HYUNDAI 31Q4-40030 31Q4-40031 XKAH-01182 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

Name: HYUNDAI 31Q4-40030 31Q4-40031 XKAH-01182 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS
Brand: +8613035309093
Price: 5000.0 USD
Availability: InStock

HYUNDAI 31Q4-40030 31Q4-40031 XKAH-01182 TRAVEL MOTOR ROTARY GROUP AND SPARE PARTS

$5,000.00 USD

特價售罄

結帳時計算運費。

產品子類

數量

31Q4-40030 31Q4-40031 XKAH-01182 R140LC-9 R140LC-9(INDIA) R140LC-9A R140LC-9S R140LC-9S(BRAZIL) R140LC-9V(INDIA) R145CR-9 R145CR-9A

Pos.	Part No	Qty	Parts name	Comments
*.	31Q4-40030	[1]	TRACK MOTOR ASSY	*-1, -2, -3, -4
*.	31Q4-40031	[1]	TRACK MOTOR ASSY	*-1, -2, -3, -4
N*-1.	XKAH-01182	[1]	TRAVEL MOTOR UNIT
M-1.	XKAH-01183	[1]	CYL BLOCK & PISTON KIT
NM-2.	XKAH-01184	[9]	PISTON ASSY
N5.	XKAH-01185	[1]	PISTON
N6.	XKAH-01186	[1]	SHOE
4	XKAH-01187	[1]	BLOCK-CYLINDER
N7.	XKAH-01188	[1]	PLATE-RETAINER
N8.	XKAH-01189	[1]	BALL-THRUST
N10.	XKAH-01190	[2]	WASHER
N11.	XKAH-01191	[1]	WASHER-COLLAR
N14.	XKAH-01192	[1]	SPRING
45	XKAH-01194	[1]	RING-SNAP
N51.	XKAH-01193	[5]	ROLLER
M-3.	XKAH-01195	[1]	PISTON ASSY-2 SPEED
N61.	XKAH-01196	[1]	PISTON
N62.	XKAH-01197	[1]	SHOE
60	XKAH-01198	[1]	SPRING
2	XKAH-01199	[1]	SHAFT-MAIN
3	XKAH-01200	[1]	PLATE-SWASH
9	XKAH-01201	[1]	PLATE-TIMING
12	XKAH-01456	[1]	PISTON-PARKING
13	XKAH-00733	[10]	SPRING
15	XKAH-01164	[3]	PALTE-FRICTION
16	XKAH-01165	[3]	PLATE-MATING
K32.	XKAH-00510	[1]	SEAL-OIL
K35.	XKAH-01166	[1]	O-RING
K39.	XKAH-01167	[1]	O-RING
42	XKAH-01172	[2]	PIN-PARALLEL
43	XKAH-01174	[8]	BOLT-SOCKET
K47.	XKAH-01236	[1]	RING-BACK UP
K48.	XKAH-01169	[1]	RING-BACK UP
49	XKAH-01170	[1]	BEARING-ROLLER
50	XKAH-01173	[1]	BEARING-BALL
67	XKAH-01171	[2]	PIVOT
K75.	XKAH-00262	[2]	O-RING
*-2.	@	[1]	CONTROL PART ASSY	SEE 4150
*-3.	@	[2]	VALVE KIT-RELIEF	SEE 4150
*-4.	@	[1]	REDUCTION GEAR ASSY	SEE 4160
K.	XKAH-01457	[1]	SEAT KIT	SEE ILLUST
N.	@	[AR]	NOT SUPPLIED PARTS
Parts on group TRAVEL MOTOR(2/2, TYPE 1):

Pos.	Part No	Qty	Parts name	Comments
*.	@	[1]	TRAVEL MOTOR ASSY	SEE 4140
N*-2.	XKAH-01228	[1]	CONTROL PART ASSY
*-20.	XKAH-01229	[1]	FLANGE ASSY-REAR
*-21.	XKAH-01230	[1]	FLANGE KIT-REAR
N1.	XKAH-01231	[1]	FLANGE-REAR
N23.	XKAH-01232	[1]	MAIN SPOOL-E TYPE
18	XKAH-00793	[1]	SEAT-VALVE
19	XKAH-00792	[1]	VALVE-T
20	XKAH-00791	[1]	SPRING
21	XKAH-00032	[1]	PLUG-RO
22	XKAH-00461	[1]	RING
24	XKAH-00789	[2]	PLUG-MAIN
25	XKAH-00788	[2]	RETAINER-SPRING
26	XKAH-01233	[2]	PLUG-CHECK
27	XKAH-01234	[2]	VALVE-CHECK
28	XKAH-00785	[2]	SPRING-MAIN
30	XKAH-00784	[2]	SPRING-CHECK
K33.	XKAH-00389	[1]	O-RING
K36.	XKAH-00035	[2]	O-RING
37	XKAH-00256	[2]	O-RING
K38.	XKAH-00035	[1]	O-RING
41	XKAH-01180	[1]	PIN-PARALLEL
42	XKAH-01172	[2]	PIN-PARALLEL
K46.	XKAH-00035	[2]	O-RING
52	XKAH-00050	[4]	PLUG-RO
54	XKAH-00208	[7]	PLUG-PT
63	XKAH-00032	[1]	PLUG-RO
65	XKAH-01235	[1]	SPOOL-TWO SPEED
66	XKAH-00055	[1]	SPRING
68	XKAH-00378	[2]	BALL-STEEL
69	XKAH-00884	[1]	SCREW-SET
71	XKAH-01179	[1]	ORIFICE
K74.	XKAH-00052	[4]	O-RING
N89.	XKAH-01181	[1]	NAME PLATE
90	XKAH-00116	[2]	SCREW-RIVET
91	XKAH-00880	[4]	PLUG
*-3.	XKAH-01175	[2]	RELIEF VALVE ASSY
46	XKAH-00035	[2]	O-RING
N202.	XKAH-01066	[1]	SEAT
N203.	XKAH-01176	[1]	PLUNGER
N204.	XKAH-00671	[1]	SPRING
N205.	XKAH-01177	[1]	BODY
N206.	XKAH-00669	[1]	SHIM
N207.	XKAH-00668	[1]	PISTON
N208.	XKAH-01178	[1]	ROD
N209.	XKAH-00666	[1]	PLUG
K210.	XKAH-00665	[1]	RING-BACK UP
K.	XKAH-01457	[1]	SEAT KIT	SEE ILLUST
N.	@	[AR]	NOT SUPPLIED PARTS
