HYUNDAI 31Q4-11130 31Q4-11131 31Q4-11131AR SWING MOTOR PARTS

HYUNDAI 31Q4-11130 31Q4-11131 31Q4-11131AR SWING MOTOR PARTS

$5,000.00 USD
$5,000.00 USD
特價 售罄
結帳時計算運費。
31Q4-11130 31Q4-11131
31Q4-11131AR
R140LC-9 R125LCR-9A R140LC-9 R140LC-9(INDIA) R140LC-9A R140LC-9S R140LC-9S(BRAZIL) R140LC-9V(INDIA) R140W-9 R140W-9S R145CR-9 R145CR-9A
Pos. Part No Qty Parts name Comments
N*. @ [1]   SWING MOTOR ASSY      *-1,*-2
N*-1. 31Q4-11130 [1]   SWING MOTOR UNIT
*-1. 31Q4-11131 [1]   SWING MOTOR UNIT
*-1. 31Q4-11131AR [1]   SWING MOTOR
1 XKAY-01099 [1]   BODY
1 XKAY-02199 [1]   BODY
K2. XKAY-00281 [1]   SEAL-OIL
3 XKAY-00282 [1]   BEARING-ROLLER
4 XKAY-00283 [1]   RING-SNAP
5 XKAY-01100 [1]   SHAFT
6 XKAY-00285 [1]   BUSHING
7 XKAY-00625 [1]   PIN
8 XKAY-01101 [1]   PLATE-SHOE
9 XKAY-02003 [1]   ROTARY KIT
9 XKAY-02004 [1]   ROTARY KIT
9-1. JA7D9016A [1]   Deleted...
9-1. XKAY-02006 [1]   BLOCK KIT-CYLINDER
N9-11. JA7D9004A [1]   Deleted...
N9-11. XKAY-02008 [1]   BLOCK-CYLINDER
N9-12. XKAY-00291 [9]   SPRING
N9-12. XKAY-02010 [9]   SPRING
N23. XKAY-01114 [1]   PLATE-VALVE
N23. XKAY-02009 [1]   PLATE-VALVE
9-2. XKAY-01105 [1]   RETAINER KIT
N9-21. XKAY-01584 [1]   GUIDE-BALL
N9-22. XKAY-01106 [1]   PLATE-SET
9-3. XKAY-01107 [1]   PISTON KIT
N9-31. XKAY-01108 [9]   PISTON ASSY
14 XKAY-01109 [2]   PLATE-FRICTION
15 XKAY-01110 [2]   PLATE
16 XKAY-01111 [1]   PISTON-BRAKE
K17. XKAY-00301 [1]   O-RING
K18. XKAY-01112 [2]   O-RING
19 XKAY-01585 [16]   SPRING
20 XKAY-01113 [1]   COVER-REAR
20 XKAY-02011 [1]   COVER-REAR
21 XKAY-00304 [1]   BEARING-NEEDLE
22 XKAY-00562 [2]   PIN
23 XKAY-01114 [1]   PLATE-VALVE
23 XKAY-02009 [1]   PLATE-VALVE
24 XKAY-00308 [4]   BOLT-WRENCH
25 XKAY-02200 [2]   PLUG
K26. XKAY-00141 [2]   RING-BACK UP
K27. XKAY-00310 [2]   O-RING
28 XKAY-02201 [2]   SPRING
29 XKAY-02202 [2]   CHECK
30 XKAY-02001 [2]   RELIEF VALVE ASSY
31 XKAY-00314 [2]   VLV ASSY-REACTIONLESS
32 XKAY-01470 [1]   VALVE ASSY-TIME DELAY
33 XKAY-00692 [3]   BOLT-WRENCH
34 XKAY-00150 [3]   PLUG
K35. XKAY-00256 [3]   O-RING
36 XKAY-00140 [1]   PLUG
37 XKAY-00317 [1]   PLUG
38 XKAY-02012 [1]   LEVEL GAUGE ASSY
39 XKAY-01116 [1]   NAME PLATE
39 XKAY-02000 [1]   NAME PLATE
40 XKAY-00277 [2]   RIVET
41 XKAY-00322 [2]   PLUG
K42. XKAY-00324 [2]   O-RING
K43. XKAY-00247 [2]   O-RING
K44. XKAY-00605 [2]   RING-BACK UP
45 XKAY-00137 [1]   PLUG
46 XKAY-02203 [1]   LEVEL GAUGE KIT
47 XKAY-02194 [1]   BAR-LEVEL
48 XKAY-01985 [1]   PLUG
49 XKAY-02172 [1]   REAR COVER ASSY      SEE ILLUST
*-2. @ [1]   SWING REDUCTION GEAR      SEE 4110
K. XKAY-01117 [1]   SEAL KIT      SEE ILLUST
N. @ [AR]   NOT SUPPLIED PARTS
