HPV75 hydraulic pump parts

HPV75 hydraulic pump parts

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。

Komatsu PC60-6 PC60-7 PC60-8 PC78S-5 excavator

708-1W-00111 708-1W-00131 708-1W-01111 708-1W-01130 PC60-7 PC60-7-B PC70-7 PC70-7-B
Pos. Part No Qty Parts name Comments
     708-1W-00111   [1]   PUMP ASS'Y Komatsu 60.001 kg.
  ["SN: 52374-58000"] analogs:["7081W01111"] |$1.
        708-1W-01111   [1]   PUMP SUB ASS'Y Komatsu 60.001 kg.
  ["SN: 52374-58000"] analogs:["7081W00111"] |$3.
     708-1W-04180   [1]   CYLINDER BLOCK ASS'Y Komatsu 3.94 kg.
  ["SN: 52374-58000"] |$4.
3   720-68-19610   [1]   PIN Komatsu 0.002 kg.
  ["SN: 52374-58000"]
4   708-1W-23351   [1]   GUIDE,RETAINER Komatsu 1.2 kg.
  ["SN: 52374-58000"]
5   708-7L-13360   [3]   PIN Komatsu 0.003 kg.
  ["SN: 52374-58000"]
6   708-1W-23150   [1]   SPRING Komatsu 0.12 kg.
  ["SN: 52374-58000"]
7   708-1W-23130   [1]   SEAT Komatsu 0.016 kg.
  ["SN: 52374-58000"]
8   708-1W-23140   [1]   SEAT Komatsu 0.05 kg.
  ["SN: 52374-58000"]
9   04065-04218   [1]   RING,SNAP Komatsu 0.005 kg.
  ["SN: 52374-58000"]
10   708-1W-33340   [1]   RETAINER,SHOE Komatsu 0.22 kg.
  ["SN: 52374-58000"]
11   708-1W-33310   [9]   PISTON SUB ASS'Y Komatsu 1.26 kg.
  ["SN: 52374-58000"]
     708-1W-04160   [1]   CRADLE ASS'Y Komatsu China
  ["SN: 52374-58000"] |$16.
     708-1W-04150   [1]   CRADLE SUB ASS'Y Komatsu China
  ["SN: 52374-58000"] |$17.
15   04020-01024   [1]   PIN Komatsu 0.015 kg.
  ["SN: 52374-58000"] analogs:["PZF890001197"]
16   01010-81035   [8]   BOLT Komatsu 0.033 kg.
  ["SN: 52374-58000"] analogs:["801015556", "01010D1035", "0101051035"]
17   01643-31032   [8]   WASHER Komatsu 0.054 kg.
  ["SN: 52374-58000"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
18   07000-B2011   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 52374-58000"]
19   07000-02145   [1]   O-RING Komatsu China 0.03 kg.
  ["SN: 52374-58000"] analogs:["0700012145"]
     708-1W-00131   [1]   PUMP ASS'Y Komatsu 55 kg.
  ["SN: 58001-UP"] |$1.
        708-1W-01130   [1]   PUMP SUB ASS'Y Komatsu China
  ["SN: 58001-UP"] |$4.
     708-1W-04110   [1]   CASE ASS'Y Komatsu 30.2 kg.
  ["SN: 58001-UP"] |$5.
3   07044-12412   [1]   PLUG Komatsu 0.09 kg.
  ["SN: 58001-UP"] analogs:["0704402412", "R0704412412"]
4   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 58001-UP"] analogs:["7081W28910"]
5   04530-11018   [1]   BOLT,EYE Komatsu 0.079 kg.
  ["SN: 58001-UP"]
6   720-68-19870   [1]   PLUG Komatsu 0.03 kg.
  ["SN: 58001-UP"]
7   07002-61223   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 58001-UP"] analogs:["7082L23940"]
8   706-8E-14191   [1]   PLUG Komatsu China
  ["SN: 58001-UP"] analogs:["890001288"]
