HITACHI ZX850-3 ZX850-3F ZX850LC-3-DH ZX870H-3 ZX870H-3F ZX870H-3-HCMC ZX870R-3 ZX870R-3F EXCAVATOR 4635787 HYDRAULIC PISTON PUMP ROTARY GROUP AND SPARE PARTS

HITACHI ZX850-3 ZX850-3F ZX850LC-3-DH ZX870H-3 ZX870H-3F ZX870H-3-HCMC ZX870R-3 ZX870R-3F EXCAVATOR 4635787 HYDRAULIC PISTON PUMP ROTARY GROUP AND SPARE PARTS

$2,000.00 USD
$2,000.00 USD
特價 售罄
結帳時計算運費。
4635787
ZX850-3 ZX850-3F ZX850LC-3-DH ZX870H-3 ZX870H-3F ZX870H-3-HCMC ZX870R-3 ZX870R-3F
Pos. Part No Qty Parts name Comments
4635787 [1]   PUMP;UNIT
01 4661756 [1]   REGULATOR;PUMP
011 0928006 [1]   PISTON ASS'Y
011A. +++++++ [9]   PISTON
011B. +++++++ [9]   SHOE
013 0978701 [1]   CYL. ASS'Y
013A. +++++++ [1]   BLOCK;CYL.
013B. +++++++ [1]   PLATE;VALVE
030 0818503 [1]   PLATE ASS'Y
030A. +++++++ [1]   PLATE
030B. +++++++ [1]   BUSHING
111 0983101 [1]   SHAFT
123 0878107 [1]   BRG.;ROL.
124 0878108 [1]   BRG.;NEEDLE
127 0818508 [2]   SPACER
153 0878109 [1]   PLATE
156 0818510 [1]   BUSHING;SPH.
157 0818511 [9]   SPRING
211 0818512 [1]   PLATE
251 0818513 [1]   SUPPORT
261 0878111 [1]   COVER;SEAL (F)
271 0978702 [1]   CASING;PUMP
312 0928002 [1]   COVER
401 0818519 [4]   BOLT;SOCKET
406 0237902 [4]   BOLT;SOCKET
466 0629404 [1]   PLUG
467 0818520 [2]   PLUG
490 0263019 [7]   PLUG
530 0878115 [1]   PIN ASS'Y
530A. +++++++ [1]   PIN
530B. +++++++ [1]   PIN
532 0878116 [1]   PISTON
534 0818523 [1]   STOPPER
535 0818524 [1]   STOPPER
702 0443404 [1]   O-RING
710 A811085 [1]   O-RING
717 A811120 [1]   O-RING
719 A811115 [1]   O-RING
724 4506408 [9]   O-RING
725 957366 [1]   O-RING
728 4506418 [2]   O-RING
732 0443407 [1]   O-RING
774 0983102 [1]   SEAL;OIL
789 4085607 [1]   RING;BACK-UP
792 0249148 [1]   RING;BACK-UP
801 0124811 [1]   NUT;LOCK
808 0131108 [2]   NUT;LOCK
824 0991342 [1]   RING;RETAINING
885 0175241 [1]   PIN
886 0244604 [2]   PIN;SPRING
901 4163072 [1]   BOLT;EYE
953 0978703 [1]   SCREW;SET
954 0818525 [1]   SCREW;SET
981 +++++++ [1]   PLATE
983 0625509 [2]   PIN
Parts on group PUMP;GEAR:
Pos. Part No Qty Parts name Comments
9217993 [1]   PUMP;GEAR
Parts on group REGULATOR;PUMP:
Pos. Part No Qty Parts name Comments
4661756 [1]   REGULATOR:PUMP
079 4654325 [1]   VALVE;REDUCING
412 0135904 [2]   BOLT;SOCKET
413 0213208 [2]   BOLT;SOCKET
418 0667626 [2]   BOLT;SOCKET
436 0211510 [4]   BOLT;SOCKET
438 0102411 [8]   BOLT;SOCKET
466 0236014 [1]   PLUG
496 0263019 [11]   PLUG
601 +++++++ [1]   CASING
611 +++++++ [1]   LEVER
612 +++++++ [1]   LEVER
613 +++++++ [1]   LEVER
614 +++++++ [1]   PLUG
615 +++++++ [1]   PLUG
621 +++++++ [1]   PISTON
622 +++++++ [1]   CASE
623 +++++++ [1]   ROD
624 +++++++ [1]   SEAT;SPRING
625 +++++++ [1]   SPRING
626 +++++++ [1]   SPRING
627 +++++++ [1]   ROD
628 +++++++ [1]   SCREW;ADJUSTING
629 +++++++ [1]   COVER
630 +++++++ [1]   NUT;LOCK
631 +++++++ [1]   SLEEVE
641 +++++++ [1]   COVER
643 +++++++ [1]   PISTON
644 +++++++ [1]   SEAT;SPRING
645 +++++++ [1]   ROD
646 +++++++ [1]   PISTON;PILOT
651 +++++++ [1]   SLEEVE
652 +++++++ [1]   SPOOL
653 +++++++ [1]   SEAT;SPRING
654 +++++++ [1]   SPRING;RETURN
655 +++++++ [1]   SPRING;SET
656 +++++++ [1]   COVER
708 A811075 [1]   O-RING
722 4506406 [3]   O-RING
724 4506408 [9]   O-RING
725 4506320 [1]   O-RING
728 4506418 [1]   O-RING
730 4509181 [1]   O-RING
732 0443407 [2]   O-RING
733 4506420 [1]   O-RING
734 A811025 [1]   O-RING
735 4140470 [1]   O-RING
755 957366 [3]   O-RING
756 4509182 [1]   O-RING
763 A811035 [1]   O-RING
801 0124811 [2]   NUT;LOCK
814 991334 [1]   RING;RETAINING
836 +++++++ [1]   RING;RETAINING
858 0288704 [2]   RING;RETAINING
874 +++++++ [1]   PIN
875 +++++++ [2]   PIN
876 +++++++ [2]   PIN
887 +++++++ [1]   PIN
897 +++++++ [1]   PIN
898 +++++++ [1]   PIN
924 0218852 [1]   SCREW
925 +++++++ [1]   SCREW;ADJUSTING
