Hitachi HPV050 Hydraulic Main Pump Rotary group and Spare Parts for EX100-5 EX120-5 EX130-5

Hitachi HPV050 Hydraulic Main Pump Rotary group and Spare Parts for EX100-5 EX120-5 EX130-5

$1,000.00 USD
$1,000.00 USD
特價 售罄
結帳時計算運費。
HPV050 HPK050 EX120-5 9147342
EX100-5 EX100M-5 EX120-5 EX120-5HG EX120-5LV EX120-5X EX120-5Z EX120SS-5 EX130H-5 EX130K-5 EX135UR EX135UR-5  EX135US-5 EX135USR EX135USRK EX140US-5
Pos. Part No Qty Parts name Comments
+++++++ [1]   PUMP;UNIT 9147342A
1 1020513 [1]   CASING;PUMP
3 2036963 [1]   DISC;DRIVING
4 2036965 [1]   DISC;DRIVING
6 4339254 [2]   BRG.;ROL.
7 4348299 [2]   RING
8 4338325 [2]   BRG.;ROL.
9 4180790 [2]   NUT;BRG.
10 4331993 [1]   RING;THRUST
12 4340358 [2]   SEAL;OIL
13 4086775 [2]   RING;RETAINING
15 4233165 [2]   PLUG
16 957366 [2]   O-RING
18 9742464 [14]   PISTON
21 4339296 [2]   SHAFT;CENTER
22 4198956 [2]   PIN
23 4180786 [2]   SPRING;COMPRES.
25 2036958 [2]   ROTOR
27 2036441 [1]   VALVE
28 2037013 [1]   VALVE
29 4179179 [4]   PIN
31 3069960 [2]   LINK
32 9724756 [4]   LEVER
33 4179177 [4]   PIN
34 4179176 [2]   PIN
35 4146370 [12]   RING;RETAINING
36 4200227 [2]   PIN
37 4355872 [2]   LEVER
38 4358324 [2]   PLATE;LOCK
39 J900616 [4]   BOLT
41 1020401 [1]   HEAD
42 3068226 [2]   PISTON;SERVO
43 4330909 [2]   PIN
44 4179838 [2]   SCREW;SET
46 4355081 [2]   O-RING
47 4330951 [2]   STOPPER
50 4355080 [2]   O-RING
51 4330950 [2]   STOPPER
54 4180349 [20]   O-RING
55 M340825 [16]   BOLT;SOCKET
56 4514388 [16]   WASHER;SPRING
57 3071500 [1]   RING;BACK-UP
58 4099290 [2]   PIN;SPRING
59 4345061 [1]   O-RING
60 M341245 [10]   BOLT;SOCKET
61 M341290 [2]   BOLT;SOCKET
64 4355012 [2]   SENSOR;PRES.
64A. 4365826 [1]   O-RING
67 9134110 [2]   PLUG
67A. 957366 [1]   O-RING
69 -9149230 [2]   REGULATOR<for transportation> &lt;for transportation&gt;
69 9147341 [2]   REGULATOR I 9149230 9147341&lt;for assembly of machine&gt;
72 4515041 [4]   PIN;SPRING
73 4343074 [4]   O-RING
74 4348665 [2]   O-RING
82 4252767 [3]   BRACKET
83 M340613 [3]   BOLT;SOCKET
84 4169516 [3]   WASHER;SPRING

Model：HPV050
Part number：
Application：EX100-5 EX120-5 EX130-5
Brand：ITRITA
Material：Aluminum and Steel
Place of production：China
Delivey time：within 3 days
Payment：Western Union，T/T
Warranty（in China）：3 months
