HITACHI HPV091EW hydraulic pump valve plate timing plate balance plate control plate control lens port plate

HITACHI HPV091EW hydraulic pump valve plate timing plate balance plate control plate control lens port plate

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
HPV091DS/DW/EW
9133006 9118971 EX200-3 EX200-3C EX200-3M EX200K-3 HPV091EW
Pos. Part No Qty Parts name Comments
+++++++ [1]   PUMP;UNIT 9118972A
1 1018750 [1]   CASING;PUMP
1 1022032 [1]   CASING;PUMP I 1018750
3 2034788 [1]   DISC;DRIVING
4 2034789 [1]   DISC;DRIVING
5 4175666 [2]   BRG.;ROL.
9 4178173 [2]   NUT;BRG.
10 4199307 [2]   BRG.;ROL.
11 4339171 [2]   RING
12 4232069 [2]   SEAL;OIL
13 4116290 [2]   RING;RETAINING
14 4338907 [1]   RING;THRUST
15 4310992 [2]   PLUG
16 957366 [2]   O-RING
18 9134111 [3]   PLUG
18A. 4509180 [1]   O-RING
19 8043698 [14]   PISTON
21 4233180 [2]   SHAFT;CENTER
22 4198956 [2]   PIN
23 4248499 [2]   SPRING;COMPRES.
24 2027277 [2]   ROTOR
27 +++++++ [1]   SENSOR;ANGLE 9128251A
30 4252767 [1]   BRACKET
31 M340613 [1]   BOLT;SOCKET
32 4169516 [1]   WASHER;SPRING
37 1020223 [1]   VALVE
39 1018752 [1]   HEAD P 1022034
39 1022034 [1]   HEAD
41 3055313 [1]   PISTON;SERVO
42 4272674 [1]   RING;PISTON
43 4260211 [1]   PIN
44 4179838 [1]   SCREW;SET
46 4317635 [1]   O-RING
47 4260500 [1]   STOPPER
48 4260493 [1]   STOPPER
50 4317637 [1]   O-RING
51 4311778 [1]   COVER
54 4317636 [1]   O-RING
55 M340820 [8]   BOLT;SOCKET
56 4514388 [8]   WASHER;SPRING
57 3066033 [1]   RING;BACK-UP
58 4099290 [2]   PIN;SPRING
60 M341245 [10]   BOLT;SOCKET
61 M341290 [2]   BOLT;SOCKET
62 4317619 [1]   O-RING
64 9134110 [1]   PLUG
64A. 957366 [1]   O-RING
68 4317636 [4]   O-RING
69 9120292 [2]   VALVE;SOLENOID
71 M340645 [4]   BOLT;SOCKET
72 A590106 [4]   WASHER;PLANE
73 4339754 [1]   SENSOR;PRES.
73A. 4150302 [1]   O-RING
75 4276559 [2]   CLAMP
76 M340613 [2]   BOLT;SOCKET
78 4169516 [2]   WASHER;SPRING
82 4252767 [1]   BRACKET
83 M340613 [1]   BOLT;SOCKET
84 4169516 [1]   WASHER;SPRING
