31Q5-42050 31Q5-42051 TRAVEL MOTOR PARTS

Name: HYUNDAI 31Q5-42030 31Q5-42050 31Q5-42051 TRAVEL MOTOR PARTS
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

HYUNDAI 31Q5-42030 31Q5-42050 31Q5-42051 TRAVEL MOTOR PARTS

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

31Q5-42030 31Q5-42050 31Q5-42051 HX140L HX160L HX180L R140LC-9 R140LC-9A R140LC-9S R160LC-9 R160LC-9A R160LC-9S R160LC-9S(BRAZIL) R180LC-9 R180LC-9A R180LC-9S

Pos.	Part No	Qty	Parts name	Comments
N*.	31Q5-42050	[1]	TRAVEL MOTOR ASSY	-1, -2
N*.	31Q5-42051	[1]	TRAVEL MOTOR ASSY	-1, -2
*-1.	31Q5-42030	[1]	TRAVEL MOTOR UNIT
*.	XKAY-02327	[1]	COVER ASSY-REAR	NEW
29	XKAY-00475	[1]	COVER-REAR	OLD
29	XKAY-02334	[1]	COVER-REAR	NEW
C.	XKAY-00476	[1]	SPOOL KIT	INCL 30-34
N30.	XKAY-00477	[1]	SPOOL
N31.	XKAY-00478	[2]	CHECK
N32.	XKAY-00479	[2]	SPRING
N33.	XKAY-00480	[2]	PLUG
K34.	XKAY-00481	[2]	O-RING
35	XKAY-00482	[2]	SEAT-SPRING
36	XKAY-00483	[2]	SPRING
37	XKAY-00484	[2]	COVER
38	XKAY-00485	[2]	SPRING
39	XKAY-00486	[2]	SPOOL
40	XKAY-00487	[2]	BALL-STEEL
41	XKAY-00488	[2]	SPRING
42	XKAY-00489	[2]	PLUG
43	XKAY-00490	[2]	SEAT-SPRING
K44.	XKAY-00825	[2]	O-RING
45	XKAY-00492	[8]	BOLT-WRENCH
46	XKAY-01407	[2]	RELIEF VALVE ASSY
K46-3.	XKAY-00670	[1]	O-RING
K46-8.	XKAY-00669	[1]	O-RING
46-9.	XKAY-00684	[2]	RING-BACK UP
K46-12.	XKAY-00671	[1]	O-RING
46-13.	XKAY-00687	[2]	RING-BACK UP
K46-16.	XKAY-00668	[1]	O-RING
47	XKAY-00494	[1]	SPOOL
48	XKAY-00826	[1]	GUIDE
K49.	XKAY-00827	[1]	O-RING
K50.	XKAY-00497	[1]	RING-BACK UP
K51.	XKAY-00828	[1]	O-RING
K52.	XKAY-00499	[1]	RING-BACK UP
53	XKAY-00500	[1]	RING-SNAP
54	XKAY-00501	[3]	PLUG
K55.	XKAY-00247	[4]	O-RING
56	XKAY-00502	[1]	SPRING
57	XKAY-00503	[1]	SEAT-SPRING
58	XKAY-00504	[1]	PLUG
59	XKAY-00505	[1]	SPOOL
60	XKAY-00506	[2]	ORIFICE
61	XKAY-00507	[2]	ORIFICE
62	XKAY-00508	[3]	PLUG
K63.	XKAY-00256	[3]	O-RING
64	XKAY-00032	[1]	PLUG
65	XKAY-00509	[4]	PIN
66	XKAY-00510	[1]	PIN
67	XKAY-00511	[8]	SPRING
68	XKAY-00512	[8]	SPRING
71	XKAY-00385	[16]	BOLT-WRENCH
72	XKAY-00515	[1]	PLUG
73	XKAY-01128	[1]	NAME PLATE
74	XKAY-00517	[2]	RIVET
76	XKAY-00519	[2]	ORIFICE
77	XKAY-01097	[AR]	SHIM
*-2.	@	[1]	REDUCTION GEAR ASSY	SEE 4177
K.	XKAY-00518	[1]	SEAL KIT	SEE ILLUST
N.	@	[AR]	NOT SUPPLIED PARTS
Parts on group TRAVEL MOTOR (2/2, HIGH WALKER):

Pos.	Part No	Qty	Parts name	Comments
*.	@	[1]	TRAVEL MOTOR ASSY	SEE 4175
*-1.	@	[1]	TRAVEL MOTOR UNIT
1	XKAY-00442	[1]	CASING-SHAFT
2	XKAY-00443	[10]	PLUG
K3.	XKAY-00444	[1]	SEAL-OIL
A.	XKAY-00445	[2]	SWASH PISTON KIT	INCL 4,5
N4.	XKAY-00446	[1]	PISTON-SWASH
N5.	XKAY-00447	[1]	RING-PISTON
6	XKAY-00448	[1]	SHAFT
7	XKAY-00449	[1]	BEARING
8	XKAY-00450	[2]	BALL-STEEL
9	XKAY-00451	[1]	PLATE-SWASH
B.	XKAY-01124	[1]	ROTARY KIT	INCL B-A,B,C
B-A.	XKAY-01125	[1]	BLOCK KIT-CYLINDER	INCL 10-15,70
N10.	XKAY-01126	[1]	BLOCK-CYLINDER
11	XKAY-00455	[1]	SEAT-SPRING
12	XKAY-00456	[1]	SPRING
13	XKAY-00457	[1]	PLATE-END
14	XKAY-00458	[1]	RING-SNAP
15	XKAY-00459	[3]	PIN
70	XKAY-01127	[1]	PLATE-VALVE
B-B.	XKAY-00460	[1]	RETAINER KIT
16	XKAY-00461	[1]	GUIDE-BALL
17	XKAY-00462	[1]	PLATE-SET
B-C.	XKAY-00463	[1]	PISTON KIT
N18.	XKAY-00464	[9]	PISTON ASSY
19	XKAY-00465	[3]	PLATE-FRICTION
20	XKAY-00466	[3]	PLATE
21	XKAY-00467	[1]	PISTON-PARKING
K22.	XKAY-00468	[1]	O-RING
K23.	XKAY-00469	[1]	RING-BACK UP
K24.	XKAY-00470	[1]	O-RING
K25.	XKAY-00471	[1]	RING-BACK UP
26	XKAY-00472	[1]	ORIFICE
K27.	XKAY-00473	[3]	O-RING
K28.	XKAY-00474	[1]	O-RING
69	XKAY-00513	[1]	BEARING
K.	@	[1]	SEAL KIT	SEE ILLUST,4175
N.	@	[AR]	NOT SUPPLIED PARTS
