KOMATSU HPV165 hydraulic pump piston shoe piston subassembly piston kit

KOMATSU HPV165 hydraulic pump piston shoe piston subassembly piston kit

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
HPV165 PC400-7 PC400-8 PC450-7 PC450-8
Pos. Part No Qty Parts name Comments
     708-2H-00450   [1]   Pump Assembly Komatsu 212 kg.
  ["SN: 70199-UP"] |$0.
        708-2H-01450   [1]   Pump Subassembly Komatsu China
  ["SN: 70199-UP"] |$1.
1   708-2H-32110   [1]   Shaft Komatsu 6.1 kg.
  ["SN: 70199-UP", "SCC: C2"]
2   708-1H-22150   [1]   Bearing Komatsu OEM 1.25 kg.
  ["SN: 70199-UP", "SCC: C2"] analogs:["7081H12151"]
3   708-17-05010   [1]   Washer Kit Komatsu 0.09 kg.
  ["SN: 70199-UP", "SCC: C2"] analogs:["7082700230"]
4   708-17-12780   [1]   Ring, Snap, Snap Komatsu 0.015 kg.
  ["SN: 70199-UP", "SCC: C2"]
5   708-2H-22570   [1]   Seal, Oil Komatsu 0.000 kg.
  ["SN: 70199-UP"]
5   708-27-22811   [1]   Seal, Oil Komatsu 0.101 kg.
  ["SN: 70199-70473"] analogs:["7082722810"]
6   708-2H-22160   [1]   Spacer Komatsu 0.06 kg.
  ["SN: 70199-UP"]
7   04065-08225   [1]   Ring, Snap Komatsu 0.024 kg.
  ["SN: 70199-UP"]
8-9   708-2H-04750   [1]   Cylinder Block Assembly Komatsu 8.352 kg.
  ["SN: 70199-UP", "SCC: C2"] analogs:["7082H04620"] |$13.
10   708-18-13230   [1]   Pin Komatsu 0.01 kg.
  ["SN: 70199-UP", "SCC: C2"]
11   04065-05820   [1]   Ring, Snap Komatsu 0.01 kg.
  ["SN: 70199-UP", "SCC: C2"]
12   708-2H-33140   [1]   Seat Komatsu 0.1 kg.
  ["SN: 70199-UP", "SCC: C2"]
13   708-2H-33150   [1]   Spring Komatsu 0.29 kg.
  ["SN: 70199-UP", "SCC: C2"]
14   708-2H-23141   [1]   Seat Komatsu 0.03 kg.
  ["SN: 70199-UP", "SCC: C2"]
15   708-2H-23350   [1]   Guide, Retainer, Retainer Komatsu 0.24 kg.
  ["SN: 70199-UP", "SCC: C2"] analogs:["R7082H23350"]
16   708-2H-23360   [3]   Pin Komatsu 0.006 kg.
  ["SN: 70199-UP", "SCC: C2"]
17   708-2H-33343   [1]   Retainer, Shoe, Shoe Komatsu 0.45 kg.
  ["SN: 70199-UP", "SCC: C2"]
18   708-2H-33311   [9]   Piston Subassembly Komatsu 0.36 kg.
  ["SN: 70199-UP", "SCC: C2"]
19-20   708-2H-04690   [1]   Cradle Subassembly Komatsu 8 kg.
  ["SN: 70199-UP"] |$25.
21   04020-01434   [1]   Pin, Dowel Komatsu 0.044 kg.
  ["SN: 70199-UP", "SCC: C2"]
22   07000-B1009   [1]   O-ring Komatsu China 0.001 kg.
  ["SN: 70199-UP", "SCC: C2"] analogs:["7082L23910"]
23   01252-61235   [6]   Bolt, Hexagon Socket Head Komatsu 0.048 kg.
  ["SN: 70199-UP", "SCC: C2"] analogs:["801105554", "0125231235"]
