HYUNDAI 31Q4-40030 31Q4-40031 XKAH-01182 TRAVEL MOTOR PARTS

HYUNDAI 31Q4-40030 31Q4-40031 XKAH-01182 TRAVEL MOTOR PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
31Q4-40030 31Q4-40031
XKAH-01182
R140LC-9 R140LC-9(INDIA) R140LC-9A R140LC-9S R140LC-9S(BRAZIL) R140LC-9V(INDIA) R145CR-9 R145CR-9A
Pos. Part No Qty Parts name Comments
*. 31Q4-40030 [1]   TRACK MOTOR ASSY      *-1, -2, -3, -4
*. 31Q4-40031 [1]   TRACK MOTOR ASSY      *-1, -2, -3, -4
N*-1. XKAH-01182 [1]   TRAVEL MOTOR UNIT
M-1. XKAH-01183 [1]   CYL BLOCK & PISTON KIT
NM-2. XKAH-01184 [9]   PISTON ASSY
N5. XKAH-01185 [1]   PISTON
N6. XKAH-01186 [1]   SHOE
4 XKAH-01187 [1]   BLOCK-CYLINDER
N7. XKAH-01188 [1]   PLATE-RETAINER
N8. XKAH-01189 [1]   BALL-THRUST
N10. XKAH-01190 [2]   WASHER
N11. XKAH-01191 [1]   WASHER-COLLAR
N14. XKAH-01192 [1]   SPRING
45 XKAH-01194 [1]   RING-SNAP
N51. XKAH-01193 [5]   ROLLER
M-3. XKAH-01195 [1]   PISTON ASSY-2 SPEED
N61. XKAH-01196 [1]   PISTON
N62. XKAH-01197 [1]   SHOE
60 XKAH-01198 [1]   SPRING
2 XKAH-01199 [1]   SHAFT-MAIN
3 XKAH-01200 [1]   PLATE-SWASH
9 XKAH-01201 [1]   PLATE-TIMING
12 XKAH-01456 [1]   PISTON-PARKING
13 XKAH-00733 [10]   SPRING
15 XKAH-01164 [3]   PALTE-FRICTION
16 XKAH-01165 [3]   PLATE-MATING
K32. XKAH-00510 [1]   SEAL-OIL
K35. XKAH-01166 [1]   O-RING
K39. XKAH-01167 [1]   O-RING
42 XKAH-01172 [2]   PIN-PARALLEL
43 XKAH-01174 [8]   BOLT-SOCKET
K47. XKAH-01236 [1]   RING-BACK UP
K48. XKAH-01169 [1]   RING-BACK UP
49 XKAH-01170 [1]   BEARING-ROLLER
50 XKAH-01173 [1]   BEARING-BALL
67 XKAH-01171 [2]   PIVOT
K75. XKAH-00262 [2]   O-RING
*-2. @ [1]   CONTROL PART ASSY      SEE 4150
*-3. @ [2]   VALVE KIT-RELIEF      SEE 4150
*-4. @ [1]   REDUCTION GEAR ASSY      SEE 4160
K. XKAH-01457 [1]   SEAT KIT      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
Parts on group TRAVEL MOTOR(2/2, TYPE 1):
Pos. Part No Qty Parts name Comments
*. @ [1]   TRAVEL MOTOR ASSY      SEE 4140
N*-2. XKAH-01228 [1]   CONTROL PART ASSY
*-20. XKAH-01229 [1]   FLANGE ASSY-REAR
*-21. XKAH-01230 [1]   FLANGE KIT-REAR
N1. XKAH-01231 [1]   FLANGE-REAR
N23. XKAH-01232 [1]   MAIN SPOOL-E TYPE
18 XKAH-00793 [1]   SEAT-VALVE
19 XKAH-00792 [1]   VALVE-T
20 XKAH-00791 [1]   SPRING
21 XKAH-00032 [1]   PLUG-RO
22 XKAH-00461 [1]   RING
24 XKAH-00789 [2]   PLUG-MAIN
25 XKAH-00788 [2]   RETAINER-SPRING
26 XKAH-01233 [2]   PLUG-CHECK
27 XKAH-01234 [2]   VALVE-CHECK
28 XKAH-00785 [2]   SPRING-MAIN
30 XKAH-00784 [2]   SPRING-CHECK
K33. XKAH-00389 [1]   O-RING
K36. XKAH-00035 [2]   O-RING
37 XKAH-00256 [2]   O-RING
K38. XKAH-00035 [1]   O-RING
41 XKAH-01180 [1]   PIN-PARALLEL
42 XKAH-01172 [2]   PIN-PARALLEL
K46. XKAH-00035 [2]   O-RING
52 XKAH-00050 [4]   PLUG-RO
54 XKAH-00208 [7]   PLUG-PT
63 XKAH-00032 [1]   PLUG-RO
65 XKAH-01235 [1]   SPOOL-TWO SPEED
66 XKAH-00055 [1]   SPRING
68 XKAH-00378 [2]   BALL-STEEL
69 XKAH-00884 [1]   SCREW-SET
71 XKAH-01179 [1]   ORIFICE
K74. XKAH-00052 [4]   O-RING
N89. XKAH-01181 [1]   NAME PLATE
90 XKAH-00116 [2]   SCREW-RIVET
91 XKAH-00880 [4]   PLUG
*-3. XKAH-01175 [2]   RELIEF VALVE ASSY
46 XKAH-00035 [2]   O-RING
N202. XKAH-01066 [1]   SEAT
N203. XKAH-01176 [1]   PLUNGER
N204. XKAH-00671 [1]   SPRING
N205. XKAH-01177 [1]   BODY
N206. XKAH-00669 [1]   SHIM
N207. XKAH-00668 [1]   PISTON
N208. XKAH-01178 [1]   ROD
N209. XKAH-00666 [1]   PLUG
K210. XKAH-00665 [1]   RING-BACK UP
K. XKAH-01457 [1]   SEAT KIT      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