9   07002-11823   [1]   O-RING Komatsu 0.36 kg.
  ["SN: 58001-UP"] analogs:["0700201823"]
10   708-1W-22310   [1]   SHAFT Komatsu 1.79 kg.
  ["SN: 58001-UP"]
11   708-1W-22140   [1]   BEARING Komatsu 0.431 kg.
  ["SN: 58001-UP"]
12   708-23-05011   [1]   WASHER KIT Komatsu 0.05 kg.
  ["SN: 58001-UP"]
13   708-23-12840   [1]   RING,SNAP Komatsu China
  ["SN: 58001-UP"] analogs:["890001295"]
14   04065-07225   [1]   RING Komatsu 0.02 kg.
  ["SN: 58001-UP"]
15   708-1W-22320   [1]   BEARING Komatsu 0.25 kg.
  ["SN: 58001-UP"]
16   708-8D-12221   [1]   SEAL,OIL Komatsu 0.053 kg.
  ["SN: 58001-UP"] analogs:["7088D12220"]
17   708-1W-22160   [1]   SPACER Komatsu China
  ["SN: 58001-UP"] analogs:["890001298"]
18   04065-05520   [1]   RING Komatsu 0.01 kg.
  ["SN: 58001-UP"]
Pos. Part No Qty Parts name Comments
     708-1W-00111   [1]   PUMP ASS'Y Komatsu 60.001 kg.
  ["SN: 52374-58000"] analogs:["7081W01111"] |$1.
        708-1W-01111   [1]   PUMP SUB ASS'Y Komatsu 60.001 kg.
  ["SN: 52374-58000"] analogs:["7081W00111"] |$3.
1   708-1W-24150   [1]   PISTON,SERVO Komatsu China
  ["SN: 52374-58000"] analogs:["890001317"]
2   708-1W-24450   [1]   SLIDER Komatsu China
  ["SN: 52374-58000"] analogs:["890001318"]
3   708-1W-24250   [1]   BOLT,ADJUST Komatsu China
  ["SN: 52374-58000"] analogs:["890001319"]
4   07002-63334   [1]   O-RING Komatsu 1.46 kg.
  ["SN: 52374-58000"]
5   708-1W-24311   [1]   BOLT,ADJUST Komatsu China
  ["SN: 52374-58000"] analogs:["890001321"]
6   07002-62434   [1]   O-RING Komatsu 0.001 kg.
  ["SN: 52374-58000"] analogs:["7081W28910"]
7   708-1W-24350   [1]   SPRING Komatsu China
  ["SN: 52374-58000"] analogs:["890001322"]
8   708-1W-25840   [1]   LEVER Komatsu China
  ["SN: 52374-58000"] analogs:["890001324", "7081W26121"]
9   708-1W-26132   [1]   PIN Komatsu China
  ["SN: 52374-58000"] analogs:["890001325"]
10   708-1W-26113   [1]   COVER Komatsu China
  ["SN: 52374-58000"] analogs:["890001326"]
11   07000-03045   [1]   O-RING Komatsu China 0.002 kg.
  ["SN: 52374-58000"] analogs:["0700013045"]
12   01010-80830   [2]   BOLT Komatsu 0.017 kg.
  ["SN: 52374-58000"] analogs:["6735511120", "0101050830", "0737200830", "1240145H1"]
13   01643-30823   [2]   WASHER Komatsu 0.004 kg.
  ["SN: 52374-58000"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"]
14   708-1W-26210   [1]   PIN Komatsu China
  ["SN: 52374-58000"] analogs:["890001330"]
15   708-1W-26221   [1]   SLIDER Komatsu China
  ["SN: 52374-58000"] analogs:["890001331"]
16   708-1W-26230   [1]   WASHER Komatsu China
  ["SN: 52374-58000"] analogs:["890001332"]
17   01580-10605   [1]   NUT Komatsu 0.01 kg.
  ["SN: 52374-58000"] analogs:["21D0921430", "M018200600006", "801920103"]
  708-1W-04712   [1]   VALVE ASS'Y,LS Komatsu China
