HPV118 hydraulic pump parts for hiatchi ZX200-3

HPV118 hydraulic pump parts for hiatchi ZX200-3

$1,000.00 USD
$1,000.00 USD
特價 售罄
結帳時計算運費。
HPV118 ZX240-3 ZX250H-3 ZX250K-3 ZX250LC-3 ZX250LCN-3
Pos. Part No Qty Parts name Comments
+++++++ [1]   PUMP;UNIT
0 1032319 [1]   CASING;PUMP
2 2052079 [1]   DISC;DRIVING
5 2052080 [1]   DISC;DRIVING
9 4178173 [2]   NUT;BRG.
10 4338907 [1]   RING;THRUST
11 4410050 [2]   BRG.;ROL.
12 4333170 [2]   SEAL;OIL
13 4116290 [2]   RING;RETAINING
14 4339171 [2]   RING
15 4233165 [1]   PLUG
16 957366 [1]   O-RING
17 4622945 [2]   BRG.;ROL.
19 8050658 [14]   PISTON
21 4337035 [2]   SHAFT;CENTER
22 4198956 [2]   PIN
23 4179181 [2]   SPRING;COMPRES.
25 2052956 [2]   ROTOR
27 2052073 [1]   VALVE
28 2052067 [1]   VALVE
29 4179179 [4]   PIN
31 3104058 [2]   LINK
32 9724756 [4]   LEVER
33 4179177 [4]   PIN
34 4179176 [2]   PIN
35 4146370 [12]   RING;RETAINING
36 4200227 [2]   PIN
41 1032517 [1]   HEAD
42 3069541 [2]   PISTON;SERVO
43 4338053 [2]   PIN
44 4337812 [2]   SCREW;SET
46 4355085 [2]   O-RING
47 4338060 [2]   STOPPER
50 4355083 [2]   O-RING
51 4338061 [2]   STOPPER
54 4180349 [20]   O-RING
55 M340825 [16]   BOLT;SOCKET
57 3070581 [1]   RING;BACKUP
58 4099290 [2]   PIN;SPRING
59 4342840 [1]   O-RING
60 M341245 [12]   BOLT;SOCKET
65 4436271 [2]   SENSOR;PRES.
65A. 4365826 [1]   O-RING
67 9134110 [2]   PLUG
67A. 957366 [1]   O-RING
72 4515041 [4]   PIN;SPRING
73 4343074 [4]   O-RING
74 4348665 [2]   O-RING
79 4274552 [2]   RING;RETAINING
80 9134111 [2]   PLUG
80A. 4509180 [1]   O-RING
89 3100993 [1]   GEAR
90 3100994 [1]   GEAR
100 4451039 [1]   KIT;SEAL
