KOMATSU LPD25-PI LPD28hydraulic pump piston shoe piston subassembly piston kit
KOMATSU LPD25-PI LPD28hydraulic pump piston shoe piston subassembly piston kit
定價
$200.00 USD
定價
售價
$200.00 USD
單價
/
每
結帳時計算運費。
No reviews
無法載入取貨服務供應情況
PC50MR-2 PC55MR-3 PC55/PC56 708-3S-14290 PC35MR-1 PC38UU-3 PC40MR-1 PC45MR-1 PC58UU-3 708-3S-00332 PC35MR-3 708-3s-00711 708-3S-00711 PC35MR-3 708-3S-00952 708-3S-01860 PC35MR-3 PC45MR-3 PC55MR-3 |
||||
Pos. | Part No | Qty | Parts name | Comments |
708-3S-00952 | [1] | Pump Assembly Komatsu China | ||
["SN: 17435-UP"] |$0. | ||||
708-3S-01860 | [1] | Pump Subassembly Komatsu China | ||
["SN: 17435-UP", "SCC: C2"] |$1. | ||||
1 | 708-3S-12121 | [1] | Shaft Komatsu China | |
["SN: 17435-UP", "SCC: C2"] | ||||
2 | 708-3S-12210 | [1] | Bearing Komatsu | 0.4 kg. |
["SN: 17435-UP", "SCC: C2"] | ||||
3 | 708-21-12840 | [1] | Ring, Snap Komatsu China | |
["SN: 17435-UP", "SCC: C2"] | ||||
4 | 708-3S-12140 | [1] | Holder Komatsu | 0.215 kg. |
["SN: 17435-UP"] | ||||
5 | 207-09-11140 | [1] | O-ring Komatsu | 0.002 kg. |
["SN: 17435-UP"] | ||||
6 | 708-3S-12150 | [1] | Seal, Oil Komatsu | 0.02 kg. |
["SN: 17435-UP"] | ||||
7 | 04065-06220 | [1] | Ring, Snap Komatsu | 0.013 kg. |
["SN: 17435-UP"] | ||||
8 | 708-3S-13530 | [1] | Cylinder Block Komatsu China | |
["SN: 17435-UP", "SCC: C2"] | ||||
9 | 708-3S-13490 | [1] | Plate, Valve Komatsu China | |
["SN: 17435-UP", "SCC: C2"] | ||||
10 | 708-3S-13160 | [2] | Washer Komatsu China | |
["SN: 17435-UP", "SCC: C2"] | ||||
11 | 708-3S-13430 | [1] | Spring Komatsu | 0.07 kg. |
["SN: 17435-UP", "SCC: C2"] | ||||
12 | 04065-03515 | [1] | Ring, Snap Komatsu | 0.003 kg. |
["SN: 17435-UP", "SCC: C2"] | ||||
13 | 708-1S-13370 | [1] | Guide, Retainer Komatsu | 0.045 kg. |
["SN: 17435-UP", "SCC: C2"] analogs:["7083S13370", "R7081S13370"] | ||||
14 | 708-1S-13380 | [3] | Pin Komatsu | 0.06 kg. |
["SN: 17435-UP", "SCC: C2"] | ||||
15 | 708-3S-13410 | [1] | Retainer, Shoe Komatsu | 0.24 kg. |
["SN: 17435-UP", "SCC: C2"] | ||||
16 | 708-3S-13520 | [10] | Piston Subassembly Komatsu | 0.08 kg. |
["SN: 17435-UP", "SCC: C2"] | ||||
17 | 708-3S-14290 | [1] | Piston Subassembly Komatsu | 0.087 kg. |
["SN: 17435-UP", "SCC: C2"] analogs:["7081S14230", "7083S14250"] | ||||
18 | 708-1S-14241 | [1] | Spring Komatsu | 0.01 kg. |
["SN: 17435-UP", "SCC: C2"] | ||||
Pos. | Part No | Qty | Parts name | Comments |
708-3S-00952 | [1] | Pump Assembly Komatsu China | ||
["SN: 17435-UP"] |$0. | ||||
1. | 708-2L-25480 | [6] | Filter Komatsu OEM | 0.5 kg. |
["SN: 17435-UP"] | ||||
2. | 708-2L-25490 | [6] | O-ring Komatsu | 0.001 kg. |
["SN: 17435-UP"] | ||||
3. | 708-1S-19710 | [1] | Orifice Komatsu | 0.002 kg. |
["SN: 17435-UP"] | ||||
4. | 01252-60640 | [4] | Bolt, Hexagon Socket Head Komatsu | 0.012 kg. |
["SN: 17435-UP", "SCC: C2"] | ||||
5. | 07000-13040 | [1] | O-ring Komatsu China | 0.002 kg. |
["SN: 17435-UP", "SCC: C2"] analogs:["0700003040", "0700003040E", "YM24311000400"] | ||||
6. | 04020-00616 | [2] | Pin, Dowel Komatsu | 0.004 kg. |
["SN: 17435-UP", "SCC: C2"] | ||||
7. | 07000-11008 | [1] | O-ring Komatsu China | 0.01 kg. |
["SN: 17435-UP", "SCC: C2"] analogs:["0700001008", "2016018950"] | ||||
8. | 708-3S-04573 | [1] | Pump Assembly Komatsu | 4.8 kg. |
["SN: 17435-UP"] analogs:["7083S04571", "7083S04541", "7083S04570", "7083S04572"] | ||||
9. | 708-1T-19210 | [1] | Coupling Komatsu China | |
["SN: 17435-UP"] analogs:["890001673"] | ||||
10. | 700-30-63140 | [1] | Ring, Snap Komatsu China | |
["SN: 17435-UP"] analogs:["890001674"] | ||||
11. | 708-1T-19230 | [1] | Ring Komatsu China | |
["SN: 17435-UP"] analogs:["890001675", "7081T19220"] | ||||
12. | 07000-12014 | [1] | O-ring Komatsu China | 0.01 kg. |
["SN: 17435-UP"] analogs:["0700002014"] | ||||
13. | 07000-12070 | [1] | O-ring Komatsu China | 0.03 kg. |
["SN: 17435-UP"] analogs:["0700002070"] | ||||
14. | 01010-80830 | [4] | Bolt Komatsu | 0.017 kg. |
["SN: 17435-UP"] analogs:["6735511120", "0101050830", "0737200830", "1240145H1"] | ||||
15. | 01643-30823 | [4] | Washer Komatsu | 0.004 kg. |
["SN: 17435-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"] | ||||
17. | 708-3S-19150 | [1] | Orifice Komatsu China | |
["SN: 17435-UP", "SCC: C2"] | ||||
18. | 708-3S-15810 | [2] | Plug Komatsu China | |
["SN: 17435-UP"] | ||||
19. | 708-3S-15820 | [2] | Nut Komatsu China | |
["SN: 17435-UP"] | ||||
20. | 07000-11003 | [2] | O-ring Komatsu | 0.001 kg. |
["SN: 17435-UP"] analogs:["0700001003"] | ||||
21. | 07001-01003 | [2] | Ring, Back-up Komatsu | 0.001 kg. |
["SN: 17435-UP"] | ||||
22. | 20B-27-11210 | [1] | Bleeder Komatsu | 0.02 kg. |
["SN: 17435-UP"] | ||||
23. | 04530-10815 | [1] | Bolt, Eye Komatsu | 0.05 kg. |
["SN: 17435-UP"] |
